LG 27UK650 Owner's Manual
Ips led monitor
Hide thumbs
Also See for 27UK650:
- Owner's manual (32 pages) ,
- Owner's manual (32 pages) ,
- Owner's manual (32 pages)
Table of Contents
Related Manuals for LG 27UK650
Summary of Contents for LG 27UK650
- Page 1 Owner's Manual IPS LED MONITOR (LED MONITOR*) *LG LED Monitors are LCD Monitors with LED Backlighting. Please read the safety information carefully before using the product. IPS LED Monitor (LED Monitor) Model List 27UK650 27UK600 www.lg.com...
-
Page 2: Table Of Contents
TROUBLESHOOTING - How to Use the Joystick Button Input Connector Moving and Lifting the Monitor SPECIFICATIONS Installing the Monitor 27UK650 - Assembling the stand base 27UK600 Installing the Monitor Factory Support Mode (Preset Mode, PC) - Assembling the stand base... -
Page 3: License
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. -
Page 4: Assembling And Preparing
The product warranty will not cover damage or injury caused by the use of counterfeit components. It is recommend that use the supplied components. If you use generic cables not certified by LG, the screen may not display or there may be image noises. NOTE Note that the components may look different from those shown here. -
Page 5: Supported Drivers And Software
Supported Drivers and Software You can download and install the latest version from the LGE website ( www.lg.com ). 27UK650 Drivers and Software Installation Priority 27UK600 Monitor Driver Recommended OnScreen Control Recommended Dual Controller Optional... -
Page 6: Component And Button Description
Component and Button Description 27UK650 27UK600 Joystick Button Power LED On: power is on Off: power is off How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. -
Page 7: Input Connector
Input Connector... -
Page 8: Moving And Lifting The Monitor
27UK650 27UK650 It is advisable to place the monitor in the original box or packing material before attempting to move it. -
Page 9: Installing The Monitor
Turn the screw clockwise to secure the stand base. Assembling the stand base Cable Holder 27UK650 Please put a soft cloth on a low table or box to protect the screen of the monitor. Please put the monitor on the soft cloth with the screen facing down. -
Page 10: Installing The Monitor
Installing the Monitor Attach the Stand Base to Stand Body. Tighten the screw to the right. Assembling the stand base 27UK600 Place the screen face down. Stand Body Stand Base CAUTION Attach the screw cover. To protect the screen from scratches, cover the Screw Cover surface with a soft cloth. -
Page 11: Using The Cable Holder
27UK650 Do not carry the monitor upside down by just holding the stand base. This may cause the monitor to fall off the stand and could result in personal injury. -
Page 12: Installing Onto A Table
Place at least 100 mm away from the wall to ensure sufficient ventilation. Adjust the angle of the screen. The angle of the screen can be adjusted forwards or backwards for a comfortable viewing experience. 27UK650 27UK650 15° -5° 100 mm... -
Page 13: Adjusting The Stand Height
Adjusting the Stand Height WARNING 27UK650 To avoid injury to the fingers when adjusting the Handle the monitor with both hands for safety. screen, do not hold the lower part of the moni- tor's frame as illustrated below. 27UK650 27UK600 The height can be adjusted up to 110.0 mm. -
Page 14: Pivot Feature
Pivot Feature Rotate the monitor clockwise as shown in the figure. 27UK650 The pivot feature allows the monitor to rotate 90° clockwise. Head 27UK600 Complete the installation by rotating the monitor Stand 90° as shown below. WARNING To avoid scratching the stand base, make sure... -
Page 15: Using The Kensington Lock
To avoid injury when rotating the display, do not electronics store. place your fingers between the display and the stand base. 27UK650 NOTE The left or right side of the monitor head can be slightly rotated up or down (up to 3°). Adjust the horizontal level of the monitor head. -
Page 16: Installing The Wall Mount Plate
27UK650 If you use improper screw, the product might be dam- aged and drop from mounted position. In this case, LG Electronics is not responsible for it. 27UK650 27UK600 Wall Mount (A x B) 100 x 100... - Page 17 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Please use the genu- ine LG wall mounting bracket. For more informa- tion, contact your local retail store or a qualified installer.
-
Page 18: Using The Monitor
NOTE There may be no video or audio output depending on the DP version of the PC. If you use generic cables not certified by LG, the screen may not display or there may be image noises. For using Mini DP to DP (Mini DisplayPort to DisplayPort) cable, it is recommended that you use DisplayPort 1.2 cable. -
Page 19: Connecting To Av Devices
Connecting to External Devices Connecting to AV Devices HDMI connection Connecting Headphones Transmits the digital video and audio signals from your Connect peripherals to the monitor via the headphones PC and A/V devices to the monitor. Connect your PC port. Connect as illustrated. and AV device to the monitor with the HDMI cable as illustrated below. -
Page 20: User Settings
USER SETTINGS Activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up/down ( ▲ / ▼ ) and left/right( ◄ / ► ) to set the options. Press the joystick button once more to exit the main menu. Joystick Button Button Menu Status... -
Page 21: User Settings
User Settings Menu Settings To view the settings menu, press the joystick button at the bottom of the monitor and then enter the Settings. Configure the options by moving the joystick up/down/left/right. To return to the upper settings or set other settings items, move the joystick to ◄ or press ( ). If you want to exit the settings menu, move the joystick to ◄... - Page 22 Picture Mode on SDR(Non-HDR) signal. Settings > Picture Description Picture Mode Custom Allows the user to adjust each element. The color mode of the main menu can be adjusted. Reader Optimizes the screen for viewing documents. You can brighten the screen in the OSD menu.
- Page 23 Picture Adjust Brightness Adjusts the brightness of the screen. Contrast Adjusts the contrast of the screen. Sharpness Adjusts the sharpness of the screen. SUPER High Optimized picture quality is displayed when a user wants crystal clear images. It RESOLUTION+ is effective for high quality video or game. Middle The optimized picture quality is displayed when a user wants images between low and high modes for comfortable viewing.
- Page 24 Game Adjust Response Time Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Setting to Faster may cause image sticking.
- Page 25 Settings > General Description Language Sets the menu screen to the desired language. SMART ENERGY High Saves energy using the high-efficiency SMART ENERGY SAVING feature. SAVING Saves energy using the low-efficiency SMART ENERGY SAVING feature. Disables the SMART ENERGY SAVING feature. Power LED Turns the power LED on the bottom of the monitor on or off.
-
Page 26: Troubleshooting
TROUBLESHOOTING Nothing is displayed on the screen. Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. Is the power LED on? Check the power cable connection and press the power button. Check that the connected input is enabled (Settings >... - Page 27 Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? Be sure to install the display driver from our web site: http://www.lg.com . Have you installed the display driver? Make sure to check if the video card supports Plug&Play function.
-
Page 28: Specifications
SPECIFICATIONS 27UK650 LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Sub Pixel Pitch 0.1554 mm x 0.1554 mm Resolution Maximum Resolution 3840 x 2160 @ 60 Hz Recommended Resolution 3840 x 2160 @ 60 Hz Video Signal... -
Page 29: 27Uk600
SPECIFICATIONS 27UK600 LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Sub Pixel Pitch 0.1554 mm x 0.1554 mm Resolution Maximum Resolution 3840 x 2160 @ 60 Hz Recommended Resolution 3840 x 2160 @ 60 Hz Video Signal Horizontal Frequency 30 kHz to 135 kHz Vertical Frequency... -
Page 30: Factory Support Mode (Preset Mode, Pc)
Factory Support Mode (Preset Mode, PC) HDMI Horizontal Vertical Display Modes (Resolution) Polarity(H/V) Remarks Frequency(kHz) Frequency(Hz) 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 1280 x 800 49.702 59.810 1280 x 1024... -
Page 31: Hdmi Timing (Video)
HDMI Timing (Video) Factory support mode Horizontal Vertical Remarks (Preset Mode) Frequency(kHz) Frequency(Hz) 480p 31.5 720p 45.0 1080p 67.5 When HDMI ULTRA HD Deep Color is 2160p set to ON Power LED Mode LED Color On Mode White (For a few seconds) Sleep Mode Off Mode... - Page 32 In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
