CHARGING THE HELMET

Use the supplied USB cable and a wall charger to charge the Fenix AR before powering the
helmet. Plug the micro USB cord into the port adjacent to the quick-release strap and secure to
the supplied wall charger.
The Fenix AR utilizes a sophisticated battery charging system. Indicator lights on the back of the
helmet show battery charge status.
Helmet Power On
●●●
●●o
●oo
(●)oo
Helmet Charging
(●)oo
-> o(●)o -> oo(●)
●(●)o ●o(●)
->
●●(●)
●●●
Additional
●●●
(●)oo->ooo
oo(●) -> o(●)o ->
(●)o(●) (●)o(●)
-> ooo->
(●)(●)(●) (●)(●)(●)
-> ooo->
(●)(●)(●)
3 solid red lights
2 solid red lights on left
1 solid red light on left
1 blinking red light on left
all 3 lights blink green in order
from left to right over and over
1 solid green light on the left, 2
green lights on right blink green
in order from left to right
over and over
2 solid green light on the left, 1
green light blinking on right
3 solid green lights
1 solid red light on left, 1 solid
green light in center, 1 solid
blue light on right
all 3 lights blink bright blue in
order from right to left. left led
lights up dim blue until pattern
reaches it, then bright blue,
then all leds turn off and entire
sequence repeats
left and right lights blink blue,
turn off, sequence repeats
all three lights blink blue
together, sequence repeats
all three leds flash magento on
and off at the same time
together
battery fully charged status
while riding
battery ⅔ charged status
while riding
battery low while riding
battery very low while
riding
battery charging, battery
level 30-55%
battery charging, battery
level 55-80%
battery charging, battery
level 80-95%
battery fully charged
helmet is starting up
helmet is updating
software
helmet can be discovered
by other Bluetooth devices
helmet is paired with a
phone by Bluetooth
Error
