Sw-4 Dipswitch Settings - Locknetics 101+ Installation And Programming Manual

CONFIGURE FIRE ALARM INTERFACE DIPSWITCH (SW-1) FOR CORRECT TYPE OF INPUT.
A dry contact is required. It can be normally open or normally closed. If no direct connection is to be made, configure the input for normally open (SW-1 to RIGHT).
SW-1 FIRE ALARM INPUT:
To configure interface to terminals 3&4
on main terminal block.
CONFIGURE THE SW-4 DIPSWITCHES TO SET THE FUNCTIONS OF THE SYSTEM.
Power should not be applied at this time. Note that dipswitches 4 and 6 are specifically for the SEC option. Also note that dipswitch 7 must be "on" for the lock to auto-
matically lock when powered up, or after a fire alarm condition. If it is off, the lock will remain unlocked, with the LED green, when power is applied. In order to lock it, a
reset input or valid code or TEK will be required after power up or after a fire alarm condition.

SW-4 DIPSWITCH SETTINGS

NUISANCE ALERT:
Horn sounds when door pushed to alert people that door is armed. Avoids false alarms.
AUTOMATIC RELOCK:
Door locks upon power up or after fire alarm. If set to OFF: manual reset required.
DOOR FORCED / DOOR PROPPED ALARM (SEC OPTION ONLY)
UNLOCK ALERT:
Horn sounds whenever door is unlocked (and still has power applied to it).
ANTI-TAILGATE (SEC OPTION ONLY):
CONFIGURE HOW
THE DELAYED
EGRESS EVENT IS TO
BE TRIGGERED,
USING DIPSWITCHES
2 & 3
EGRESS DELAY TIME:
This is the time that the door will remain locked and in alarm before it unlocks.
FORM 10111 Rev. C
SW-1 TO RIGHT FOR N.O. OR NO CONNECTION:
SW-1 TO LEFT FOR N.C. CONNECTION:
When door closes it immediately relocks (cancels time delay).
-
BY ON BOARD ROCKER SWITCH ONLY
BY ROCKER SWITCH OR AUXILIARY INPUT
BY ROCKER SWITCH AND AUXILIARY INPUT
DELAYED EGRESS DISABLED
101+ DELAYED EGRESS
MAGNETIC LOCKING SYSTEM
( )
DEFAULT
.
