H401-T-PENNY
Temperature Controller
Manual
IST307_REV02
SV 1.2.6.0
1

Advertisement

Table of Contents
loading

Related Manuals for Okolab H401-T-PENNY

Summary of Contents for Okolab H401-T-PENNY

  • Page 1 H401-T-PENNY Temperature Controller Manual IST307_REV02 SV 1.2.6.0...

  • Page 2: Table Of Contents

    Index PREFACE ..................................... 3 SYMBOL DESCRIPTION ................................4 ................................4 YMBOLS USED IN THIS MANUAL ................................4 YMBOLS ON THE PRODUCT LABEL SAFETY NOTES ..................................5 SUPPLIED EQUIPMENT ................................6 EQUIPMENT DESCRIPTION ..............................7 ....................................7 AVIGATION BUTTONS 5.1.1 ON/OFF device ....................................8 INSTALLATION ..................................9 ......................................9 OMPATIBILITY ...............................

  • Page 3: Preface

    H401-T-PENNY is a compact single-channel temperature controller allowing to set and control the temperature of a single channel Okolab heating device. It is a reliable solution to maintain the effective desired temperature of the specimen right on the microscope stage within the range 25-60°C.

  • Page 4: Symbol Description

    Symbol description This paragraph describes the symbols used in this manual and on the product label. Symbols used in this manual The following symbols identify important information to note: CAUTION or WARNING: this symbol warns you about the risk of electrical shock. CAUTION or WARNING or IMPORTANT: this symbol warns you of circumstances or practices that can affect the functionality of the instrument.

  • Page 5: Safety Notes

    Safety Notes In order to achieve best performance and to ensure proper operation of your new equipment, please read carefully the following safety notes and instructions. If you have any question, please contact Okolab at: info@oko-lab.com − The equipment must only be used as intended and as described in this Manual.

  • Page 6: Supplied Equipment

    Controller. One channel temperature controller. See Figure 1 (1). Device support/cradle. See Figure 1 (2) Power supply and power cord. 24V DC-60 W power supply. See Figure 1 (3) Heating device connector. See Figure 1 (4) Figure 1. H401-T-PENNY – Components.

  • Page 7: Equipment Description

    H401-T-PENNY is a compact single-channel temperature controller allowing to set and control the temperature of a single channel Okolab heating device. It is a reliable solution to maintain the effective desired temperature of the specimen right on the microscope stage within the range 25-60°C.

  • Page 8: On/Off Device

    Figure 3. Turning H401-T-PENNY on. To turn H401-T-PENNY off, keep the UP button pressed for 2 seconds (see Figure 4 a), then press UP for 1 second, following the display info as shown in Figure 4 b. Press DOWN button for 1 second to undo.

  • Page 9: Installation

    Installation H401-T-PENNY can control the temperature of a single heating device. Compatibility H401-T-PENNY is compatible with the following Okolab heating devices: − H601-T-GLASS series* − H401-T-METAL series − H401-T-PAD series − H401-GLASS-TABLE − OBJ-COLLAR-SERIES *single channel For a complete list of compatible heating devices, refer to: www.oko-lab.com.

  • Page 10: Connections Of The Heating Device

    Figure 5. Connection of the heating device. Connect the heating device to the Heating Device connector of H401-T-PENNY (see Figure 5 and Figure 2 (1)). Connect the Power Supply to the 24 VDC Power connector (see Figure 5 and Figure 2 (5)).

  • Page 11: User Interface

    Device temperature Setpoint. See paragraph 7.1.2. Device temperature current value. Tip ► Setpoint Temperature is pre-set at 37. Once turned on, H401-T-PENNY will start operating to reach Note ► If no device is connected, the display shows OPEN, see Figure 7.

  • Page 12: Status Icons

    Setpoint change. The system is working properly, it is not in alarm and no action is needed. As soon as H401-T-PENNY stabilizes the temperature of the heating device, the Controller Status changes to NORMAL and the Check Mark icon appears.

  • Page 13: Menu Navigation

    Figure 10 b. During the transient regime, the controller will not go in alarm. As soon as H401-T-PENNY stabilizes the temperature of the heating device, the controller status changes to NORMAL and the Check Mark icon appears.

  • Page 14: Device Selection

    Figure 11. How to access to Menu navigation: press DOWN button for 2 seconds. Figure 12. H401-T-PENNY Menu. Scroll by pressing UP or DOWN button for 1 second a) page1/2; b) page 2/2. 7.2.1 Device selection The Device selection menu allows to select the type of heating device connected to H401-T-PENNY.
  • Page 15 Figure 14. Heating device label. Figure 15. Selecting the Device Type Number. H401-T-PENNY is pre-set with Type 010. Once turned on, it will start operating with the parameters of Device Type 010. To optimize the temperature control of your heating device, set the Type Number that you can read on the heating device label.

  • Page 16: Advanced: How To Manually Set The Control Parameters

    5. Press UP & DOWN buttons at the same time for 1 second to confirm (see Figure 17 e). 6. Repeat steps 1,2,3, 4 and 5 to insert values for T1, K2, T2 and Delta T parameters. To know the correct parameters values for you device or to receive more information about PID parameters contact Okolab at support@oko-lab.com.

  • Page 17: Calibration

    7.2.2 Calibration H401-T-PENNY allows to calibrate the connected Heating Device. To do so, you need an accurate independent Temperature Sensor with which to measure the temperature of the liquid inside the sample holder. The Calibration is completed when you achieve the desired temperature of the liquid inside the sample holder.
  • Page 18 Figure 18. T Sensor secured inside a Petri Dish 2. Fill the sample holder with oil or water to the level used during regular practice. Make sure the tip of the independent T Sensor is immersed in the liquid, inside the sample holder (see Figure 19). Figure 19.
  • Page 19 Figure 20. H401-T-PENNY: manual calibration with LEO 5. Wait until the temperature measured by LEO (or by any other independent sensor) is stable. 6. Make sure that H401-T-PENNY has reached the steady state, i.e. the status indicator is the Check Mark icon (see paragraph 7.1.1).
  • Page 20 T Sensor and the Setpoint temperature. In the example shown in Figure 20, LEO reports 37.2°C and H401-T-PENNY reads 37°C, the Offset value will be 0.2°C, as shown in Figure 23. Note ► After changing the offset, it is advisable to wait at least 10-20 minutes to ensure that the temperature inside the sample holder is stable.

  • Page 21: Alarm

    7.2.3 Alarm H401-T-PENNY features a visual alarm if the temperature of the heating device becomes unstable. To set alarm specifications, follow the instructions below: 1. Press UP & DOWN buttons at the same time for 1 second (see Figure 24 a) to enter the Alarm page. The submenu will appear as shown in Figure 24 b.

  • Page 22: Unit

    Note ► The alarm time range is 5/20 minutes. The alarm time value is pre-set at 5 minutes. Figure 26. Time alarm setting (a – b). 7.2.4 Unit The H401–T–PENNY allows to choose the measurement unit for Temperature. To set the unit, follow the instructions below: 1.

  • Page 23: System Info

    Select System info by pressing on UP and DOWN buttons for 1 second (see Figure 29 a). This page contains the information related to the H401-T-PENNY serial number and version (see Figure 29 b). Figure 29. System info selection (a – b).

  • Page 24: Cleaning & Maintenance

    Do not pour any cleaning solutions directly on the Heating Device. − Never use thinners, benzene, solvents on or near the Heating Devices to avoid corrosion and discoloration. Maintenance − Periodically check the status of all cables. If you notice any damage please contact Okolab to receive assistance.

  • Page 25: Support

    To contact one of our engineers please write to support@oko-lab.com or contact us through the live chat in www.oko-lab.com. You can request a remote support session anytime. Please, do not hesitate to contact Okolab should you need any further commercial information or technical support. HARDWARE SUPPORT: sibillo@oko-lab.com Phone...

  • Page 26: Technical Specifications

    Technical Specifications H401-T-PENNY TECHNICAL SPECIFICATIONS Range: from ambient to 60°C Temperature Setpoint resolution: 0.1°C Operating Temperature 0°C ~+55°C Storage Temperature 5°C ~ +60°C Operating Humidity 0-70% Temperature control method PID control Power Consumption Depending on the devices connected Max output...

  • Page 27: Troubleshooting

    Troubleshooting The table below shows some frequently asked questions. Please contact Okolab if you need assistance. Symptom Probable cause Remedy Device wrong connections Properly connect the cables to the device Device is off Device cables damaged Replace the cables Low Setpoint value...

  • Page 28: Manual Revision Table

    Figure 11. How to access to Menu navigation: press DOWN button for 2 seconds.................... 14 Figure 12. H401-T-PENNY Menu. Scroll by pressing UP or DOWN button for 1 second a) page1/2; b) page 2/2......14 Figure 13. Device selection (a) and Device selection submenu (b)........................... 15 Figure 14.

  • Page 29: Quick Guide

    Quick guide...
  • Page 35 LIMITATION OF LIABILITY: the total liability of Okolab S.r.l. shall not exceed the purchase price of the component upon which liability is based. In NO event shall Okolab S.r.l. be liable for consequential, incidental or special damage.
