Quick Start Guide
BX8 + 6-Axis Sensor and BlueDAQ Software
CAUTION: Please read this entire guide before making any connections or first powering on the
system.
INTRODUCTION
The model BX8 amplifier and 6-Axis sensor comprise a stand-alone measurement system with
analog outputs of +/-10V on each of the 6 axis. When purchased as a system the BX8 is fully
configured and no further setup is required by the customer. The 6-Axis coefficient matrix is factory
installed in the BX8.
USE CASE 1: The BX8 analog outputs will be connected to the customer's data acquisition
system. Interface BlueDAQ software will not be used. SEE PAGE 3
USE CASE 2: BX8 will be used with Interface BlueDAQ software for viewing, graphing and logging
data. SEE PAGE 5
USE CASE 3: BX8 will be simultaneously connected to customer's data acquisition system and to
the Interface BlueDAQ software. SEE BOTTOM OF PAGE 14
15-233 Rev D 11/17/2016
Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924
● Email:
● ORDER TOLL-FREE 800.947.5598
www.interfaceforce.com
contact@interfaceforce.com
Page 1 of 14

Advertisement

loading

Related Manuals for Interface BX8

Summary of Contents for Interface BX8

  • Page 1 The model BX8 amplifier and 6-Axis sensor comprise a stand-alone measurement system with analog outputs of +/-10V on each of the 6 axis. When purchased as a system the BX8 is fully configured and no further setup is required by the customer. The 6-Axis coefficient matrix is factory installed in the BX8.
  • Page 2 There are two capped feedthroughs on the side of the BX8-AS enclosure labeled Output 1 and 2. Either or both of these holes can be used to feed the signal cable out of the BX8 enclosure. Remove either one or both caps and replace with a supplied large cable gland.
  • Page 3 Potentiometric sensors can be supplied via +Us. The power supply for active sensors can be via galvanic isolated voltage VCCIO and GNDIO. Analog Output SUB-D25 Socket Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 ● Email: ● ORDER TOLL-FREE 800.947.5598 www.interfaceforce.com...
  • Page 4 60kHz frequency -6V Out OutB+ 60kHz frequency +6V Out GNDINT GNDINT Shield Earth (housing) Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 ● Email: ● ORDER TOLL-FREE 800.947.5598 www.interfaceforce.com contact@interfaceforce.com Page 4 of 14...

  • Page 5: Default Settings

    BX8 will be used with Interface BlueDAQ software for viewing, graphing and logging data. The Analog Outputs will NOT be used. Before connecting the BX8 to the PC you must first install the BX8 drivers by running setupBX8driver.exe and then install the Interface BlueDAQ software. These are supplied on a USB Flash Drive along with user manuals and copies of the sensor calibration files and certificates.
  • Page 6 UN-CHECK “Disable Windows Fast Startup…” There are currently no known issues with the BX8 hardware and Windows Fast Startup. Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 ● Email: ● ORDER TOLL-FREE 800.947.5598 www.interfaceforce.com...
  • Page 7 Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 ● Email: ● ORDER TOLL-FREE 800.947.5598 www.interfaceforce.com contact@interfaceforce.com Page 7 of 14...
  • Page 8 5. Connect the supplied power cable to the BX8 amplifier 4-pin DC power jack. 6. Connect the supplied USB cable to the BX8 and the PC. The PC will recognize and install the BX8 as a COM Port. You should check in windows device manager to make sure the BX8 was installed correctly.
  • Page 9 Update Driver Software Select Browse my computer for driver software, browse to C:\BX8driver\inf and click Next Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 ● Email: ● ORDER TOLL-FREE 800.947.5598 www.interfaceforce.com...
  • Page 10 7. Now run BlueDAQ from the Start/Programs Menu Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 ● Email: ● ORDER TOLL-FREE 800.947.5598 www.interfaceforce.com contact@interfaceforce.com Page 10 of 14...
  • Page 11 COM as noted during the BX8 driver installation. When finished click Connect and all 6 channels will be added. Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 ● Email: ● ORDER TOLL-FREE 800.947.5598 www.interfaceforce.com...
  • Page 12 9. Next, click the Special Sensor button to load the pre-assigned channel names. For example, Chan 7_1 will be renamed to ForceX. 10. Select Multidimensional Sensor and click OK Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 ● Email: ● ORDER TOLL-FREE 800.947.5598 www.interfaceforce.com...
  • Page 13 PC. Next time you open the software just select Open Session, select the file and all of the channels and channel names will be added automatically. Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 ● Email: ●...
  • Page 14 BX8 while the analog output signals are actively connected to an external data acquisition system. Data can be viewed, logged and recorded simultaneously Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924 ● Email: ●...
