www.selectronix.us
SLC4075 TouchScreen Gateway Installation & Operating Manual
___________________________________________________________________________________________________
SLC4060 Relays
a.
Source Selector defines the signal which activates the relay
a.
0 = Disabled
b.
1 = GPDIx, the corresponding GPDIx operates the relay.
c.
2 = GPDIx and GPDI4 the corresponding GPDIx And'ed with GPDI4 operates the relay.
d.
3 = GPDIx and GPDI4 the corresponding GPDIx Or'ed with GPDI4 operates the relay.
e.
4 = DDC, Building Management System operates
f.
5 = SLC4000 Fault
g.
6 = PGW & Cmd=0 Fault
h.
7 = TSGW Fault
i.
8 = Combines #2 and #6 above
j.
9 = Combines #3 and #6 above
b.
Relay Invert Mask is used to invert the logical source signal to operate the relay.
a.
Note that an inverted relay reverts to normally open on AC power loss.
Expansion Relays
a.
8 additional relays may be added by using a standard SLC4000 with the "Dedicated Test" position selected, (SW2-
1 Off). This sets an SLCnet pre-determined address and "Expansion Relay mode" operation. The dedicated test
functions for 'Test Up' and 'Test Dn' remain, as does the Status indication.
b.
Source Selector defines the signal which activates the relay according to the following table:
SrcSel
XRly1
0
Disabled Disabled Disabled Disabled Disabled Disabled
1
XDIx
2
XDIx
3
XDIx
4
BMS
SLC4060 Voltage Driver
a.
Source Select defines the signal that is sent to the voltage driver
a.
0 = Disabled
b.
1 = RTD1
c.
2 = RTD2
d.
3 = GPA1
e.
4 = GPA2
f.
5 = PID1 0-10 V dc
g.
6 = PID1 2-10 V dc
h.
7 = PID2 0-10 V dc
i.
8 = PID2 2-10 V dc
j.
9 = BMS
SLC4060 Information
a.
PGW Firmware Version:
b.
Remote Enable Code:
a.
90 is the default enable code
b.
0 is the default disable code
c.
PGW Step Cmd % is the step command originating from either PID1, PID2, or a PGW BMI.
d.
PGW Ld Lmt % originating from a PGW BMI.
e.
PGW On Dly Sec originating from a PGW BMI I
f.
PGW Fault
g.
MSTP Addr is the setting of the MSTP address by DIP switch SW2.
Selectronix, Inc.
XRly 2
XRly 3
XRly 4
XDIx
XDIx
XDIx
XDIx
XDIx
XDIx
XDIx
XDIx
XDIx
BMS
BMS
BMS
XRly 5
XRly 6
XDIx
XDIx
PGW
TSGW
Flt
Flt
BMS
BMS
BMS
BMS
18
(425) 788-2979
XRly 7
XRly 8
Disabled Disabled
XDIx
XDIx
S4K Flt
Rsv Flt
BMS
BMS
BMS
BMS
