Instruction Manual
RS-989
Stock No: 161-1624
Heavy Duty True RMS Digital Multimeter
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-989 and is the answer not in the manual?

Questions and answers

Related Manuals for RS PRO RS-989

Summary of Contents for RS PRO RS-989

  • Page 1 134 Godocho, Hodogaya, Instruction Manual Kyalami Business Park, Yokohama, Kanagawa 240-0005 Kyalami, Midrand Japan South Africa www.rs-components.com RS-989 www.rs-components.com U.S.A Stock No: 161-1624 Asia Allied Electronics RS Components Ltd. 7151 Jack Newell Blvd. S. Heavy Duty True RMS Digital Multimeter...
  • Page 2 Heavy Duty True RMS Digital Multimeter/English 1. Introduction Professional True RMS Industrial Digital Multimeter and TFT color LCD display, providing fast A/D converting sampling time, high accuracy , built-in datalogging and Trend Capture feactures. It can trace any interrupted problems of the equipments and watch on without person.

  • Page 3: Overvoltage Category

    Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 3. Safety Instructions This symbol indicates that a device is protected throughout by double insulation or reinforced insulation. This meter has been designed for safe use, but must be operated with caution. The rules listed below must be carefully followed for safe operation.
  • Page 4 Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 4. Feature 4-2. Understanding the Display 4-1. Understanding the Push Buttons GRAPH MODE SAVE The 6 push buttons on the front of the Meter activate features that augment the function selected using the rotary switch, navigate menus HOLD RANGE...

  • Page 5: Measure Function

    Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 5. Measure Function otar Select a primary measurement function by positioning the rotary switch to one 5-1. AC Voltage Measurements of the icons around its perimeter. For each function, the Meter presents a standard WARNING: Risk of Electrocution.
  • Page 6 Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 5-2. DC Voltage Measurements 5-4. mV Voltage Measurements CAUTION: Do not measure DC voltages if a motor on the circuit is being CAUTION: Do not measure mV voltages if a motor on the circuit is being switched ON or OFF.
  • Page 7 Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English - . Continuity Check 1.Set the function switch to the green position. WARNING: To avoid electric shock, disconnect power to the unit under test 2.Insert the black test lead banana plug into the and discharge all capacitors before taking any resistance negative COM jack.
  • Page 8 Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 5-11. DC Current Measurements WARNING: To avoid electric shock, disconnect power to the unit under test CAUTION: Do not make 20A current measurements for longer than 30 and discharge all capacitors before taking any capacitance seconds.

  • Page 9: Default Display

    Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 6. Default Display 5-12. AC Current Measurements CAUTION: Do not make 10A current measurements for longer than 30 seconds. Auto range 06:32pm Exceeding 30 seconds may cause damage to the meter and/or the test leads. 1.Insert the black test lead banana plug into the 0 0 0 0 negative COM jack.
  • Page 10 Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 6-3. Capturing Peak Values Press SAVE soft key to save Graph. Press Auto range Auto range 06:32pm 08 :12 pm To activate the peak mode, at AC measure BACK soft key to return.
  • Page 11 Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English Press the << and >> soft keys to move unction 06:32pm ViewGrap 06/02/14 cursor Then pressing the labeled , into save menu. Rate: 0.2 s Ω Range: 50M For common measurement functions, a snapshot of the screen data is saved by Press the softkey labeled .

  • Page 12: Setup Options

    Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 7-2. Meter Info Press the + soft key to increase Graph Auto range 08:27pm The Meter Info selection lists the serial number, firmware version, are displayed. resolution. Press the >> soft keys to move 06/02/14 08:26:09pm Open the setup menu.
  • Page 13 Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 7-6. Auto Power Off 7- . 10 Replacing the Batteries Open the setup menu. Position the menu selector next to the menu item labeled Refer to Figure and replace the batteries as follows: Display and press the key Enter.
  • Page 14 Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 7-12 Li-ion Battery Charge AC True RMS The term stands for “Root-Mean-Square,” which represents the method of calculation of the voltage 2.Insert the socket into the Meter Input port. And the Adapter connected to the switch or current value.

  • Page 15: Specifications

    Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English 8. Specifications Function Range Resolution Accuracy Temp -200 to 1350˚C 0.1˚C ±(1.0% reading + 3.0°C) Range Resolution (type-K) ±(1.0% reading +5.4°F) oltage (probe accuracy not included) 1. Does not include error of the thermocouple probe. 2.
  • Page 16 Heavy Duty True RMS Digital Multimeter/English Heavy Duty True RMS Digital Multimeter/English Function Range Resolution Accuracy Frequency 50Hz 0.001Hz ±(0.01% + 5) (electronic) 500Hz 0.01Hz ±(0.01% + 5) 5kHz ±(0.01% + 5) 0.0001kHz 50kHz 0.001kHz ±(0.01% + 5) 500kHz 0.01kHz ±(0.01% + 5) 5MHz 0.0001MHz...
