Heat Recovery DC Inverter Multi VRF Unit

2 Product Introduction

Gree Modular Heat Recovery Multi VRF System adopts inverter compressor technology. By
changing the displacement of compressor, stepless capacity regulation can be realized . Various
product lineups are provided with capacity range from 22.4kW to 180kW, and indoor units within a
same system can operate in cooling or heating mode in the meantime. This system can be widely
used in commercial and working area and is especially applicable to places with big load change.
Gree commercial multi VRF system is absolutely your best choice.

2.1 Names of Main Parts

①
No,
Name Fan motor, motor

2.2 Combinations of Outdoor Units

2.2.2 GMV5 HR DC Inverter Heat Recovery Multi VRF Units
Model
GMV-Q504WM/B-X
(Combined)
GMV-Q224WM/B-X
Model (Single)
+ GMV-Q280WM/B-X
Model
GMV-Q730WM/B-X
(Combined)
GMV-Q280WM/B-X
Model (Single)
+ GMV-Q450WM/B-X
Figure 1
②
Electric box
Valve interface
assembly
GMV-Q560WM/B-X
GMV-Q280WM/B-X
+ GMV-Q280WM/B-X
GMV-Q785WM/B-X
GMV-Q335WM/B-X
+ GMV-Q450WM/B-X
3
③ ④
Power cord
through-hole
GMV-Q615WM/B-X
GMV-Q280WM/B-X
+ GMV-Q335WM/B-X
GMV-Q850WM/B-X
GMV-Q400WM/B-X
+ GMV-Q450WM/B-X
⑤
Communication wire
through-hole
GMV-Q680WM/B-X
GMV-Q280WM/B-X
+ GMV-Q400WM/B-X
GMV-Q900WM/B-X
GMV-Q450WM/B-X
+ GMV-Q450WM/B-X
