Thuraya ATLAS IP and ATLAS IP+ Satellite Terminals
Atlas IP+ terminal encompasses all the features of Atlas IP terminal with an additional phone port on the
Below Deck Unit in carrying out VoIP phone call and data connection simultaneously. There is no change on
the antenna unit. The following guided content is illustrated using the Atlas IP terminal and Atlas IP+
terminal, with the additional phone port.
Antenna Unit
Modem Unit-Connectivity Ports and Buttons
Status Indicators
Antenna Connector (TNC)
Wi-Fi Antenna Connector (SMA)
I/O Port
RS-232 Serial Port
Alert Button
ON/OFF Power Switch
*Only for ALTAS IP+
Thuraya Atlas IP and Atlas IP+
Radome Top
Radome Bottom
Antenna Connector (N-Type)
LAN Ports 1, 2, 3 (RJ45)
PoE Port (RJ45)
Primary Handset Port
*Phone Port (RJ11)
SIM Card Slot
Circuit Breaker Reset
DC Input
Grounding Stud
Advertisement
Related Manuals for Thuraya ATLAS IP
Summary of Contents for Thuraya ATLAS IP
- Page 1 Thuraya ATLAS IP and ATLAS IP+ Satellite Terminals Atlas IP+ terminal encompasses all the features of Atlas IP terminal with an additional phone port on the Below Deck Unit in carrying out VoIP phone call and data connection simultaneously. There is no change on the antenna unit.
- Page 2 Thuraya Atlas IP and Atlas IP+ Above Deck Unit (ADU) Installation 1. Connect the antenna cable to ADU properly 2. Secure ADU to the pole mount or the mast by without kinking it. Ensure that there is a rubber using M6 x 25mm screws and the flat washers.
- Page 3 Terminal Simplified Block Diagram on page 2. 1. On the Web Console, select Settings > Admin 2. Insert a Thuraya SIM card, with the gold printed circuit > System Operation Mode, click “Voice” and facing down and switch on the terminal.
- Page 4 Thuraya Atlas IP and Atlas IP+ Accessing Web Console Open the web browser. Type http://192.168.2.1 in the Address field. 2. Type admin in Username field and admin in Password field. Click Login. The terminal will register to the network, and The satellite signal bar and the details of the achieve GPS acquisition and satellite region.
