- Page 1 PBZ Owner's Manual 20’ Manual Fold Boom Model ATV-MX240 Manufactured by PBZ LLC A Paul B Zimmerman Inc. Company www.CropCareEquipment.com Form: ATV-MX240OM Revision A Rev. Date 01/17...
- Page 2 Notes...
-
Page 3: Table Of Contents
Table Of Contents Before You Begin ..................3 Calibrating the Sprayer..............10 Calculating the Speed ............10 Safety Precautions.................4 Determining Nozzle Size/Using Calibration Chart ..10 Before Operation ................4 During Operation ...............4 Maintenance Instructions ............... 11 Following Operation ..............4 Winterizing your Sprayer ............11 Transporting the Sprayer ............4 Routine Maintenance ............. -
Page 4: Safety Precautions
Safety Precautions Before Operation • • All maintenance should be performed with the sprayer Be aware of the location of all the safety and warning unhooked from the tractor and clean of any harmful decals. Always replace any decals that are illegible or are chemicals. -
Page 5: Assembly Instructions
Assembly Instructions ATV-MX240 Kit Contents ATV-MX240 Boxed Contents Ref # Qty. Part Number Description Center Frame Left Wing Right Wing HDKMX240 Hardware & Nozzle Kit ATV-MX240OM Manual, Owner’s ATV Manual Fold Boom 20’ HDKMX240 Hardware & Nozzle Kit Contents (Figure 1) Ref # Qty. -
Page 6: Atv-Mx240 Assembly Instructions
Assembly Instructions This ATV-MX240 boom kit requires some assembly. Follow the step-by-step instructions to ensure proper assembly. Before assembling, make sure that all of the necessary components and parts are present as shown in the tables on page 5. ATV-MX240 Assembly Instructions Bolt the boom mount brackets (13) (Figure 1 &... - Page 7 Assembly Instructions Connect the hose coming from the controls to the tee on the center frame as shown in figure 7. Slide a loose hose clamp (6) (Figure 1 & 7, pg 5 & 7) onto the hose coming from the controls.
-
Page 8: F2500 Assembly Instructions
Assembly Instructions ***This assembly step is only for assembling an F2500 foam marker kit onto the 20’ manual fold boom. *** F2500 Foam Marker Kit on ATV-MX240 Assembly Instructions Bolt foam marker pan onto ATV-MX240 center frame with using the (1) carriage bolts and (2) flange nuts provided in the F2500 foam marker kit. -
Page 9: Operating Instructions
Operating Instructions Boom Operation Unfold the boom by pulling the boom wings toward the rear of the sprayer as shown (Figure 1). Note: Do not pull on the boom hoses or nozzle bodies when unfolding, as this could cause damage to the components. Begin spraying by operating the sprayer’s control valve(s). -
Page 10: Calibrating The Sprayer
Calibrating the Sprayer Note: All calibration needs to be done with water only! When spraying with the boom, the sprayer must be calibrated to ensure proper spray coverage. Before calibrating the sprayer, it is important to familiarize yourself with the operating instructions. The calibration process is simplified when broken down into the following steps: Calculate the speed of the sprayer or equipment. -
Page 11: Maintenance Instructions
Maintenance Instructions Winterizing your Sprayer It is essential that you winterize your sprayer to avoid damage and to allow for optimal performance. The winterization process should be undertaken before freezing conditions and/or after each season of use. Failure to winterize your sprayer will void the manufacturer’s warranty. -
Page 12: Atv-Mx240 Breakdown
Breakdowns & Parts Lists ATV-MX240 Breakdown... -
Page 13: Atv-Mx240 Parts List
Breakdowns & Parts Lists ATV-MX240 Parts List * Nozzle body breakdown is listed on page 9 ® Contact an authorized CropCare dealer for ordering information Ref# Qty. Part Number Description 19FT 1208 Hose, EPDM Rubber 1/2" 200 PSI 6806052 Hose Clamp, 1/2" - 29/32" SS 22251311500NYB* Body, Nozzle Elbow 1/2"... -
Page 14: Cropcare® Limited Warranty
CropCare ® Limited Warranty Manual Fold Boom ATV-MX240 Warranty Coverage CropCare® hereby provides a Limited One (1) Year Warranty on the Products manufactured by CropCare® that such Products shall be free from manufacturer’s defects in any of the Product’s components in the 12 month period following the original date of purchase from the authorized dealer (the “Warranty Period”). - Page 15 PBZ Manufactured by PBZ LLC A Paul B Zimmerman Inc. Company www.CropCareEquipment.com...
