ATL Sport Model
All Terrain Launching R/C Brushless Airplane
IMPORTANT NOTE:
J4C03 2.4GHz 4CH transmitter is supplied with MODE 2 as
standard set, If needed, you could simply switch to MODE 1
by easy steps, see details in page 9.
SPECIFICATION:
Wing span: 700mm
●
Wing loading: 25g/dm
●
Fuselage length: 970mm
●
Flying weight: 575g
●
●
Motor thrust power: 850g
V2013-7 manual
Model No:6302
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dragonfly 6302 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Joysway Dragonfly 6302

Summary of Contents for Joysway Dragonfly 6302

  • Page 1 V2013-7 manual Model No:6302 IMPORTANT NOTE: J4C03 2.4GHz 4CH transmitter is supplied with MODE 2 as standard set, If needed, you could simply switch to MODE 1 by easy steps, see details in page 9. SPECIFICATION: Wing span: 700mm ● Wing loading: 25g/dm ●...

  • Page 2: Fcc Requirement

    Dragonfly All Terrain Launching Airplane PNP Model No:6302 WA R NIN GS IMPORTANT: Before beginning assembly, please read and understand the warnings listed following. Failure to read and understand these warnings could lead to bodily harm and/or injury. 1. This model is not a toy. It is for beginner, intermediate and experienced modeller 2.

  • Page 3: Kit Contents

    KIT CO N TE NT S Right horizontal tail Fuselage Left wing Right wing Left horizontal tail 6*4*400mm carbon fiber tube Electronic compartment hatch Y wire cord Battery compartment hatch 6*4*200mm carbon fiber tube 3*1.4*120mm carbon fiber tube Push rod for horizontal tail 1.5mm Allen key Cohere sticker for horizontal tail Spare 6*4 propeller...
  • Page 4 AS SE MB LI NG Y OU R DR AG O N F L Y 1. Remove battery compartment hatch and electronic compartment hatch as photos show. 2. Rip off the double side tape on the left wing as photos show. 3.
  • Page 5 5. Rip off right wing doulbe side tape, align carbon fiber tube with two holes on right wing side and press right wing to join fuselage. before they join together, make sure the servo extend wire get through the hole on fuselage. the servo extend wire can’t be stuck when right wing join with fuselage. 6.

  • Page 6: Prep A Rat Ion B E F Or E Fl I Ght

    8. Use two pcs of cohere sticker to join two horizontal tails together up and down. 9. Insert Z shape end of pushrod into the outer hole of servo arm as show. The other end of pushrod get through the clevis and secure it with 1.5mm allen key as show. make sure horizontal tail are in neutral position. Servo wires connecting to Receiver (Apply to MODE 1 and MODE 2) 1.
  • Page 7 STEP 2: CHARGING THE LIPO PACK (NOT INCLUDED) The following parts are optional purchasing parts. 11.1V 1200mAh 20C LiPo pack. 2S/3S Balance charger with adapter NOTE: Familiarize yourself with the charging procedure of the lipo battery. Read the charger Manual completely and fully charge the lipo battery.
  • Page 8 STEP 4: FAMILIAR WITH RADIO CONTROL SYSTEM Mode 1 Power indicator Power switch Elevator down Throttle Max Rudder Rudder Aileron Aileron Ieft right Ieft right Elevator up Throttle Min Elevator Trim Throttle Trim Rudder Trim Aileron Trim Mix Control Switch Reverse switch on throttle Charge Jack Reverse switch on rudder...
  • Page 9 TRANSMITTER MODE SWITCHING J4C03 2.4GHz 4CH transmitter is supplied with MODE 2 as standard set, If needed, you could simply switch to MODE 1 by easy steps as belowing: Step 1: Open battery cover, switch MODE button to MODE 1. Step 2: Use screwdriver to screw down the up-left screw tightly as photo shown.
  • Page 10 TRANSMITTER/RECEIVER BINDING The binding process effectively ties the J4C03 transmitter and J5C01R receiver together. Under normal circumstances, both items are supplied like this from the factory. If, however, you find that your transmitter and receiver are not bound (receiver’s red LED will be lighting), you should do the following: 1.
  • Page 11 STEP 7: TEST THE RUDDER (Mode 2) 1. Move the rudder control stick to the left, the rudder turns to the left. 2. Move the rudder control stick to the right, the rudder turns to the right. NOTE: If the movement of rudder works in opposite position, please check the rudder reverse switch and make necessary adjustment.

  • Page 12: Valu Abl E Ex Pe Ri E N C E

    FL IGHT MA NU AL Choose a good flying site and day 1. The ideal location for flying has wide-open space in four directions with no people 2. Choose location carefully! Do not operate model near these areas: Houses or buildings, children’s play areas, road traffic, railways, airports, overhead powerlines.
  • Page 13 Command And Fly (Mode 2) Speed up Left stick up Speed down Left stick down Ascending Right stick down Descending Right stick up Left stick right Nose turn right Left stick left Nose turn left The Body incline Right Stick Right to Right The Body incline Right Stick Left...

  • Page 14: Spare Part List

    Adjusting trims during flight (Mode 2) Rudder Trim 1. Let go of control sticks. If airplane moves left, adjust rudder trim to the right. Elevator Trim 2. Let go of control sticks. If airplane moves upward, adjust elevator trim to downward. Aileron Trim 3.
