- Page 1 SKYLINE EASY-LINK ASSEMBLY MANUAL June 2019...
-
Page 2: Table Of Contents
Information is supplied upon the condition that the persons receiving the information will make their own determination as to its suitability for their purposes prior to use. Rollease Acmeda assumes no liability whatsoever for any damages incurred by you resulting from errors in or omissions from the information included herein. -
Page 3: Section 1 − Tools And Additional Items Required
• Scissors • Measuring Tape • Pencil ADDITIONAL ITEMS REQUIRED (NOT SUPPLIED) To assemble a SKYLINE EASY-LINK, the following non-stocked items are required: • Fabric SKYLINE EASY-LINK Assembly Manual | June 2019 Page 1.1 Copyright © 2019 Rollease Acmeda Group. -
Page 4: Section 2 − System Details
LINK SKYLINE EASY- | DUAL CONTROL The Rollease Acmeda Skyline Easy-Link™ system combined with the Pin to Pin Disk allows for multiple controls to be used on a single installation allowing for maximum user customisation. SYSTEM INDEX Skyline Pin End... -
Page 5: Part B - Deductions
Medium Link Bracket Disk Pin to Pin Piece RB41-1001-XXX038 Medium Easy-Link Intermediate Male Drive DRIVES RB41-1002-XXX038 Medium Easy-Link Intermediate Female Drive NOTE: = number of Skyline Easy-Link Brackets required for installation SKYLINE EASY-LINK Assembly Manual | June 2019 Page 2.2 Copyright © 2019 Rollease Acmeda Group. -
Page 6: Section 3 Assembly
SECTION 3 ASSEMBLY PART A – ASSEMBLING TUBE STEP 1 – INSERT INTERMEDIATE MALE SKYLINE EASY-LINK DRIVE INTO BLIND “A” NOTE: THE FINS ON ALL DRIVE UNITS SHOULD BE ALIGNED OUTSIDE THE FINS IN THE TUBE SKYLINE EASY-LINK Assembly Manual | June 2019 Page 3.3... - Page 7 STEP 2 – INSERT INTERMEDIATE FEMALE SKYLINE EASY-LINK DRIVE INTO BLIND “B” STEP 3 – INSERT INTERMEDIATE MALE & FEMALE SKYLINE EASY-LINK DRIVES INTO BLIND “X” (WHEN USING 3+ BLINDS) MALE FEMALE CONTROL END IDLER END NOTE: Repeat step 3 for each Blind “X” being used SKYLINE EASY-LINK Assembly Manual | June 2019 Page 3.4...
-
Page 8: Part B - Prepare & Pack Assemblies Ready For Transportation & Installation
3. Medium Link Bracket Disk Pin to Pin 4. Medium Easy-Link Bracket Disk + Bearing 5. Blind “A” (Left Control) 6. Blind “B” (Right Control) 7. Blind “X” (Linking Blind) SKYLINE EASY-LINK Assembly Manual | June 2019 Page 3.5 Copyright © 2019 Rollease Acmeda Group.
