www.selectronix.us
SLC4075 TouchScreen Gateway Installation & Operating Manual
___________________________________________________________________________________________________
SLC4060 PID 1
a.
Mode Select
a.
1 = Heat Mode DDC
b.
2 = Cool Mode DDC
c.
3 = Heat Mode AUX available for monitoring or optional Voltage Driver
d.
4 = Cool Mode AUX available for monitoring or optional Voltage Driver
b.
Process Var:
c.
Setpt:
d.
Units:
a.
0 = Deg F
b.
1 = Deg C
e.
Process Variable: Displays in the selected units
f.
SPM Select selects the Setpt Modifier Mode
a.
0 = Disabled
b.
1 = RTD2 Deg F
c.
2 = RTD2 Deg C
d.
3 = GPA2 % Span
e.
4 = GPA2 PSI
g.
Setpt Cnts:
h.
Preset:
a.
0 = Slow
b.
1 = Medium
c.
2 = Fast
See "SLC4060InstallationAndOperatingManual" available at
calculations and tuning tips.
SLC4060 Setpoint Modifier 1 (SPM1) – Outdoor Air Reset
a.
SPM Select:
a.
0 = Disabled
b.
1 = RTD2 Deg F
c.
2 = RTD2 Deg C
d.
3 = GPA2 % Span
e.
4 = GPA2 PSI
b.
Setpt:
Setpoint after SPM1 applied
c.
Preset:
a.
0 = TBD
b.
1 = TBD
c.
2 = TBD
d.
Lo Mod Deg is the amount to modify the setpoint at the X axis Lo point
e.
X Axis Lo is the low temperature corresponding to the Lo Mod Deg
f.
High Mod Deg is the amount to modify the setpoint at the X axis Hi point
g.
X Axis Hi is the high temperature corresponding to the Hi Mod Deg
Selectronix, Inc.
Displays the process variable sensor
Displays the set point
Set point in internal ADC counts
www.selectronix.us
for more details and an example of PID
12
(425) 788-2979
