4IPNET HSG100 Quick Installation Manual

Wireless hotspot gateway
Hide thumbs

Advertisement

Quick Links

Download this manual
HSG1 00
V2. 0 0

Advertisement

loading
Need help?

Need help?

Do you have a question about the HSG100 and is the answer not in the manual?

Questions and answers

Related Manuals for 4IPNET HSG100

Summary of Contents for 4IPNET HSG100

  • Page 1 HSG1 00 V2. 0 0...
  • Page 2 All rights reserv ed. download up-to-date v ersion this document, please v isit www.4 ipnet.com. Copyright © 4IPNET, INC. All rights re se rv e d .
  • Page 3 R e g u l a t o r y I n f o r m a t i o n FCC Certification HSG100 has been evaluated and certified according to FCC Rules Part 15 subpart C under one granted FCC-ID: VZ9080001.
  • Page 4 This declaration is only valid for configurations (combinations of software, firmware, and hardware) provided and supported by 4ipnet Inc. The use of software or firmware not provided and supported by 4ipnet Inc. may result in the equipment no longer being compliant with the regulatory requirements.

  • Page 5: Package Contents

    The 4ipnet HSG100 is the most economical yet feature-rich Wireless Hotspot Gateway, targeting mini-size stores who want to provide small, single-point wireless Internet access service. HSG100 is a perfect choice for beginners to run hotspot businesses. It does not cost a fortune to buy a pile of equipment, nor does it take the skills of an expert to glue multiple applications out of multiple freeware.

  • Page 6: System Overview

    Press and hold the Reset button for more than 10 seconds to reset the system to default configurations. WAN (PoE) This port is for connection to external network not managed by HSG100. For example, it may connect to the ATU-Router of an ADSL, or the port of a Cable Modem.
  • Page 7 Quick Installation Guide H S G1 0 0 Wireless Hotspot Gateway E N GL I S H Rear Panel Top LED Panel Copyright © 4IPNET, INC. All rights re se rv e d .
  • Page 8 Connect HSG100 to your outbound network device. Connect one end of the Ethernet cable to the WAN port of HSG100 on the front panel. Per your needs, connect the other end of the cable to the ATU-Router of an ADSL, a cable modem, a switch or a hub.

  • Page 9: Getting Started

    Once the hardware installation is done, set DHCP in TCP/IP of the administrator PC to get an IP address dynamically. Connect the PC to the LAN Port of HSG100. An IP address will be assigned to the PC automatically via the HSG100 built-in DHCP server.
  • Page 10 The Home Page will appear after a successful login. To logout, simply click Logout at the upper right hand corner Note: of the interface to return to the Administrator Login Page. Copyright © 4IPNET, INC. All rights re se rv e d .
  • Page 11 E N GL I S H C o mmo n Settin g s < Setup Wizard > HSG100 provides a Setup Wizard for quick configuration. To quickly configure HSG100 by using the Setup Wizard, click on the Setup Wizard button to start the configuration process.
  • Page 12 For security concern, it is strongly recommended to change the administrator's password. HSG100 supports NTP time synchronization only, it is strongly recommended to make sure the NTP server is reachable and alive. Copyright © 4IPNET, INC. All rights re se rv e d .
  • Page 13 Below depicts an example for Dynamic. • Click Wireless radio button. • Select desired wireless Band, Channel, and ESSID for public zone. • Click Next to continue. Copyright © 4IPNET, INC. All rights re se rv e d .
  • Page 14 Required is enabled. When authentication is enabled, a default authentication server shall be configured. HSG100 supports 4 kinds of authentication servers including Server 1 (LOCAL), Server 2 (RADIUS), Server 3 (RADIUS), and On-demand (ONDEMAND). Below depicts an example for LOCAL.
  • Page 15 Step 4. Confirm and Restart • Click Finish to save current settings and restart the system. • A confirmation dialog box will then appear. Click OK to continue. Copyright © 4IPNET, INC. All rights re se rv e d .
  • Page 16 DNS cannot be found. When the following Administrator Login Page appears, it means the restart process • is now completed. Copyright © 4IPNET, INC. All rights re se rv e d .
  • Page 17 ESSID of HSG100 (e.g. “HSG100”) and get associated with this ESSID. The client device will obtain an IP address automatically via DHCP from HSG100. Open a web browser on a client device, access any URL, and then the default User Login Page will appear.
  • Page 18 “testuser” or “testuser@local” in the Username field. Congratulation! The Login Success Page will appear after a client has successfully logged into HSG100 and has been authenticated by the system. The appearance of Login Success Page means that HSG100 has been installed and configured properly.
  • Page 19 HSG100 supports two zones, Private and Public. In the Private Zone, authentication is not required to access the network via wired and wireless. Administrator can access the Web Management Interface (WMI) of HSG100 through the wired LAN port.
  • Page 20 Wireless Hotspot Gateway E N GL I S H Step 2: Configure Public Zone Settings Click the System menu. Click the Zone Configuration tab. Click Configure of Public. Copyright © 4IPNET, INC. All rights re se rv e d .
  • Page 21 Wireless Hotspot Gateway E N GL I S H Step 3: Configure ESSID for Public Zone Enter a desired ESSID for Public Zone in Wireless Settings: HSG100-2. Click Apply at the bottom of this page. Step 4: Configure ESSID for Private Zone Enter a desired ESSID for Private Zone in Wireless Settings: HSG100-1.
  • Page 22 Quick Installation Guide H S G1 0 0 Wireless Hotspot Gateway E N GL I S H Step 5: Confirm Configuration and Restart Click Restart once all configurations are done. Copyright © 4IPNET, INC. All rights re se rv e d .
  • Page 23 Please do not interrupt the system during the restarting process. For further configuration and information, please refer to the User’s Manual. P / N : 2 0 0 2 0 0 9 0 7 1 8 Copyright © 4IPNET, INC. All rights re se rv e d .
