- Page 1 ELECTRONIX, WOODINVILLE, WA SUPERSTEP SERIES 4000 SLC4075 Touch Screen GATEWAY INSTALLATION & OPERATING MANUAL Models: SLC4075-4 4” Screen Models: SLC4075-7 7” Screen Models: SLC4075-10 10” Screen DOC:SLC4075InstallationAndOperatingManual.DOC REV 02/15/19...
- Page 2 Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________...
-
Page 3: Table Of Contents
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ TABLE OF CONTENTS GENERAL INFORMATION............................. 6 ................................6 NTRODUCTION WARNINGS AND ADVISORIES ..........................7 RED LION KADET & CR1000 HMI DETAILED INFORMATION............8 UNIT CONFIGURATION ..........................9 CONFIGURATION USING SD CARD ........................ - Page 4 Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________...
-
Page 5: List Of Tables
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ LIST OF TABLES TABLE 1 SLC4075 ERROR INDICATIONS ....................21 TABLE 2 BUILDING MANAGEMENT INTERFACE –MOST COMMONLY USED BACNET AND MODBUS ADDRESSES .............................. 22 TABLE 3 BUILDING MANAGEMENT INTERFACE –BACNET AND MODBUS CONFIGURATION ADDRESSES .................................. -
Page 6: General Information
GENERAL INFORMATION Introduction load limit, for both the Auxiliary and the BMS control. A The SELECTRONIX, INC. SLC4075-n, TouchScreen large “AUX/DDC” 2-position switch, duplicated on every Gateway (TSGW) is a human-machine interface that page, allows for convenient status and control of the is used with our SUPERSTEP SERIES 4000 equipment. -
Page 7: Warnings And Advisories
This system is not designed or intended to be applied in a fail-safe system, such as life-support. In no event shall Selectronix be liable for any loss of profits, loss of data, loss of configuration, or cost of procurement of substitute goods or services, or installation or labor charges. -
Page 8: Red Lion Kadet & Cr1000 Hmi Detailed Information
(425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual 1. Red Lion Kadet & CR1000 HMI Detailed Information Detailed TSGW information is contained in the Red Lion documentation, available on the Selectronix website at www.selectronix.us or at http://www.redlion.net Communicating With the G304K2 i. -
Page 9: Unit Configuration
Verify that the wired adapter is enabled on the laptop. ii. Method 2: Using Programming Cable Selectronix SLC4074-2 OR Red Lion Cable CBLPRO4K Determine the COM port on the host PC that will connect to the TSGW. -
Page 10: Configuration Using Sd Card
The CR1000 TSGW may upload a new image by using an SD card (SLC4030)) inserted into the unit. Obtain an SD card with the desired image from Selectronix or On a PC using the Crimson software, loaded with the desired database •... -
Page 11: Tsgw
AUX/DDC switch (available on all pages) i. AUX enables the local connection to the SLC4000 ii. DDC enables the Building Management Interface and local changes via the TSGW front panel. SLCnet Tx, Selectronix, transmit SLCnet Rx, Selectronix, receive GWnet Tx, BMI communication link transmit m. -
Page 12: Slc4060 Pid 1
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ SLC4060 PID 1 Mode Select 1 = Heat Mode DDC 2 = Cool Mode DDC 3 = Heat Mode AUX available for monitoring or optional Voltage Driver... -
Page 13: Slc4060 Pid 2
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ SLC4060 PID 2 Mode Select 1 = Heat Mode DDC 2 = Cool Mode DDC 3 = Heat Mode AUX available for monitoring or optional Voltage Driver... -
Page 14: Pid Tuning Procedure
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ PID Tuning Procedure The PID control loop is designed to accommodate a very large range of control installations, and as such may require adjustments from the default values to provide the desired control characteristics. The following steps provide a guideline for establishing the correct settings. - Page 15 Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ 9. New feature with TSGW Version 2.17+ and PGW V1.70+ PID Terms The PID term’s contribution as a percentage of the step command is displayed on the active PID page. This provides invaluable information in the PID tuning process.
-
Page 16: Steam Boilers Or Plants With High Thermal Inertia
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ Steam Boilers or plants with high thermal inertia Steam Boilers or plants with high thermal inertia For a plant that has a high thermal inertia, such as a steam plant, the application of heat may be applied more gently, while maintaining a high Proportional value and low Integral value, by increasing the “On Time Delay”... -
Page 17: Slc4060 General Purpose Digital Inputs (Gpdi)
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ SLC4060 General Purpose Digital Inputs (GPDI) Displays the state of the General purpose digital inputs Invert illuminates when the GPDI Invert Mask is set to ‘1’ in the applicable position Alm En illuminates if this GPDI is designated as an alarm Active illuminates when the GPDI is in the logical active state. -
Page 18: Slc4060 Relays
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ SLC4060 Relays Source Selector defines the signal which activates the relay 0 = Disabled 1 = GPDIx, the corresponding GPDIx operates the relay. 2 = GPDIx and GPDI4 the corresponding GPDIx And’ed with GPDI4 operates the relay. -
Page 19: Classic Lead Lag
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ Classic Lead Lag Classic Lead Lag (CLL) is an optional feature that provides several different sequencing profiles to match specific control objectives, in addition to providing the ability to define a custom profile. -
Page 20: Slc4000 Information
Bootloader version of the HMI User Manager The Selectronix Building Management Interface allows remote write access to various data points via BACnet or Modbus. It is the end-user’s responsibility to determine which data points are allowed to be changed, and which user may perform this action. -
Page 21: Communication Assurance
Device Status is a binary number representing the devices online, where each bit represents the corresponding address of an SLCnet device. Address 0 corresponds with bit 0 of the byte. The reference documents may be found in the Support section on our website www.selectronix.us. Table 1 SLC4075 Error Indications... -
Page 22: T Able 2 B Uilding M Anagement I Nterface –M Ost C Ommonly U Sed Bac Net A Nd M Odbus A Ddresses
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ Table 2 Building Management Interface –Most Commonly Used BACnet And Modbus Addresses Description Units BACnet BACnet Modbus Modbus TSGW Analog Analog Analog Holding Page Input Value Input... -
Page 23: T Able 3 B Uilding M Anagement I Nterface –Bac Net A Nd M Odbus C Onfiguration A Ddresses
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ Table 3 Building Management Interface –BACnet And Modbus Configuration Addresses Description Units BACnet BACnet Modbus Modbus TSGW Analog Analog Analog Holding Page Input Value Input Present Present... - Page 24 Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ Description Units BACnet BACnet Modbus Modbus TSGW Analog Analog Analog Holding Page Input Value Input Present Present Value Value (Read (Read Read Read/ Only) /Write) Only Write...
-
Page 25: T Able 5 P Acked Byte Assignments
Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________ Description Units BACnet BACnet Modbus Modbus TSGW Analog Analog Analog Holding Page Input Value Input Present Present Value Value (Read (Read Read Read/ Only) /Write) Only Write... -
Page 26: Field Wiring
Grounding The low voltage circuit common on the Selectronix Superstep SLC4000 controller is TB3, and TB6. It is isolated from the line control voltage and relay connections. Connecting the low voltage circuit common to earth ground is optional, however extreme care must be taken not to introduce ground loops. -
Page 27: Configuration Customization
Select <Edit> to the right side of the “On Startup Complex Code:” iv. Enable or disable any of the available selections by adding or removing “//” at the beginning of the line. v. Contact Selectronix technical support (email techsupport@selectronix.us ) for instructions to change specific parameters, not included in the delivered list. - Page 28 Selectronix, Inc. www.selectronix.us (425) 788-2979 SLC4075 TouchScreen Gateway Installation & Operating Manual ___________________________________________________________________________________________________...
