Data sheet
Actuator for modulating control
AME 55QM
Description
Ordering
Technical data
© Danfoss | 2016.09
Type
Supply voltage
AME 55 QM
24 V~
Power supply
Power consumption
Frequency
Control input Y
Output signal X
Close of force
Max. stroke
Speed
Max. medium temperature
Ambient temperature
Storage and transport temp.
Ambient humidity
Protection class
Degree of protection
Weight
- marking in accordance with standards
Actuator is used with pressure independent
balancing and control large valve type AB-QM
DN 125 and DN 150.
Features:
• "Self stroking" function
• Load related "Switch off" function that
prevents overloading
• Diagnostic LED
Main data:
• Nominal voltage: 24 VAC, 50 Hz/60 Hz
• Control input signal:
- 0(4)-20 mA
- 0(2)-10 V
• Force: 2000 N
• Stroke: 40 mm
• Speed: 8 s/mm
• Max. medium temperature: 200 °C
• Manual operation
Code No.
082H3078
V
VA
Hz
V
mA
V
N
mm
s/mm
°C
kg
Low Voltage Directive 73/23/EEC
EMC-Directive 2006/95/EEC, EN 60730-1, EN 60730-2-14
24~; +10 to – 15%
9
50 / 60
0 – 10 (2 – 10) Ri = 24 kΩ
0 – 20 (4 – 20) Ri = 500 Ω
0 – 10 (2 – 10)
2000
40
8
200
0 – 55
–40 to +70
95% r.h., non-condensing
III safety extra-low voltage
IP 54
3.8
VD.CV.A2.02 | 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Danfoss AME 55QM
Summary of Contents for Danfoss AME 55QM
- Page 1 Ambient humidity 95% r.h., non-condensing Protection class III safety extra-low voltage Degree of protection IP 54 Weight Low Voltage Directive 73/23/EEC - marking in accordance with standards EMC-Directive 2006/95/EEC, EN 60730-1, EN 60730-2-14 © Danfoss | 2016.09 VD.CV.A2.02 | 1...
- Page 2 Subsequently, the self stroking feature can be re-initialised by changing position of SW9. Wiring for modulating control Wiring for 3-point control Note: If switch SW6 is set to ON than use this wiring. VD.CV.A2.02 2 | © Danfoss | 2016.09...
- Page 3 • Ensure that the actuator drives the valve over its full stroke, by applying the appropriate control signal. This action will set the valve stroke length. The unit is now fully commissioned. VD.CV.A2.02 © Danfoss | 2016.09 | 3...
- Page 4 AME 55 QM + AB-QM DN 150 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequential changes being necessary eady agreed.
