13.4 Burner Parts List

Item
1 Air pressure switch
2A Primary printed circuit board (5-18)
2B Primary printed circuit board (6-26)
2C Primary printed circuit board (9-36)
3 Burner fan and motor
N/A Air restriction plate (5-18kW only)
4 Servo motor (for brazier)
5
6 LED display support
7 Electrical connector (7-way female) - burner plug No. 2
8 Electrical connector (7-way male) - burner plug No. 2
9
10 Ignition element (no housing)
11 Pellet feed tube thermostat
12 Pellet feed tube thermostat cover
Pellet feed tube (one piece)
13
Pellet feed tube (two piece)
N/A Pellet feed (flexi) tube
14 Pellet feed tube gasket
15 Burner fan gasket
16 Ignition element housing (housing only)
17
18 Electrical connector (6-way male) - burner plug No. 3
19
20A Brazier - bottom (5-18 and 6-26 kW)
20B Brazier - bottom (9-36kW)
21A Brazier - angle plate (5-18 and 6-26 kW)
21B Brazier - angle plate (9-36kW)
22A Burner hood (5-18 and 6-26kW)
22B Burner hood (9-36kW)
23 Ignition element mounting plate
24 Boiler water thermistor
25 Burner back plate and base
26
27 Special - contact Grant UK
28 Special - contact Grant UK
29 Cleaning mechanism spring
30 Special - contact Grant UK
31 Special - contact Grant UK
32 Back plate for photocell
33 Special - contact Grant UK
N/A Brazier measuring tool
Description
LED display unit
Photocell
Photocell tube
Brazier - chassis
Burner cover
Product code Qty - 5-18kW
WPS111 1
WPS112C 1
WPS112 -
WPS112B -
WPS03 1
WPS178 1
WPS04X 1
WPS05 1
WPS06 1
WPS07 1
WPS08 1
WPS09 1
WPS10A 1
WPS11 1
WPS12 1
WPS174 1
WPS174A 1
WPS13 1
WPS14 1
WPS24 1
WPS10B 1
WPS17 1
WPS18 1
WPS19 1
WPS33A 1
WPS33B -
WPS32A 1
WPS32B -
WPS29X 1
WPS29Y -
WPS22 1
WPS25 1
WPS27 1
WPS28 1
N/A 1
N/A 1
WPS82 1
N/A 1
N/A 1
WPS23 1
N/A 1
WPS199 1
Qty - 6-26kW Qty - 9-36kW
1 1
- -
1 -
- 1
1 1
- -
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 -
- 1
1 -
- 1
1 -
- 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
