- Page 1 I401500 INSTALLATION, OPERATION AND MAINTENANCE GUIDE For Saturn Series Ball Valves Ball Valve Division P.O. BOX 125 PAGELAND, S.C. 29728 803-672-6161...
- Page 2 ****CAUTION**** BEFORE INSTALLATION: Ensure that the component materials of the valve being installed are compatible with the media, with regard to corrosiveness, pressure, and temperature. THREADED END INSTALLATION 1. Pipe connections to be threaded into these valves should be accurately threaded, clean and free of dirt and metal shavings.
- Page 3 MAINTENANCE Normal stem packing wear can be compensated for by tightening the packing gland nut (except 91-200 Series). If all of the adjustment to the packing gland nut has been made, remove the lever and packing gland nut and add one or two replacement bearings on top of the old packing.
- Page 4 1. LEVER SCREW OR NUT 7. SEAT 2. LEVER & GRIP ASSEMBLY 8. BALL 3. PACKING GLAND NUT 9. RETAINER 4. STEM (Blow-Out-Proof Type) 10. STEM BEARING 5. STEM PACKING 11. “O”-RING 6. VALVE BODY 12. PACKING GLAND...
