Nexsan Unity Storage 316 Quick Start Manual

NEXSAN Unity Storage 316 Expansion
Quick Start Guide
This document provides installation steps to rack, cable, and power on a Unity Storage 316 Expansion.
For additional documentation please visit
Taking delivery
Check to ensure that no damage has been sustained
to the packaging in transit. If any of the Unity
Storage 316 components appear damaged, please
contact your reseller immediately.
Item Name
1 LAN port
2 Status LED
3 Unit ID status LED
4 BMC Reset button
5 SAS IN ports
6 SAS OUT ports
7 SAS link status LEDs (2 IN, 2x OUT)
Prepare for installation
Carefully read the safety notices on
A
Ensure ahead of time that you have a suitable
B
rack; see Rack and enclosure specifications
page 4.
Ensure that you have a Phillips screwdriver.
C
http://helper.nexsansupport.com/unt_support.html
Front view (bezel removed)
Rear view controller I/O components.
page 4.
on
1 — Unity Storage 316 Expansion Quick Start Guide
Hardware overview
Here are some of the key components of the US 316
Expansion:
Description
Not used with Unity Storage Expansions
Green: Initialization successful
Red: Initialization failure
On/Off
Resets the base management controller
Serial Attached SCSI IN ports from the head unit
SAS OUT ports to another storage unit
Green: All four physical layers (PHY) of each
port connected with consistent link speed (12 G
or 6G)
Red: Single PHY degraded link speed or
disconnected
Arrange for someone to assist you during
D
installation.
CAUTION: Acclimate new disk drives to
room temperature for two hours before you
install them.
Firmware Version 5.1
