- Page 1 HSG320 V1.00 Wireless Hotspot Gateway...
-
Page 2: Copyright Notice
Copyright Notice This document is protected by USA copyright laws and other laws. Besides, the document is the property of 4IPNET, INC. You may not copy, reproduce, distribute, publish, display, perform, or modify any part of this publication in any form or by any means without prior written permission from 4IPNET, INC. - Page 3 This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. Copyright © 4IPNET, INC. All rights reserved.
- Page 4 This declaration is only valid for configurations (combinations of software, firmware, and hardware) provided and supported by 4ipnet Inc. The use of software or firmware not provided and supported by 4ipnet Inc. may result in the equipment no longer being compliant with the regulatory requirements.
-
Page 5: Package Contents
(2 x 300Mbps), high capacity Wireless Hotspot Gateway, targeting small-to-medium-sized store owners who want to provide wireless Internet access services. The HSG320 is a perfect choice for hotspot operation, in terms of cost-effectiveness, deployment time, and user management. This feature-rich product goes beyond what an operator could think of. Not only does it come with two built-in access point compliant with IEEE 802.11 a/b/g/n, it... -
Page 6: System Overview
For attaching an Ethernet cable to an uplink service. PoE (Power over Ethernet) is supported for the WAN port. 6 LAN Ports 1 - 2 The ports for connections with LAN side devices. Copyright © 4IPNET, INC. All rights reserved. - Page 7 Quick Installation Guide HSG320 Wireless Hotspot Gateway ENGLISH 7 Console To access HSG320 via the console interface. 9 WES LED For indicating WDS connection status. Master (Press for more Slave (Press once and than 3 seconds) then release right away)
-
Page 8: Hardware Installation
3. Connect HSG320 to your outbound network device. Connect one end of the Ethernet cable to the WAN port of HSG320 on the rear panel. Depending on the type of Internet service provided by your ISP, connect the other end of the cable to the ATU-Router of an ADSL, a cable modem, a switch or a hub. -
Page 9: Getting Started
1. Once the hardware installation is complete, set DHCP in TCP/IP settings of the administrator PC to “Obtain an IP address automatically”. Connect the PC to the LAN1 Port of HSG320. An IP address will be assigned to the PC automatically via the HSG320 built-in DHCP server. -
Page 10: Common Settings
Administrator Login Page. Common Settings < Setup Wizard > HSG320 provides a Setup Wizard for quick configuration. To quickly configure HSG320 by using the Setup Wizard, click on the Setup Wizard button to start the configuration process. - Page 11 Select an appropriate time zone from the Time Zone drop-down list box and enter the URL of a valid NTP server to set up the system time. Click Next to continue. Copyright © 4IPNET, INC. All rights reserved.
- Page 12 HSG320 Wireless Hotspot Gateway ENGLISH For security concern, it is strongly recommended to change the administrator's password. HSG320 supports NTP time synchronization. If NTP is the option selected, it is strongly recommended to make sure the NTP server is reachable and alive.
- Page 13 MAC address of this user) and assign an Applied Group to this particular user (or use the default None). Click Next to continue. Step 4. Confirm and Restart Click Finish to save current settings and restart the system. Copyright © 4IPNET, INC. All rights reserved.
- Page 14 The system is trying to locate a DNS server at this stage. Therefore, a Note: longer startup time is required if the configured DNS cannot be found. When the following Administrator Login Page appears, it means the restart process is now completed. Copyright © 4IPNET, INC. All rights reserved.
-
Page 15: Deployment Example
Using wireless instead of wired service helps hotspot owners to build network service quickly. HSG320 supports two zones, Private and Public. In the Private Zone, authentication is not required to access the network via wired and wireless. Administrator can access the Web Management Interface (WMI) of HSG320 through the wired LAN port. - Page 16 Quick Installation Guide HSG320 Wireless Hotspot Gateway ENGLISH Copyright © 4IPNET, INC. All rights reserved.
- Page 17 Step 3: Configure ESSID for Public Zone Enter a desired ESSID for Public Zone in Wireless Settings for both RF cards RF1 and RF2: HSG320-2. Click Apply at the bottom of this page. Copyright © 4IPNET, INC. All rights reserved.
- Page 18 HSG320 Wireless Hotspot Gateway ENGLISH Step 4: Configure ESSID for Private Zone Enter a desired ESSID for Private Zone in Wireless Settings: HSG320-1. Note: Private Zone ESSID is not broadcasted by default but can be Enabled. Select a desired Security Type for Private Zone for security enhancement if needed.
- Page 19 Quick Installation Guide HSG320 Wireless Hotspot Gateway ENGLISH Copyright © 4IPNET, INC. All rights reserved.
- Page 20 Please do not interrupt the system during the restarting process. For further configuration and information, please refer to the User’s Manual. If you have purchased 4ipnet’s Wireless Ticket Generator and/or 4ipnet’s POS Printer and wish to incorporate it into your Hotspot, please follow the Connection Guide of Wireless Ticket Generator after you have installed and configured your HSG320.
