Daikin DCM601A51 Commissioning Manual

Intelligent touch manager energy navigator setup
Hide thumbs Also See for DCM601A51:

Advertisement

Quick Links

See also: Commissioning Manual , Installation Manual
Commissioning Manual
Supplementary Volume
intelligent Touch Manager
Energy Navigator Setup
Model
DCM601A51
MONITOR
ON
SLAVE
LAN SW
CPU ALIVE
LAN LINK D MONITOR
D MASTER
BACKUP
FRONT BACK
RESET
OFF
MASTER
SERVICE LAN

Advertisement

loading

Related Manuals for Daikin DCM601A51

Summary of Contents for Daikin DCM601A51

  • Page 1 Commissioning Manual Supplementary Volume intelligent Touch Manager Energy Navigator Setup Model DCM601A51 MONITOR SLAVE LAN SW CPU ALIVE LAN LINK D MONITOR D MASTER BACKUP FRONT BACK RESET MASTER SERVICE LAN...

  • Page 2: Table Of Contents

    • Configure the source from which to obtain the room temperature ..........9 • Configure the month when to start data collection ..............11 • Configure an additional energy conversion type ..............12 • Data Clear ..........................13 Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...

  • Page 3: Energy Navigator Setup

    Energy Navigator can address various needs but depending on how your equipment is engineered, such as whether or not watt-hour meters are installed and whether or not the commissioning process for Power Proportional Distribution has been completed. Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...
  • Page 4 Legend Legend : Available × : : Available in part : Unavailable × Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...
  • Page 5 (Creation of group to which to manually enter the actual energy consumption) (Creation of group to which to manually enter the actual energy consumption) : Available : Some functions available × : Unavailable Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...
  • Page 6 CT value.) (Displays power consumption when there is setpoint gap, based on CT value.) (Sampling possible by default rule) : Available : Some functions available × : Unavailable Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...
  • Page 7 Log into the service mode Configure the source from which to obtain the room temperature This manual Configure the month when to start data collection Configure an additional energy conversion type * When necessary Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...

  • Page 8: Log Into The Service Mode

    Log into the service mode Display the Menu List screen. Touch the four corners of the screen in the indicated order. The Password Input dialog appears. Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...
  • Page 9 Enter the service password (daikin) and touch the OK button to log into the SE Mode. Furthermore, if the screen is locked, entering the service password instead of the administrator password after carrying out the special operation indicated below, allows you to unlock the screen and log into the SE Mode.

  • Page 10: Configure The Source From Which To Obtain The Room Temperature

    *Detailed View screen (operational state) On the service mode Menu List window, select and open the Service Settings tab. Touch the Energy Navigator button to bring up the Energy Navigator Setup window. Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...
  • Page 11 Room temperature settings (4). If you have chosen Ai, touch the Modify button to bring up the Ai Selection window. Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...

  • Page 12: Configure The Month When To Start Data Collection

    Configure the month when to start data collection To configure the month when to start data collection, use the following procedure: Touch the Modify button to bring up the Month to Collect Data Setup window. Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...

  • Page 13: Configure An Additional Energy Conversion Type

    Configure an additional energy conversion type You can configure an additional energy conversion type for use in Budget/Actual Energy Management as needed. Touch the Modify button to bring up the Energy Conversion TypeSetup window. Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...

  • Page 14: Data Clear

    You can clear the trend data as needed. Touch the Clear button (11). On the confirmation dialog box that appears, touch the Yes button to clear the data and restart iTM. Commissioning Manual (Energy Navigator Setup) EM11A028 DCM601A51 intelligent Touch Manager...
  • Page 15 EM11A028 (1208) HT...
