Brushless Motor Boat
Model No: 8651V2
ROCKET V2 Deep Vee Boat
Model No: 8654
Monster Catamaran Boat
Model No: 8653 V3
Mad Flow V3 F1 Boat
Motor................................................................................Water cooled out-runner brushless motor (Included)
Propeller...........................................................................................................2pcs nylon propeller (Included)
Speed Control........................................Water cooled & Water Proof 30A Brushless ESC W/BEC (Included)
Servo.....................................................................................................9g metal gear rudder servo (Included)
Radio System...............................................2.4G 2CH Digital Proportional Transmitter & Receiver (Included)
Drive System.......................................................................................3mm Flex Cable Direct Drive (Included)
Battery..............................................................................................11.1V 2200mAh 35C LiPo (Optional Part)
Charger.............................................................2S/3S Balance Charger with AC Power Cable (Optional Part)
Transmitter Battery...........................................................................4pcs AA Alkaline Batteries (Not Included)
620mm(24.5 in)
155mm(6 in)
55 km/hr
570mm(22.5 in)
195mm(7.7 in)
55 km/hr
590mm(23.2 in)
230mm(9.1 in)
55 km/hr
Advertisement
Table of Contents
Related Manuals for Joysway ROCKET V2 Deep Vee Boat
Summary of Contents for Joysway ROCKET V2 Deep Vee Boat
- Page 1 ARTR Brushless Motor Boat 620mm(24.5 in) 155mm(6 in) 55 km/hr Model No: 8651V2 ROCKET V2 Deep Vee Boat 570mm(22.5 in) 195mm(7.7 in) 55 km/hr Model No: 8654 Monster Catamaran Boat 590mm(23.2 in) 230mm(9.1 in) 55 km/hr Model No: 8653 V3 Mad Flow V3 F1 Boat Motor................Water cooled out-runner brushless motor (Included)
-
Page 2: Satety Precautions
Satety Precautions All pictures, descriptions, and specifications founded in this instruction manual are subject to changes without notice. Joysway maintains no responsibility for inadvertent errors in this manual. One pack of 11.1V 2200mAh 35C LiPo Pack or higher capacity LiPo. - Page 3 Water proof balloon for RX Boat Stand EVA 8mm Spanner ROCKET V2 Deep Vee Boat Monster Catamaran Boat 8654 Monster Rescue Plastic Rudder Monster include one pc of rescue PVC rudder plate in the tool bag, This is installed by end user himself. If end user want to race this boat aggressively in rough wave, there is more chance boat will capsize.
- Page 4 Insert three ABS pipes into the holes of two boat stands shown as photos,compress boat stands and ABS pipes tightly,then stick EVA to the four angles,this will protect the hull bottom from scratches during construction and storage. Self-righting feature for Rocket deep vee boat & Mad Flow F1 boat Rocket deep vee boat &...
-
Page 5: Installing Transmitter Batteries
Installing transmitter batteries four RED. Receiver connection diagram BATT.(6V) THROTTE SERVO Note: If ESC with BEC function, no need to connect battery with receiver. Caution: Before racing boat, Please use balloon supplied in tool bag to wrap receiver for water proof 1. - Page 6 The battery locators help align the batteries to the best running center of gravity fof maximum performance. Belowing are the batteries location inside the hull. Battery location Battery location Rocket V2 Deep Vee Boat battery Monster Catamaran Boat battery locator locator...
-
Page 7: Transmitter/Receiver Binding
1. There is a water proof rubber ring glued along the slot of hull, always make sure it’s securely positioned before re-position the upper deck. 2. Use the waterproofing tape provided in the tool bag to seal the hull as shown after you have connected the battery pack, before placing your boat on the water. -
Page 8: Transmitter Introduction
battery Transmitter introduction Steering reverse switch Throttle trim-brake Steering trim-right Throttle trim-forward Steering trim-left Steering traveling angle-right Steering traveling angle-left Power indicator Power switch... -
Page 9: Trim Adjustment
EPA Adjustment Steering reverse switch Function Use this when performing left and right steering angle adjustments. End Point Adjustment (EPA) adjusting value range: 0%-100% Setting 1. Steering (right side) angle adjustment Rotate “ST/R” knob to the left end point means minimum value 0%, right end point means maximum value 100%. - Page 10 ESC Low Voltage Cut Off ESC with low voltage hard cut off at 3.2V per cell, when driving your boat , as soon as you notice boat stop, that means ESC low voltage cut off effective, you should immediately drive boat back to shore in slow speed, recharge battery and race again.
- Page 11 865103 D2842 Out-runner brushless motor 865205 Water cooled motor mount 865107 Pushrod 860103 Flex shaft set 860104 Rudder and Support Set 860108 Plastic boat stand 860205 Rear shaft strut set (W/O bearings) 860207 Water proof gasket (PK2) 930507 Bearing set 930511 P1.4XD35mm two blade nylon propeller (PK2) 930512...
