Base Unit Parts List - PBZ CropCare ATV-BASE Owner's Manual

Breakdowns & Parts Lists

Base Unit Parts List

Ref# Qty.
1 14'
2 5.5'
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
* Included with spray gun part number (5080015PP406)
** Included with tank part number (T247)
*** Under heat shrink tubing on pump
**** Additional Breakdowns Available
16
Part Number
1206
1208
1 10035**
1 10873**
1 10960**
1 11042
1 19024**
1 19025**
1 47965
2 62606
2 506346***
1 803401
4 6806052
1 10416D
1 2088-343-135
1 2312012PP
1 38720PPBX18*
2 3A1212
1 3A3812
1 3EL1238
1 5080015PP406
1 90FMB12
1 C13201
4 CB38*34G5
1 DE39
1 DE46
1 DEMT3980
4 FN38
1 GCR1214
1 GG60
6 H5C516*34
1 HST38*3
6 LW516
2 MR1024*38S
1 N189472
1 T247****
4 SBT316*1
1 SPT-BCG-1215A-16G
1 SPT-SWH-9615A-16G
2 T229
2 T231
1 DE170
Description
Hose, EPDM Rubber 3/8" 200 PSI
Hose, EPDM Rubber 1/2" 200 PSI
Lid, Tank 5" w/ out Lanyard
Lanyard, 12"
Gasket, Tank Outlet Cap for Den Hartog Applicator Tank
Gasket, EPDM for 5" Lid
Cap, Tank Outlet for Den Hartog Applicator Tank
Tether, Cap Tank Outlet for Den Hartog Applicator Tank
Extension, Wiring Harness 12" 14 GA
Hose Clamp, Narrow 5/16"-7/8" SS
Connector, Wire Butt Terminal 16-14 Ga Insulated
Adapter, Hose 90° 1/2" FPT x 1/2" HB
Hose Clamp, 1/2" - 29/32" SS
Strainer, Suction 3/8" FPT 40 Mesh
Pump, ShurFlo 12V 3 GPM Vi-Santo
Valve, Relief 1/2" NPT Poly 150 PSI piston-type
Adjustable spray nozzle, #18
Adapter, Hose 1/2" MPT x 1/2" HB
Fitting, Hose 3/8" MPT x 1/2" HB
Elbow, Hose 90° 1/2" MPT x 3/8" HB
Spray Gun, TriggerJet 15" Poly Ext 3/8" HB Inlet X18 Tip
Valve, Ball 1/2" FPT x 1/2" MPT 300PSI
Clip, Medium Grip
Bolt, Carriage 3/8-16 x 3/4" Gr 5
Decal, "Warning Read Owner's Manual" 2" x 3"
Decal, CropCare Logo 1.9" x 8.8"
Decal, "Warning Avoid Injury Follow Labels"
Nut, Flange 3/8-16
Cross, Gauge Port 1/2" FPT 1/4" FPT Poly
Gauge, 2-1/2" Liquid Filled 60 PSI
Bolt, Hex 5/16-18 x 3/4" Gr 5
Heat shrink tubing, 3/8" x 3" long
Washer, Lock 5/16"
Screw, Machine Rd Hd 10-24 x 3/8" SS
Clip, Gripper 3/8" - 5/8" Zinc
ATV Base Kit, Tank
Bolt, Stove Truss Head 10-24 x 1"
Harness, Battery Connector w/15A Fuse
Harness, Wiring 8 Ft w/ Switch
ATV Mounting Bracket
ATV Tank Mount
Decal, Model ATV-BASE, Rev. B.1
