LG 27UK600 Owner's Manual
Ips led monitor
Hide thumbs
Also See for 27UK600:
- Owner's manual (32 pages) ,
- Owner's manual (32 pages) ,
- Owner's manual (32 pages)
Table of Contents
Related Manuals for LG 27UK600
Summary of Contents for LG 27UK600
- Page 1 Owner's Manual IPS LED MONITOR (LED MONITOR*) *LG LED Monitors are LCD Monitors with LED Backlighting. Please read the safety information carefully before using the product. IPS LED Monitor (LED Monitor) Model List 27UK650 27UK600 www.lg.com...
-
Page 2: Table Of Contents
- How to Use the Joystick Button Input Connector Moving and Lifting the Monitor SPECIFICATIONS Installing the Monitor 27UK650 - Assembling the stand base 27UK600 Installing the Monitor Factory Support Mode (Preset Mode, PC) - Assembling the stand base HDMI - Using the cable holder DisplayPort... -
Page 3: License
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. VESA, VESA logo, DisplayPort compliance logo and DisplayPort compliance logo for dual-mode source devices are all registered trademarks of the Video Electronics Stan- dards Association. -
Page 4: Assembling And Preparing
( Depending on the country ) ( Depending on the country ) 27UK650 27UK650 27UK650 27UK650 27UK650 27UK650 27UK650 27UK650 27UK650 Stand Body Stand Base Cable Holder 27UK600 27UK600 27UK600 27UK600 27UK600 27UK600 27UK600 27UK600 27UK600 Stand Body Stand Base Screw Cover 2 Screws... -
Page 5: Supported Drivers And Software
The product warranty will not cover damage or injury caused by the use of counterfeit components. It is recommend that use the supplied components. If you use generic cables not certified by LG, the screen may not display or there may be image noises. NOTE Note that the components may look different from those shown here. -
Page 6: Component And Button Description
Component and Button Description 27UK650 27UK600 Joystick Button Power LED On: power is on Off: power is off How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. -
Page 7: Input Connector
Input Connector... -
Page 8: Moving And Lifting The Monitor
Hold the top and bottom of the monitor frame firmly. Do not hold the screen itself. 27UK600 When holding the monitor, the screen should face away from you to prevent it being scratched. If you use the monitor panel without the stand... -
Page 9: Installing The Monitor
Installing the Monitor Turn the screw clockwise to secure the stand base. Cable Holder Assembling the stand base 27UK650 Please put a soft cloth on a low table or box to protect the screen of the monitor. Please put the monitor on the soft cloth with the screen facing down. -
Page 10: Installing The Monitor
Installing the Monitor Attach the Stand Base to Stand Body. Tighten the screw to the right. Assembling the stand base 27UK600 Place the screen face down. Stand Body Stand Base CAUTION To protect the screen from scratches, cover the Attach the screw cover. -
Page 11: Using The Cable Holder
Using the cable holder CAUTION Arrange the cables using the cable holder as shown in Illustrations in this document represent typical the illustration. procedures, so they may look different from the actual product. 27UK650 Do not carry the monitor upside down by just holding the stand base. -
Page 12: Installing Onto A Table
-5° 100 mm 100 mm (3.94 inches) (3.94 inches) 100 mm (3.94 inches) 100 mm (3.94 inches) Rear Side Front Side 27UK600 15° -5° 27UK600 100 mm 100 mm (3.94 inches) (3.94 inches) 100 mm (3.94 inches) 100 mm Rear Side Front Side (3.94 inches) -
Page 13: Adjusting The Stand Height
To avoid injury to the fingers when adjusting the screen, do not hold the lower part of the moni- Handle the monitor with both hands for safety. tor's frame as illustrated below. 27UK650 27UK600 The height can be adjusted up to 110.0 mm(4.33 inches). 110.0 mm(4.33 inches) 27UK600... -
Page 14: Pivot Feature
Pivot Feature Rotate the monitor clockwise as shown in the 27UK650 figure. The pivot feature allows the monitor to rotate 90° clockwise. 27UK600 Head Complete the installation by rotating the monitor Stand 90° as shown below. WARNING To avoid scratching the stand base, make sure... -
Page 15: Using The Kensington Lock
The left or right side of the monitor head can be slightly rotated up or down (up to 3°). Adjust the horizontal level of the monitor head. 27UK650 27UK600 Monitor head Using the Kensington lock The Kensington security system connector is located at the back of the Monitor set. -
Page 16: Installing The Wall Mount Plate
27UK650 If you use improper screw, the product might be damaged and drop from mounted position. In this case, LG Electronics is not responsible for it. 27UK650 27UK600 Wall Mount (A x B) 100 x 100... - Page 17 Please use the genuine LG wall mounting bracket. For more informa- tion, contact your local retail store or a qualified installer.
-
Page 18: Using The Monitor
NOTE There may be no video or audio output depending on the DP version of the PC. If you use generic cables not certified by LG, the screen may not display or there may be image noises. For using Mini DP to DP (Mini DisplayPort to DisplayPort) cable, it is recommended that you use DisplayPort 1.2 cable. -
Page 19: Connecting To Av Devices
Connecting to AV Devices Connecting to External Devices HDMI connection Connecting Headphones Transmits the digital video and audio signals from your Connect peripherals to the monitor via the headphones PC and A/V devices to the monitor. Connect your PC port. Connect as illustrated. and AV device to the monitor with the HDMI cable as illustrated below. -
Page 20: User Settings
USER SETTINGS Activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up/down ( ▲ / ▼ ) and left/right( ◄ / ► ) to set the options. Press the joystick button once more to exit the main menu. Joystick Button Button Menu Status... -
Page 21: User Settings
User Settings Menu Settings To view the settings menu, press the joystick button at the bottom of the monitor and then enter the settings. Configure the options by moving the joystick up/down/left/right. To return to the upper settings or set other settings items, move the joystick to ◄ or press ( ). If you want to exit the settings menu, move the joystick to ◄... - Page 22 Picture Mode on SDR(Non-HDR) signal. Settings > Picture Description Picture Mode Custom Allows the user to adjust each element. The color mode of the main menu can be adjusted. Reader Optimizes the screen for viewing documents. You can brighten the screen in the OSD menu.
- Page 23 Picture Adjust Brightness Adjusts the brightness of the screen. Contrast Adjusts the contrast of the screen. Sharpness Adjusts the sharpness of the screen. SUPER High Optimized picture quality is displayed when a user wants crystal clear images. It RESOLUTION+ is effective for high quality video or game. Middle The optimized picture quality is displayed when a user wants images between low and high modes for comfortable viewing.
- Page 24 Game Adjust Response Time Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Setting to Faster may cause image sticking.
- Page 25 Settings > General Description Language Sets the menu screen to the desired language. SMART ENERGY High Saves energy using the high-efficiency SMART ENERGY SAVING feature. SAVING Saves energy using the low-efficiency SMART ENERGY SAVING feature. Disables the SMART ENERGY SAVING feature. Power LED Turns the power LED on the bottom of the monitor on or off.
-
Page 26: Troubleshooting
TROUBLESHOOTING Nothing is displayed on the screen. Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. Is the power LED on? Check the power cable connection and press the power button. Check that the connected input is enabled (Settings >... - Page 27 Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? Have you installed the display driver? Be sure to install the display driver from our web site: http://www.lg.com. Make sure to check if the video card supports Plug&Play function.
-
Page 28: Specifications
SPECIFICATIONS 27UK650 LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Sub Pixel Pitch 0.1554 mm x 0.1554 mm Resolution Maximum Resolution 3840 x 2160 @ 60 Hz Recommended Resolution 3840 x 2160 @ 60 Hz Video Signal Horizontal Frequency 30 kHz to 135 kHz Vertical Frequency... -
Page 29: 27Uk600
SPECIFICATIONS 27UK600 LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Sub Pixel Pitch 0.1554 mm x 0.1554 mm Resolution Maximum Resolution 3840 x 2160 @ 60 Hz Recommended Resolution 3840 x 2160 @ 60 Hz Video Signal... -
Page 30: Factory Support Mode (Preset Mode, Pc)
Factory Support Mode (Preset Mode, PC) HDMI Horizontal Vertical Display Modes (Resolution) Polarity(H/V) Remarks Frequency(kHz) Frequency(Hz) 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 1280 x 800 49.702 59.810 1280 x 1024... -
Page 31: Hdmi Timing (Video)
HDMI Timing (Video) Factory support mode Horizontal Vertical Remarks (Preset Mode) Frequency(kHz) Frequency(Hz) 480p 31.5 720p 45.0 1080p 67.5 When HDMI ULTRA HD Deep Color is 2160p set to ON Power LED Mode LED Color On Mode White (For a few seconds) Sleep Mode Off Mode... - Page 32 In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
