Assemble Main Unit

Pay close attention to the illustrations on this page.
NOTICE Depending on the model, there may be slight di erences in
assembly.
Install the Wheels
A
Slide the axle pin through the
wheel, formed washer, frame and
other formed washer. Slide clip
through hole in axle pin to secure wheel
in place. Repeat steps for second wheel.
Install the Handle
B
Place handle onto
frame, depress the snap
buttons, and slide the handle
assembly onto the frame until
snap buttons snap into place.
7
