Mounting

ATTENTION
Material damage caused by neglected ambient conditions
Danger of malfunction or damage!
• Assuring accessibility for installation, operation and maintenance
• Protected, dry surroundings
• Avoid exposure to heat/sun
•
Keep a safe distance to sources of electrical noise
Control cabinet mounting
Control cabinet removal
AMBUS® Link
1. Place recesses of the device at the top
edge of the mounting rail
2. Press lightly on the AMBUS
®
3. AMBUS Link snaps onto the mounting
rail
®
AMBUS Link is firmly connected to the mount-
ing rail
1. Remove the piston
2. Lift AMBUS
rail
®
AMBUS Link is separated from the mounting
rail
®
®
Link up from the mounting
Link
