T
ECHNICAL INFORMATION
Model No.
Description
C
ONCEPT AND MAIN APPLICATIONS
Model BDF441 has been developed as an upgraded sister model of Model 6339D
with the design concept of "More Control and Maneuverability".
Features lightweight and compact design achieved by using 4-pole motor and
Lithium-ion battery as power unit.
Also features the same advantages as BDF440:
Rubberized soft grip contoured to perfectly fit operator hand and angled
to provide best tool balance
All metal gear construction
Job light with afterglow function
Single sleeve chuck
This new product will be available in the following variations.
Model No.
BDF441
BDF441SFE
(Li-ion 3.0Ah)
BDF441SFE3
S
pecification
Voltage: V
Battery
Capacity: Ah
Cell
Max output (W)
No load speed:
min-
=rpm
1
Capacity of drill chuck: mm (")
Capacity: mm (")
Torque setting
Max. clutch torque: N.m (ft.lbs)
Max. fastening
torque: N.m (ft.lbs)
Electric brake
Variable speed control
Reversing switch
Net weight*: kg (lbs)
*Includes battery BL1430
S
tandard equipment
Philips bit 2-45 ....... 2 pc
Bit holder................ 1 pc
Note: The standard equipment for the tool shown above may differ by country.
O
ptional accessories
Charger DC14SA
Charger DC14SC
BDF441
Cordless Driver Drill 13mm (1/2")
Battery
type
quantity
2
BL1430
2
DC18SC (Low voltage areas)
DC14SC (High voltage areas)
3
1st/ 2nd/ 3rd
0 - 300/ 0 - 600/ 0 - 1,700
1.5 - 13 (1/16 - 1/2)
Steel
Wood
16 stage + drill mode
1.0 - 5.9 (0.7 - 4.3)
Soft joint
Hard joint
Belt clip................... 1 pc
Grip assembly.......... 1 pc
Charger DC18SC
Charger DC24SA
Charger
DC18SC
14.4
3.0
Li-ion
265
13 (1/2)
50 (2)
32 (23.6)
70 (51.6)
Yes
Yes
Yes
2.0 (4.4)
+ Screw M4x12 .............. 2 pc
Plastic carrying case ..... 1 pc
Charger DC24SC
Li-ion battery BL1430
W
Dimensions: mm (")
Length (L)
Width (W)
Height (H)
Offered to
USA, Canada
Mexico, Panama
All countries except
those listed above
Assorted drill bits for wood
Assorted drill bits for metal
PRODUCT
P 1 / 7
L
H
238 (9-3/8)
78 (3-1/16)
255 (10)
