YLINK 1GE+WIFI EPON ONU User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

1GE+WIFI EPON ONU User Manual
1GE+WIFI EPON ONU
USER MANUAL

Advertisement

Table of Contents
loading

Summary of Contents for YLINK 1GE+WIFI EPON ONU

  • Page 1 1GE+WIFI EPON ONU User Manual 1GE+WIFI EPON ONU USER MANUAL...

  • Page 2: Table Of Contents

    1GE+WIFI EPON ONU User Manual Contents Contents ............................I ..................1 C h a p t e r 1 P r o d u c t I n t r o d u c t i o n 1.1 Product Description....................... 1 1.2 Special features ......................
  • Page 3 1GE+WIFI EPON ONU User Manual 3.4.3 MAC Filter ......................24 3.4.4 Port Filter ......................... 24 3.5 Application ........................25 3.5.1 DDNS Configuration ....................25 3.5.2 Advanced NAT Configuration ................. 25 3.5.3 UPNP Configuration ....................27 3.5.4 IGMP Configuration ....................28 3.5.5 MLD Configuration ....................

  • Page 4: Chapter 1 Product Introduction

    Chapter 1 Product Introduction 1.1 Product Description Thank you for choosing the 1GE+WIFI EPON ONU. The terminal devices are designed for fulfilling FTTH and triple play service demand of fixed network operators or cable operators. The box is based on the mature Gigabit EPON technology, which have high ratio of performance to price, and the technology of Layer 2/3.

  • Page 5: Technical Parameter

    1GE+WIFI EPON ONU USER MANUAL 1.3 Technical Parameter Technical items Descriptions PON interface 1EPON connector, SC single-mode/single-fiber, symmetric 1.25Gbps Wavelength Tx1310nm,Rx 1490nm Optical interface SC/PC connector 1* 10/100/1000Mbps auto adaptive Ethernet interfaces. Full /Half Duplex, Interface RJ45 connectors. Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R 1 internal antenna, 1...

  • Page 6: Panel Description

    1GE+WIFI EPON ONU USER MANUAL Figure 1-2: Application chart 1.5 Panel description Interface panel Figure 1-3: Interface panel Name Function ON/OFF Power switch. POWER Connect with power adaptor. Reset button. Press down less than 10s to restart ONU and more than 10s to restore factory default.
  • Page 7 1GE+WIFI EPON ONU USER MANUAL The WiFi runs normal. WiFi WiFi The WiFi is powered down. Port is connected properly. Ethernet LINK/ACT Port connection exception or not connected. Blink Port is sending or/and receiving data. The device is registered to the EPON system.

  • Page 8: Standard Packing Contents

    1GE+WIFI EPON ONU USER MANUAL Chapter 2 Quick Installation 2.1 Standard Packing Contents When you receive our products, please check carefully to make sure that our products whether have some defects or not. If something wrong with shipping, please contact carrier;...
  • Page 9 1GE+WIFI EPON ONU USER MANUAL either end. This may be caused by either too much or too little attenuation over the optical fiber. Please refer to the Layout Description section of this installation manual for normal LED activity. 4. Check all signal levels and services on all the ONU communication ports.

  • Page 10: Chapter 3 Configuration

    1GE+WIFI EPON ONU USER MANUAL Chapter 3 Configuration After finishing the basic connection configuration, you can use its basic function. In order to satisfy individuation service requirements, this charter provides the user parameter modification and individuation configuration description. 3.1 Login The device is configured by the web interface.

  • Page 11: Wan Connection Info

    1GE+WIFI EPON ONU USER MANUAL Version, Software Version. Figure 3-2: Device Information 3.2.2 WAN Connection Info 3.2.2.1 IPv4 connection Information This page shows IPv4 WAN connection information you have configured. Figure 3-3: WAN Information IPv4 3.2.2.2 IPv6 connection Information This page shows IPv6 WAN connection information you have configured.

  • Page 12: User Information

    1GE+WIFI EPON ONU USER MANUAL Figure 3-4: WAN information IPv6 3.2.2.3 EPON Inform This page shows the PON information, such as Connection Info, Link performance statistics, Warning and power, temperature, voltage, Biascurrent. Figure 3-5: EPON Information 3.2.3 User Information 3.2.3.1 WLAN Interface Information This page shows WLAN interface information.

  • Page 13: Remote Management Status

    1GE+WIFI EPON ONU USER MANUAL Figure 3-6: WLAN Interface Information 3.2.3.2 LAN Interface Information This page shows the Ethernet port information, including Gateway Info, Receive/Send Info, LAN Device Info. Figure 3-7: LAN Interface Information 3.2.4 Remote Management Status 3.2.4.1 TR069 Connection Status This page shows the Remote Connection status.

  • Page 14: Network

    1GE+WIFI EPON ONU USER MANUAL Figure 3-8: TR069 Connection Status 3.2.4.2 TR069 Configuration Status This page shows the Remote Configuration status. Figure 3-9: TR069 Configuration State 3.3 Network 3.3.1 Internet This page allows the user to configure WAN connections. You can only configure route mode WAN connections here.
  • Page 15 1GE+WIFI EPON ONU USER MANUAL Figure 3-10: WAN Connection Parameter Illustration The list of WAN connection name that has been created. If you want to create a new WAN connection, please select “Create WAN Connection” and input other Parameter at the same time and then click “Create”...

  • Page 16: Lan

    1GE+WIFI EPON ONU USER MANUAL Max transfer unit. Default Value (in Byte): 1500(static/DHCP) or 1492(PPPoE). Username PPPOE account. Password PPPOE password. Method of WAN connection Obtains IP address. If link type is IP Type/PPP TransType PPP, PPP TransType will be PPPOE; if link type is IP, IP Type will be static or DHCP.
  • Page 17 1GE+WIFI EPON ONU USER MANUAL Figure 3-12: Edit DHCP IP Pool Parameter Illustration LAN IP Address LAN IP address. Subnet Mask LAN IP mask. Enable DHCP Server Enable ONU DHCP server. Start IP Address The start IP address of DHCP IP pool.
  • Page 18 1GE+WIFI EPON ONU USER MANUAL 3.2.3.2 LAN IPv6 Address Settings Figure 3-13: LAN IPv6 Address Settings 3.2.3.3 LAN IPv6 DHCP configuration Figure 3-14: LAN IPv6 DHCP configuration Page 15...

  • Page 19: Wlan Configuration

    1GE+WIFI EPON ONU USER MANUAL 3.2.3.4 RA Configuration Figure 3-15: RA Configuration 3.3.3 WLAN Configuration Figure 3-16: WLAN Configuration Page 16...

  • Page 20: Remote Management

    1GE+WIFI EPON ONU USER MANUAL Figure 3-17: WLAN Advanced Configuration 3.3.4 Remote Management 3.3.4.1 ITMS Server Figure 3-18: ITMS Server Page 17...
  • Page 21 1GE+WIFI EPON ONU USER MANUAL 3.3.4.2 Upload CA Certificate Figure 3-19: Upload CA Certificate 3.3.4.3 LOID This page allows the user to configure LOID and password which are used for registering to OLT. Figure 3-20: LOID settings Page 18...

  • Page 22: Qos

    1GE+WIFI EPON ONU USER MANUAL 3.3.5 QoS 3.3.5.1 Policy Configuration This page allows the user to configure QoS. Figure 3-21: Policy Configuration 3.3.5.2 QoS Classify Figure 3-22: QoS Classify Page 19...
  • Page 23 1GE+WIFI EPON ONU USER MANUAL Figure 3-23: QoS Classify Edit 3.3.5.3 TC Figure 3-24: Traffic Flow Control Information Page 20...

  • Page 24: Time Configuration

    1GE+WIFI EPON ONU USER MANUAL 3.3.6 Time Configuration Figure 3-25: Timer Server 3.3.7 Router Configuration This page allows the user to configure static routing. 3.3.7.1 RIP This page allows the user to configure RIP . Figure 3-26: RIP 3.3.7.2 Static Route This page allows the user to specify a WAN connection as the Route Interface, then configure destination IP, mask and gateway.

  • Page 25: Security

    1GE+WIFI EPON ONU USER MANUAL Figure 3-27: Static Route Parameter Illustration DestNet Destination network address Subnet Mask The Mask of destination network address. Gateway Gateway IP address of static routing. Interface Select WAN connection as static routing interface. 3.4 Security 3.4.1 WAN Access Configuration...

  • Page 26: Firewall

    1GE+WIFI EPON ONU USER MANUAL 3.4.2 Firewall 3.4.2.1 Security Level This page allows the user to set the level of the firewall (IPv4) . Figure 3-29: Security Level 3.4.2.2 Attack Protection Configuration This page allows the user to set the protection against DOS attacks.

  • Page 27: Mac Filter

    1GE+WIFI EPON ONU USER MANUAL Middle: Allow inner or outer hosts which are limited by the rules that have been created to access. High: Forbid ICMP Input, Forbid Port Scan, Denial of Service protections. 3.4.3 MAC Filter This page allows the user to set the relevant parameters of the MAC filter function. The user interface will display the MAC Filter rules after setting completed.

  • Page 28: Application

    1GE+WIFI EPON ONU USER MANUAL 3.5 Application 3.5.1 DDNS Configuration This page allows the user to set DDNS configuration. Figure 3-33: DDNS Configuration 3.5.2 Advanced NAT Configuration This page allows the user to set Advanced NAT configuration. 3.5.2.1 ALG Configuration...
  • Page 29 1GE+WIFI EPON ONU USER MANUAL 3.5.2.2 DMZ Configuration Figure 3-35: DMZ Configuration 3.5.2.3 NAT Configuration Figure 3-36: NAT Configuration Page 26...

  • Page 30: Upnp Configuration

    1GE+WIFI EPON ONU USER MANUAL 3.5.3 UPNP Configuration 3.5.3.1 UPNP Configuration Figure 3-37: UPNP Configuration 3.5.3.2 DLNA Configuration Figure 3-38: DLNA Configuration Page 27...

  • Page 31: Igmp Configuration

    1GE+WIFI EPON ONU USER MANUAL 3.5.4 IGMP Configuration 3.5.4.1 IGMP SNOOPING Figure 3-39: IGMP SNOOPING 3.5.4.2 IGMP Proxy Figure 3-40: IGMP Proxy Page 28...

  • Page 32: Mld Configuration

    1GE+WIFI EPON ONU USER MANUAL 3.5.5 MLD Configuration 3.5.5.1 MLD SNOOPING Configuration Figure 3-41: MLD SNOOPING Configuration Parameter Illustration Disable Disable IGMP. Multicast streams will flood to LAN port. Enable snooping mode. Multicast streams will transmit to LAN Enable port when there is a member join the group.

  • Page 33: Other

    1GE+WIFI EPON ONU USER MANUAL 3.5.6 Other 3.5.6.1 IPTV Figure 3-43: IPTV 3.6 Management 3.6.1 User Management This page allows the user to change username or password. There are two User level accounts: admin and user. The admin account is able to access and modify all settings of ONU. It also can modify user account’s username and password.

  • Page 34: Device Management

    1GE+WIFI EPON ONU USER MANUAL Figure 3-44: User management 3.6.2 Device Management 3.6.2.1 Reboot This page allows the user to reboot the device or restore factory default. The process of reboot will take several minutes. Figure 3-45: Reboot 3.6.2.2 Upgrade This page allows the user to update the software of the device.
  • Page 35 1GE+WIFI EPON ONU USER MANUAL 3.6.2.3 Restore Default Figure 3-47: Restore Default 3.6.2.4 Config File Management This page allows the user to backup and restore the configurations. Figure 3-48: Config File Management Parameter Illustration Download Backup configurations to local computer.

  • Page 36: Log File Configuration

    1GE+WIFI EPON ONU USER MANUAL 3.6.3 Log File Configuration Figure 3-49: Level Figure 3-50: Set Loglevel 3.7 Diagnosis 3.7.1 Network Diagnosis 3.7.1.1 PING Diagnosis This page shows about the ping test. You can diagnose connection status between ONU and other devices.
  • Page 37 1GE+WIFI EPON ONU USER MANUAL Figure 3-51: PING Diagnosis Parameter Illustration IP Address or Host Name Input the destination IP you want to ping. WAN Interface Select the interface you want to test. 3.7.1.2 Tracer Diagnose Figure 3-52: Tracer Diagnose...

  • Page 38: Help

    1GE+WIFI EPON ONU USER MANUAL 3.7.1.3 Manually Inform Use Tr069 Figure 3-53: Manually Inform Use Tr069 3.8 Help The Help information of ONU displays instruction and prompt of each web UI. Figure 3-54: Help information Page 35...

  • Page 39: Chapter 4 Examples

    1GE+WIFI EPON ONU USER MANUAL Chapter 4 Examples 4.1 Internet service There are two configuration methods for Internet service. One works on bridge mode and another works on route mode. 4.1.1 Requirement Scenario 1: ONU works on bridge mode, service VLAN is 10. User gets IP address via DHCP.
  • Page 40 1GE+WIFI EPON ONU USER MANUAL Figure 4-1: Bridge Mode Page 37...
  • Page 41 1GE+WIFI EPON ONU USER MANUAL Huawei MA5680T Configurations (1) Create VLAN MA5680T(config)#vlan 10 smart (2) Configure uplink port’s VLAN MA5680T(config)#port vlan 10 0/19 1 MA5680T(config)#interface giu 0/19 MA5680T(config-if-giu-0/19)#native-vlan 1 vlan 10 (3) Configure DBA profile MA5680T(config)#dba-profile add profile-id 12 profile-name 1GE type3 assure 102400 max...
  • Page 42 1GE+WIFI EPON ONU USER MANUAL Figure 4-2: Add a route WAN connection 2) Enable DHCP server Figure 4-3: Enable LAN DHCP server 3) OLT Configurations V1600D configurations: (1) Create VLAN epon-olt (config)# vlan 10 epon-olt (config-vlan-10)# exit (2) Configure uplink port...
  • Page 43 1GE+WIFI EPON ONU USER MANUAL (3) Configure PON port epon-olt (config)# inter epon 0/2 epon-olt (config-pon-0/2)# switchport hybrid vlan 10 tagged (4) Configure ONU WAN by ONU web Figure 4-4: Route Mode Static IP Huawei MA5680T Configurations: (1) Create VLAN...

  • Page 44: Iptv Service

    1GE+WIFI EPON ONU USER MANUAL MA5680T(config-if-epon-0/5)#ont add 1 0 mac-auth 002A-8523-C610 oam ont-lineprofile-id 11 ont-srvprofile-id 6 (7) Configure service-port MA5680T(config)#service-port 27 vlan 10 epon 0/5/1 ont 0 multi-service user-vlan 10 (8) Configure ONU WAN by ONU web 4.2 IPTV service 4.2.1 Requirement...
  • Page 45 1GE+WIFI EPON ONU USER MANUAL epon-olt (config-pon-0/1)# exit (7) Configure ONU VLAN by ONU web ） Huawei MA5680T Configurations (1) Create VLAN MA5680T(config)#vlan 10 smart (2) Configure uplink port VLAN MA5680T(config)#port vlan 10 0/19 1 MA5680T(config)#interface giu 0/19 MA5680T(config-if-giu-0/19)#native-vlan 1 vlan 10...
  • Page 46 1GE+WIFI EPON ONU USER MANUAL This operation will delete all programs in current multicast vlan Are you sure to change current IGMP version? (y/n)[n]: y (13) Configure IGMP match mode MA5680T(config-mvlan10)#igmp match mode disable //disable mode indicates that OLT will match programs automatically according to members’...

  • Page 47: Chapter 5 Faq

    1GE+WIFI EPON ONU USER MANUAL Chapter 5 FAQ 2. Q: All indicators are not lit? A: (1) Power is off or power adapter is bad. (2) Indicator LED switch is turned off. 3. Q: Why Los indicator flashes? A: (1) There is no optical signal. Maybe the fiber is broke down or connection loosened.
