V
is ta
MOTORIZED SHADES
Automate
Rechargeable Motorization
Programming Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Automate Rechargeable Motorization and is the answer not in the manual?

Questions and answers

Summary of Contents for rollease acmeda Automate Rechargeable Motorization

  • Page 1 is ta MOTORIZED SHADES Automate Rechargeable Motorization ™ Programming Instructions...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Motor Configuration Options ......................3-4 Initial Set Up ............................4-5 Locking/Unlocking A Remote ........................ 5 Operation............................... 6 Link/Unlink A Remote or Switch ......................7 Adjusting/Setting Limits ........................8 Favorite Position ............................. 9 Adjusting Motor Speeds ........................10 Hide Unused Channels ........................10 Q3.0 &...
  • Page 3: Motor Configuration Options

    MOTOR CONFIGURATION OPTIONS P1 BUTTON FUNCTION The P1 button serves many purposes throughout programming. Understanding all of its functions is key to setting up a shade for use. hORT ReSS Pressing the P1 button has different outcomes depending on the state of the motor.
  • Page 4: Initial Set Up

    REVERSE DIRECTION • Hold the P1 button until the shade jogs a third time (approx. 10 seconds), then release. The shade will beep 3 times, confirming you’ve reversed the direction of the roll. • Use this only if the shade is moving in the opposite direction of the button you press. RESET THE FACTORY SETTINGS •...
  • Page 5: Locking/Unlocking A Remote

    2. If shade is moving in correct direction proceed to next section, SET LIMITS. If shade is moving in wrong direction, hold the UP and DOWN buttons at the same time (approx. 2 seconds.) The shade will jog once, this confirms the direction has been reversed.
  • Page 6: Operation

    OPERATION SINGLE CHANNEL REMOTE Use the UP and DOWN buttons to raise and lower the shade STOP Use the STOP buttons to stop the shade anywhere along the travel. Down Hold the STOP button for approx. 2 seconds to move the shade to the saved “Favorite” position. 15 CHANNEL REMOTE To select which channel to operate, hold the CHANNEL button.
  • Page 7: Link/Unlink A Remote Or Switch

    LINK/UNLINK REMOTE OR SWITCH INGLe hANNeL WITCh 15 C hANNeL emOTe Channels 1 thru 5 STOP Down Stop Up and Down Channel LINK REMOTE, CHANNEL, OR SWITCH When using the 15 channel remote or wall switch, multiple motors can be grouped onto channels for coordinated control.
  • Page 8: Adjusting/Setting Limits

    ADJUSTING LIMITS The upper and lower limits can be adjusted without having to factory reset the entire shade. NOTE: Adjusting the limits can only be done with a single channel or 15 channel remote. They cannot be adjusted with the wall switch. If using a 15 channel remote, select the channel for the shade that needs to be adjusted.
  • Page 9: Favorite Position

    FAVORITE POSITION If using a 15 channel remote or wall switch; if the desired shade shares a channel with other shades, it is recommended that it be moved to a new channel to program a Favorite position. Follow the steps in the LINK REMOTE, CHANNEL, OR SWITCH, on page 7, to link the shade to a new channel.
  • Page 10: Adjusting Motor Speeds

    ADVANCED PROGRAMMING ADJUSTING MOTOR SPEED The speed at which the shade moves can be increased or decreased. If the motor does not react to the speed adjustment, the maximum or minimum speed has already been reached. NOTE: Adjusting motor speed can only be done with a single channel or 15 channel remote. It cannot be adjusted/set with the wall switch.
