  • Page 1 HDO9000 Oscilloscopes Getting Started Guide...
  • Page 2 Teledyne LeCroy documentation for internal educational purposes. Teledyne LeCroy is a trademark of Teledyne LeCroy, Inc. Other product or brand names are trademarks or requested trademarks of their respective holders. Information in this publication supersedes all earlier versions. Specifications are subject to change without notice.

  • Page 3: Table Of Contents

    Welcome Thank you for buying a Teledyne LeCroy product. We’re certain you’ll be pleased with the detailed features unique to our instruments. This guide is intended to help you set up an HDO9000 oscilloscope and learn some basic operating procedures, so you're quickly working with waveforms.

  • Page 4: Introduction

    15.4” capacitive touch screen combined with the MAUI with OneTouch Analog Channels user interface results in an unsurpassed user experience. Equipped with a 40 GS/s sample rate and an extensive toolbox, the HDO9000 ensures Memory per Channel 64 Mpts/ch 4-channel operation 128 Mpts/ch 2-channel operation uncompromised performance when debugging in high definition.
  • Page 5 Measuring terminals are not intended to be connected directly to supply mains. Do not operate with suspected failures. Check body and cables regularly. If any part is damaged, cease operation immediately and sequester the instrument from inadvertent use. HDO9000 Getting Started Guide...

  • Page 6: Overview

    OVERVIEW Front of Oscilloscope A. Capacitive Touch Screen Display B. Front Panel C. Power On/Standby Button D. Input Channels 1-4 E. EXT In F. AUX Out G. USB 2.0 Port H. Mixed Signal Interface I. LBUS Port J. Cal Out and Ground Terminals K.

  • Page 7: Powering On/Off

    Cal out emits a signal that can be used to compensate passive probes. “Safety” for ratings. Press the Power button to turn on the oscilloscope. The HDO9000 oscilloscopes are compatible with the included passive probes button will light to show the oscilloscope is operational.

  • Page 8: Side Of Oscilloscope

    OVERVIEW Side of Oscilloscope A. HDMI 1.4 and DisplayPort 2.0 Ports B. USB 3.1 Gen 1 Ports (4) C. Ethernet Ports (2) D. Audio Mic and Speaker E. USBTMC Port (1) for remote control 930536-00 Rev A...

  • Page 9: Connecting To External Devices/Systems

    The Cal Out hook on the front can be set to output a direct current or square wave of custom amplitude and frequency. Use the Aux Output The HDO9000 is preset to accept a DHCP network address over a TCP/IP dialog to configure Cal Out.

  • Page 10: Back Of Oscilloscope

    OVERVIEW A. Built-in Carrying Handle B. Ref In and Ref Out to input/ output external Reference Clock C. AC Power Inlet D. Kensington Lock 930536-00 Rev A...

  • Page 11: Front Panel

    Most of the front panel controls duplicate functionality available through the touch screen display. They are covered in more detail in the Basics section and in the HDO9000 Oscilloscopes Operator’s Manual. Below are some special front panel controls. A. Auto Setup turns on and configures all channels with a signal attached.

  • Page 12: Touch Screen Display

    OVERVIEW Touch Screen Display The entire display is active. Use your finger to touch, drag-and-drop, swipe, pinch and flick. Many controls that display information also work as “buttons” to access other functions. If you have a mouse installed, you can click anywhere you can touch to activate a control; in fact, you can alternate between clicking and touching, whichever is convenient for you.
  • Page 13 Related Move the active trace to the next grid. dialogs appear as a series of tabs behind the main dialog. Apply a custom label to the trace. HDO9000 Getting Started Guide...

  • Page 14: Basics

    BASICS Changing the Display Q-Scape Multi-Tab Display If you have installed the Q-Scape option, the grid area can be divided into The grid is 8 Vertical divisions representing the full number of Vertical multiple tabs. Each tab can show a single grid or a multi-grid mode. levels (at current resolution) and 10 Horizontal time divisions.
  • Page 15 The front panel Intensity button sets the Adjust knob to control the trace intensity setting. Trace with Intensity 100% Oscilloscope with an extended display. Trace with Intensity 40%. HDO9000 Getting Started Guide...

  • Page 16: Working With Traces

    BASICS Working With Traces Trace Descriptor Boxes Adjusting Setups On setup dialogs, many entries can be made by selecting from the pop-up Channel (C1-C4), Zoom (Z1-Z12), Math (F1-F12), Memory (M1-M12) and menu that appears when you touch a control. Digital (Digital1-Digital4) descriptor boxes appear along the bottom of the grid area when a trace is turned on.

  • Page 17: Maui With Onetouch

    It is now To turn on the Measure table when it is closed, touch the Add New box the active trace. and choose Measurement. HDO9000 Getting Started Guide...
  • Page 18 BASICS Copy Setups Change Source To copy the setup of one trace to another of the same type (e.g., channel to To change the source of a trace, drag-and-drop the descriptor box of the channel, math to math), drag-and-drop the source descriptor box onto the desired source onto the target descriptor box.
  • Page 19 The cursors are set at either the 5 (center) or 2.5 and 7.5 divisions of descriptor box onto the Trigger descriptor box. The trigger will revert to the the grid. Cursors on the source traces adjust position accordingly. last trigger set on that channel. HDO9000 Getting Started Guide...
  • Page 20 BASICS Store to Memory Scroll To store a trace to internal memory, drag-and-drop its trace descriptor box To scroll long lists of values or readout tables, swipe the selection dialog or onto the target memory (Mn) descriptor box. table in an up or down direction. Move Trace To move a trace to a different grid, drag-and-drop the trace descriptor box onto the target grid.
  • Page 21 Zn descriptor box to open the zoom factor controls and adjust the zoom exactly. To "zoom in" on any trace, unpinch two fingers over the trace horizontally. To "zoom out" on any trace, pinch two fingers over the trace horizontally. HDO9000 Getting Started Guide...

  • Page 22: Vertical (Channel)

    BASICS Vertical (Channel) Vertical controls adjust traces along the Y axis. Traces represent eight Vertical divisions of the source signal at the selected number of units per division. The zero level is at the center grid line unless you add positive or negative Offset. The front panel Volts knob also controls the Vertical Scale of zoom, math and memory traces.
  • Page 23 Channel. Touch new Cn descriptor to open the Cn setup dialog. Enter Attenuation for passive and other vendors' probes. Enter Volts/div and Offset. Enter Coupling Apply optional Rescale channel Make any other for cables/probes. Bandwidth Filters. trace, or change Pre-Processing settings. Vertical Unit of grid. HDO9000 Getting Started Guide...

  • Page 24: Digital

    BASICS Digital On Mixed Signal models, digital selections are added to the Vertical menu, and the front panel Vertical knobs control active Digital line and bus traces. From the Front Panel Digital Descriptor Box # Digital Lines in Group Turn Offset to Digital Sample Rate raise/lower group Digital Memory...
  • Page 25 Select as you select lines. the state of each the group. and Group Height Custom to enter line: high, low, or in divisions. Optionally, enter unique names. transitioning. a custom line name in the field beneath. HDO9000 Getting Started Guide...

  • Page 26: Horizontal (Timebase)

    BASICS BASICS Horizontal (Timebase) Horizontal controls adjust traces along the X axis. Analog traces usually represent one acquisition of the source signal for 10 divisions of the selected Time per division. The trigger event is shown at the center of the grid, unless you add positive or negative Delay time. The front panel Time knob also controls the Horizontal Scale of zoom, math and memory traces, allowing you to "zoom in"...
  • Page 27 Lower number of Sampling (negative) time before trigger removes Delay. Rate or Maximum Points Active Channels to Mode. or (positive) time after trigger of memory to use in increase sample rate event to show. acquisition. and memory. HDO9000 Getting Started Guide...
  • Page 28 HD Mode The HDO9000 with HD1024 high definition technology offers more quantitization levels and greater precision when digitizing waveforms. HD1024 allows for dynamic ADC configuration based on the number of active channels and applies bandwidth filtering when the sample rate is reduced below 10 GS/s to prevent aliasing and increase resolution.

  • Page 29: Zoom

    Draw a Zoom box over a portion of the source trace. Repeat on another section to reposition the Zoom trace. The Zoom descriptor box shows the Zoom Source and Horizontal Scale, which differs from the Timebase. HDO9000 Getting Started Guide...

  • Page 30: Triggers

    Triggers tell the oscilloscope when to perform an acquisition. The acquisition starts as soon as the trigger is armed and all trigger conditions are met, unless postponed by a Holdoff count of time or number of trigger events. Trigger types and modes are described at more length in the HDO9000 Oscilloscopes Operator’s Manual.
  • Page 31 Trigger setup dialog. Source channel. Choose trigger Type. Set other conditions, Set trigger Level, Icon summarizes the such as Coupling and or Find Level based trigger selections. Slope (vary by on the input signal. trigger type). HDO9000 Getting Started Guide...

  • Page 32: Cursors

    Cursors set measurement points on the Vertical or Horizontal axis of a trace (or both). The five preset cursor types are described in more detail in the HDO9000 Oscilloscopes Operator’s Manual. All show the absolute value where the cursor intersects the waveform and the delta of the two lines.

  • Page 33: Measurements & Statistics

    Turn on Help Markers Enter Gates (in div) to constrain plot Histogram, Trend or to show what is being span of measurement, or just drag Track of measurement. measured on waveform. gate markers from edge of grid. HDO9000 Getting Started Guide...

  • Page 34: Math

    BASICS Math Math creates a new trace that displays the result of applying a mathematical function (e.g., Sum, Product, FFT) to one or more source traces. Operations can be chained by using one math function as a source for the other. The math trace always opens in a separate grid from the source and can be viewed along side it.

  • Page 35: Memories (Reference Waveforms)

    Choose Math > Memory Setup. On the Mn tab, select the trace you want stored in Copy From Waveform, then touch Copy Now. Optionally, add Notes or Labels to the stored memory. HDO9000 Getting Started Guide...

  • Page 36: Decode

    BASICS Decode The Decode front panel button opens the dialogs for configuring serial trigger and decode options. Decoders apply software algorithms to extract encoded information from physical layer waveforms measured on your oscilloscope. Waveforms are annotated to provide fast, intuitive understanding of the relationship between protocol and signal.

  • Page 37: Wavescan

    Choose scan Mode (event to find) and Source trace to scan. Select different views of the scan: event table Take action when an event is found, with/without time stamps, overlay or zoom. such as sounding a beep. HDO9000 Getting Started Guide...

  • Page 38: Spectrum Analyzer

    BASICS BASICS Spectrum Analyzer Use the Spectrum front panel button to launch Spectrum Analyzer, which lets you quickly and easily use the Fast Fourier Transform (FFT) for frequency analysis. The controls are the same as you would find on an RF spectrum analyzer. You set the inputs and desired frequency span, and the oscilloscope automatically generates output in units relevant to the frequency domain.

  • Page 39: History Mode

    Select row of History table to view that acquisition. Auto Play buttons and slider bar “replay” history View History table to find events of using absolute time interest. or relative time. HDO9000 Getting Started Guide...

  • Page 40: Saving And Sharing Data

    Saving and Sharing Data Setup, Waveform and Table Data Use the oscilloscope File menu options to save and recall data. See the HDO9000 Oscilloscopes Operator’s Manual for more information on using The current oscilloscope configuration can be saved to internal setup these features.

  • Page 41: Maintenance

    JITKIT (HDO9K-JITKIT) makes it easy to understand the basic system Many software options are available to extend the capabilities of a HDO9000. To purchase an option, contact your Teledyne LeCroy sales jitter performance of clock signals and clock-data activities through a representative.

  • Page 42: Cleaning

    We recommend that you run Calibrate All when: HDO9000 incorporates automatic calibration routines to maintain • The instrument is operating outside the 19-30 °C range and the accuracy in between factory calibrations.

  • Page 43: Firmware Updates

    MAINTENANCE Firmware Updates Switching Users Free firmware updates are available periodically from the Teledyne LeCroy Windows 10 oscilloscopes only. website at teledynelecroy.com/support/softwaredownload. Registered Windows 10 oscilloscopes are by default set to operate from the LeCroyUser users will receive email notification when a new update is released.

  • Page 44: Service

    Service Centers COD or Collect shipments. We recommend air freighting. Insure the item For a complete list of Teledyne LeCroy offices by country, including our you’re returning for at least the replacement cost. Follow these steps for a sales and distribution partners, visit: teledynelecroy.com/support/contact smooth product return.

  • Page 45: Support

    MERCHANTABILITY, FITNESS, OR ADEQUACY FOR ANY PARTICULAR PURPOSE OR Help for a demonstration of MAUI with OneTouch. USE. TELEDYNE LECROY SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER IN CONTRACT OR OTHERWISE. THE Teledyne LeCroy publishes a free Technical Library on its website at CUSTOMER IS RESPONSIBLE FOR THE TRANSPORTATION AND INSURANCE teledynelecroy.com/support/techlib.

  • Page 46: Certifications

    1 To ensure compliance with all applicable EMC standards, use high-quality shielded interface cables. 2 Emissions which exceed the levels required by this standard may occur when the instrument is Teledyne LeCroy certifies compliance to the following standards as of the time of publication. Please see the EC Declaration of Conformity connected to a test object.

  • Page 47: Safety Compliance

    The oscilloscope has been certified by Underwriters Laboratories (UL) to Intellectual Property conform to the following safety standard and bears the UL Listing Mark: All patents pertaining to the HDO9000 can be found on our website at: UL 61010-1 Third Edition – Safety standard for electrical measuring and teledynelecroy.com/patents/ test equipment.
  • Page 48 930536-00 Rev A January, 2019 © 2019 Teledyne LeCroy, Inc. All rights reserved.
