HKC SW-1070 Installation Manual page 43

RF-RKP - continued
• In the Locate:RF Keypad menu you will observe the three LEDs on the front of the RF-RKP in question flash
on and off every second when you select it.
Go to the Devices Menu in engineer mode and follow the menu path below...
1 RF Devices Menu
2 Wired Devices Menu
• To remove an RF-RKP go to the Remove:RF Keypad menu in engineer mode and follow the menu path
below.
• You will automatically be brought to RF-RKP 1
• Go to the RF-RKP you want to remove and press
1 RF Devices Menu
2 Wired Devices Menu
• Follow the prompts on the display.
Specifications
Battery Supply
Current Consumption
Battery Life
Range
Temperature
Weight
Dimensions
Standards
!
Note: When wiring a permanent 12Vdc supply to the RF-RKP please ensure that the battery pack (the
one with the 4 Lithium batteries) IS NOT CONNECTED
Default Eng. Code - 4567
4x CR123A 3V Lithium batteries (1,400mAh ea.)
Standby:
Transmit:
Maximum:
Typically >3 years
(based on 4 set/unset cycles per day)
Line-of-sight > 400m
-10°C to +40°C
365g
W = 171mm H = 126mm
EN 50131-3 Grade 2 Class II
+12Vdc
0V
Default User Code - 1111 (Irl) 1234 (UK)
4 Locate:RF SABB
5 Locate:RF Wand
6 Locate:RF Keypad
4 Remove:RF SABB
5 Remove:RF Wand
6 Remove:RF Keypad
25µA
40mA
145mA
D = 41mm
