- Page 1 ELECTRONIX, WOODINVILLE, WA SUPERSTEP SERIES 4000 SLC4075 Touch Screen GATEWAY Startup Configuration Modification Guide Models: SLC4075-4 4” Screen Models: SLC4075-7 7” Screen TSGW_ Startup Configuration Modification Guide Rev 10/12/17...
- Page 2 Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Startup Configuration Modification Guide ___________________________________________________________________________________________________...
-
Page 3: Table Of Contents
Support; Software & Firmware; Red Lion Software; Crimson; Crimson 3.0 Crimson database obtained from the boiler manufacturer or Selectronix tech support. PC to upload modified database to the TSGW. Detailed Instructions Open Crimson 3 software and load the original Crimson database. -
Page 4: Pid1
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Startup Configuration Modification Guide ___________________________________________________________________________________________________ PID1 This block sets the following: PGW.PID1.g_fUnmodSetptDeg = PGW.PID1.UNMOD_SETPT_DEFVAL; Sets the default set point in degrees. It is commented out for field modification PGW.PID1.g_fSetModeSel = PGW.PID.PID_MODE_EN_NON_INV_BMS; // Heat mode Sets the PID mode and would not normally be changed in the field PGW.PID1.g_fSetEngrUnits... -
Page 5: Spm2
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Startup Configuration Modification Guide ___________________________________________________________________________________________________ SPM2 Sets the Set Point Modifier 2 parameters Sets the SPM source selection. Uncomment the line that sets the desired mode PGW.SPM2.g_fSetSPMSrcSel = PGW.SPM.SPMSRC_DIS; PGW.SPM2.g_fSetSPMSrcSel = PGW.SPM.SPMSRC_RTD2_DEGF;... -
Page 6: Xdi
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Startup Configuration Modification Guide ___________________________________________________________________________________________________ State 3 High Limit State 4 Status State 5 Boiler #n Lockout (n is GDPI number) If the GPDI is assigned to operate the Relays, those labels need to be changed, as well. -
Page 7: Pgw Relays
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Startup Configuration Modification Guide ___________________________________________________________________________________________________ PGW Relays // Src Sel Sets the source for PGW relays 1-3 PGW.Rly.g_fSetPGWRlysSrcSel[0] = PGW.Rly.RLYSRCSEL_GPDI; PGW.Rly.g_fSetPGWRlysSrcSel[1] = PGW.Rly.RLYSRCSEL_GPDI; PGW.Rly.g_fSetPGWRlysSrcSel[2] = PGW.Rly.RLYSRCSEL_GPDI; Other Rly sources are: PGW.Rly.RLYSRCSEL_DISABLED PGW.Rly.RLYSRCSEL_BMS Relay is controlled by BMS PGW.Rly.RLYSRCSEL_CLL... -
Page 8: Xrlys
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Startup Configuration Modification Guide ___________________________________________________________________________________________________ XRlys // Src Sel selects the pre-defined definition for all rlys XRly.g_iSrcSel=XRly.SRCSEL_XDI_1; Sets the src to operate the like-numbered relay Other source choices are: SRCSEL_DIS_0 i. All XRlys are disabled SRCSEL_XDIFLT_2 i. -
Page 9: Voltage Driver
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Startup Configuration Modification Guide ___________________________________________________________________________________________________ Voltage Driver // ------------------------------VltDrvr--------------------------------- Sets the source for the voltage driver output PGW.VltDrvr.g_fSetVltDrvrSel = PGW.VltDrvr.VLTDRVR_PID1_0_10; This sets the output to PID1 percent using 0 to 10 volt.
