Rixen TK-6200 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
CONTENTS
■TK-6200 specifications---------------------------------1
■Instrument descriptions--------------------------------2
■Display descriptions------------------------------------3
■Key descriptions----------------------------------------4
■Instructions---------------------------------------------5
■RS-232 transfer protocol-------------------------------8
■Precautions--------------------------------------------11

Advertisement

loading
Need help?

Need help?

Do you have a question about the TK-6200 and is the answer not in the manual?

Questions and answers

Related Manuals for Rixen TK-6200

Summary of Contents for Rixen TK-6200

  • Page 1: Table Of Contents

    CONTENTS ■TK-6200 specifications---------------------------------1 ■Instrument descriptions--------------------------------2 ■Display descriptions------------------------------------3 ■Key descriptions----------------------------------------4 ■Instructions---------------------------------------------5 ■RS-232 transfer protocol-------------------------------8 ■Precautions--------------------------------------------11...

  • Page 2: Tk-6200 Specifications

    9 V Battery or AC Adapter Dimensions/Weight 150 x 75 x 28 mm，Approx. 320g ( battery included) Input connection Mini connector waterproof socket(IP66) TK-6200 High accuracy thermometer(Type K) TU-655C Plastic Carry case Standard Applications TU-609 Battery 9V006P Instruction manual and warranty Operating environment -20 ~ + 60℃;...

  • Page 3: Instrument Descriptions

    ■ Instrument descriptions ○ Multi-Function LCD Display ○ Battery cover ○ Power switch ○ AC Adaptor Input ○ Setting and℃/℉ switching ○ USB Output port ○ Function key ○ RS-232 Output connector ○ Setting ○ T1 Probe input connector ○ Model No.

  • Page 4: Display Descriptions

    ■ Display descriptions Display Descriptions Battery Power Symbol Manual shut down LED Back light on Buzzer on Under Calibrating Maximum Value HOLD Data Hold Minimum Value Average Value T1 probe T2 probe Hi.A High Alarm Lo.A Low Alarm Area Digit A.B.C. Testing Value, Alarm setting Value, T1,T2 indicating ℃/℉...

  • Page 5: Key Descriptions

    ■ Key descriptions ※The ℃/℉ is changeable only under the testing mode. Key Function Descriptions LCD display Press once for power on or off. (If the instrument is Power left without any button operation, it will automatically turn On/Off off after five minutes.) Hold key, then hold key to turn on,...

  • Page 6: Instructions

    ■ Instructions A. Testing Mode: Press to switch display conditions. Probe condition, warning data condition, Power indication Normal conditions T1 Temp. data, (Area A) T1 Real-time T1 Hi.A data (Area B), T1 Lo.A data(Area C) Temperature display T2 Temp. data, (Area A) T2 Real-time T2 Hi.A data (Area B), T2 Lo.A data (Area C) Temperature display...
  • Page 7 B. Readings hold mode Under the testing mode, press to enter hold mode, and press return to the testing mode. Press key to switch the display condition. The data will be deleted when the mode or system are changed. Condition Display content T1-HOLD display Lock the T1 Temperature data...
  • Page 8 C. Setting Mode Under the testing mode press for over 2 seconds to enter the setting mode. Press for over 2 seconds to switch to the next setting mode. Push key to increase the value, Push key to reduce the value Push key to change digit When all settings are done it will return to the testing mode.

  • Page 9: Rs-232 Transfer Protocol

    RS-232 transfer protocol ■ RS-232 The transmission end is one way transfer via the three wire (touch ground) to input and output. Using the original transmission line or cable under 10m is recommended. Baud rate: 57600, 19200, 9600, 4800 Transfer status: / 8 / N / 1 Transfer content: (8BIT) Read Holding Registers by Function 03H A.
  • Page 10 Slave Byte Data(1) Data(1) Data(1) Data (1) Function address count Middle Last Data(2) Data (2) Data(2) Data (2) Middle Last 0x00013883=80003，Real value = 80003/100，Real value = 800.03 0x00013CAB=81067，Real value = 81067/100，Real value = 810.67 ☆℃ and ℉ set is data of MOD “bit 05” at address 0x000A C .Request Data Frame Ex: Read the data from address 0x0008 (Read 10-byte of data from address 0x0008) Starting...
  • Page 11 **Example** Set mode: 1. Temperature unit=℃ 2. No use 3.T1 no ERROR 4. T2 no ERROR 5. Power74~50% Address Data name Data size 0000h T1 Real-Time Data(Hold) 4-Byte 0001h T1 Max 4-Byte 0002h T1 Min 4-Byte 0003h T1 Avg 4-Byte 0004h T2 Real-Time Data(Hold) 4-Byte...

  • Page 12: Precautions

    1. This instrument has a waterproof function, please do not use it in a high temperature environment or with corrosive materials to avoid leakage or damage. 2. To avoid the problems that might occur when connecting to the computer, the Rixen USB computer interface cable and windows software (Model No. TU-USB-C) is recommended.
