O P E R A T I N G I N S T R U C T I O N S
RFU63x, RFU65x
RFID read/write devices (UHF)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFU63x-131 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SICK RFU63x-131 Series

Summary of Contents for SICK RFU63x-131 Series

  • Page 1 O P E R A T I N G I N S T R U C T I O N S RFU63x, RFU65x RFID read/write devices (UHF)
  • Page 2 This work is protected by copyright. Any rights derived from the copyright shall be reserved for SICK AG. Reproduction of this document or parts of this document is only permissible within the limits of the legal determination of Copyright Law. Any modifica‐...

  • Page 3: Table Of Contents

    Connecting external antennas..............Connecting the supply voltage..............Wiring data interfaces................8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 4 Maintenance..................81 Maintenance..................... Cleaning..................... Troubleshooting................. 82 10.1 Overview of Potential Errors and Faults..........10.2 Detailed fault analysis................10.3 Status log....................10.4 SICK service....................10.5 Repairs...................... 10.6 Returns...................... 10.7 Replacing the device................Decommissioning................86 11.1 Disposal..................... Technical data..................87 12.1 Technical data RFU63x................

  • Page 5: About This Document

    These instructions apply to all available device variants of the products. Functions spe‐ cific to special devices are, where necessary, described in additional documents. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...

  • Page 6: Explanation Of Symbols

    … highlights useful tips and recommendations as well as information for efficient and trouble-free operation. O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 7: Further Information

    The parameter description supports the user in configuring applications with the SOPAS ET configuration software. SICK service If you require any technical information, our SICK Service will be happy to help. To find your agency, see the final page of this document. NOTE Before calling, make a note of all type label data such as type code, serial number, etc.,...

  • Page 8: Safety Information

    SICK AG assumes no liability for losses or damage arising from the use of the product, either directly or indirectly. This applies in particular to use of the product that does not conform to its intended purpose and is not described in this documentation.

  • Page 9: Improper Use

    The device must not be used in explosion-hazardous areas, in corrosive environ‐ ments or under extreme environmental conditions. • Any use of accessories not specifically approved by SICK AG is at your own risk. WARNING Danger due to improper use! Any improper use can result in dangerous situations.

  • Page 10: Internet Protocol (Ip) Technology

    Modifications and conversions to the device may result in unforeseeable dangers. Interrupting or modifying the device or SICK software will invalidate any warranty claims against SICK AG. This applies in particular to opening the housing, even as part of mounting and electrical installation.

  • Page 11: Requirements For Skilled Persons And Operating Personnel

    (e.g. for configuration, troubleshooting). Permanent use in real operation of the system as a host interface is not intended. For further warranty provisions, see the General Terms and Conditions of SICK AG, e.g. on the delivery note of the device.

  • Page 12: Operational Safety And Particular Hazards

    Safety requirements relating to work on electrical systems must be complied with. ■ O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 13 For regional assignment, see the type-specific online data sheet in the Internet at: www.sick.com/RFU63x 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...

  • Page 14: Repairs

    Repairs Repair work on the device may only be performed by qualified and authorized person‐ nel from SICK AG. Interruptions or modifications to the device by the customer will inval‐ idate any warranty claims against SICK AG. For regional assignment, see type-specific online data sheet in the Internet at: www.sick.com/RFU63x...

  • Page 15: Product Description

    Type label The type label gives information for identification of the device. Type: RFU6xx-xxxxx P/N: 1062600 S/N: 16410240 SICK AG, D-22143 Hamburg Power: DC 10...30V <26W Made in Germany MAC: 00:00:00:00:00:00 Manufactured: May 2016 0700 Figure 1: Structure of the type label The UL certification is dependent on the type.
  • Page 16 The RFU65x product family consists of one variant line: O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 17: Product Characteristics

    2 x function buttons (Step ▾ and Enter p) à 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 18 1 x LED, multi-colored (process feedback) 7 x LED, multi-colored (status indicator) O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 19 “Power/Serial Data/CAN/I/O” connection (male connector, M12, 17-pin, A-coded) “Ethernet” connection (female connector, M12, 4-pin, D-coded) 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 20 O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 21 For region assignment information, see the online data sheet at: www.sick.com/RFU63x 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 22 O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 23 RFU65x The delivery of the device includes the following components: 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 24 The RFU parameter description can be found on the online product page at: • www.sick.com/RFU63x • www.sick.com/RFU65x O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 25 Future-proof due to firmware update via data interface • Future-proof SOPAS ET configuration software with password-pro‐ tected configuration mode • SICK AppSpace ready: The device already includes sensor apps for integrating it into existing communication networks • Low power consumption •...
  • Page 26 • Aux interface RS-232 (fixed data format, data transmission rate and protocol). ° Ethernet, USB ° • CAN interface for integrating the device into the SICK-specific CAN- SENSOR network. • 2 digital switching inputs • 2 digital switching outputs •...
  • Page 27 (if necessary, use a PC and card reader to check and delete the contents of the card). NOTE Only use types approved by SICK to ensure reliable function of the memory card. You can find these as accessories online at: •...
  • Page 28 O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 29: Transport And Storage

    ■ Storage temperature: see "Technical data", page ■ 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 30 ■ components and packaging on a regular basis. O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 31: Mounting

    Finely align the external antennas to the object and adjust them. Test for successful reading and writing in actual operation. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...

  • Page 32: Preparation For Mounting

    (water) or persons to come between the device/external antennas and the transponder. Mounting O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 33 The screw length required depends on the mounting base (wall thick‐ ness of the bracket). When using an optional SICK bracket, the screws for mounting the device on the bracket are included in the scope of delivery of the bracket.
  • Page 34 MOUNTING The device can be mounted using an optional SICK bracket, a combination of SICK brackets and elements, or a customer-specific bracket. • www.sick.com/RFU62x SICK offers prefabricated brackets which are optimally suited for mounting the device in a wide range of applications.
  • Page 35 Base clamp, part no. 5327611 Base (e.g. plate, supplied by the user) NOTE Dimensional drawings for SICK brackets and, if applicable, mounting instructions can be found online at: www.sick.com To do so, enter the 7-digit part number of the bracket in the search field.

  • Page 36: Mounting Location

    O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 37 Recommendation: Depending on the application it may be possible to use one of the optional SICK brackets. If necessary, perhaps also in combination with other SICK brackets. At the intended reading location, place an object with transponder within the work‐...
  • Page 38 Recommendation: Depending on the application it may be possible to use one of the optional SICK brackets. If necessary, perhaps also in combination with other SICK brackets. At the intended reading location, place an object with transponder within the work‐...

  • Page 39: Mounting External Components

    A large selection of photoelectric sensors and accessories (brackets, connecting cables) can be found online at: www.sick.com 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...

  • Page 40: Electrical Installation

    Do not lay cables in parallel with voltage supply cables or motor cables in cable channels over longer distances. O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 41 To avoid a significant attenuation in the UHF output power of the device due to the cables, use the shortest possible cable lengths for the external antennas. • Details of the length-dependent losses in SICK cables can be found in the “Acces‐ sories” section online at: www.sick.com/RFU63x Conditions for specified enclosure rating To maintain the specified enclosure rating of the device (IP67) during operation, the fol‐...
  • Page 42 Measures for widely distributed system installations O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 43 For smaller installations with only slight potential differences, insulated mounting of the device and peripheral devices may be an adequate solution. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...

  • Page 44: Wiring Instructions

    • Follow the wiring instructions closely. Pre-assembled cables O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 45: Overview Of All Interfaces And Connection Options

    Supply voltage V Connection module CDB650-204 or CDM420-0006 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 46 For regional assignment, see online data sheet at: www.sick.com/RFU63x O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 47 Configuration with SOPAS ET, prepared representation of the read result, transponder access or reading diagnostics 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 48 For regional assignment, see online data sheet at: www.sick.com/RFU63x O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 49 For CDB650-204: Connection cable 1:1 (female connector, M12, 17-pin, A-coded/male connector, M12, 17-pin, A-coded) 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 50 "Wiring the digital switching outputs ", page O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 51 Input using the terminal in SOPAS ET (from version 3.3.0) or other USB-capable terminal programs. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...

  • Page 52: Pin Assignments Of Electrical Connections

    Digital switching input 2 N.c. – N.c. – – – Screen O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 53 Digital switching input 1 SensGND Switching input ground 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...

  • Page 54: Instructions For Electrical Installation When The Ambient Temperature Can Fall Below 0 °C

    6.5.1 Prerequisites • Required supply voltage: see "Supply voltage", page 63 • Use SICK standard cables for the specified ambient temperature range, see www.sick.com/RFU63x ° www.sick.com/RFU65x ° • Do not operate the device at ambient temperatures below 0 °C when mounting or connection work is being carried out.

  • Page 55: Installation Steps

    For regional assignment, see online data sheet at: www.sick.com/RFU63x 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 56 For regional assignment, see online data sheet at: www.sick.com/RFU63x O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 57 For CDM420-0006: Adapter cable (female connector, M12, 17-pin, A-coded / male con‐ nector, D-Sub-HD, 15-pin) 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 58 For possible combinations of the device and various connection modules, see table 12, page 59 O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 59 Adapter cable (female connector, M12, 17-pin, A-coded/male connector, D-Sub-HD, 15-pin) CDM420-0007: for connecting 2 devices 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...

  • Page 60: Connecting External Antennas

    • www.sick.com/CDM NOTE Wiring the signals without a SICK connection module When using a customer-specific connection unit, refer to the relevant connection diagrams and descriptions for the basic methods for wiring the signals. • see "Connecting the supply voltage", page 61 •...

  • Page 61: Connecting The Supply Voltage

    8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 62 (signal relative to GND, shielding). O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 63 The voltage drops for a customer-specific connection or connection module have also been taken into account. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 64 When operating the device below 0 °C and using a cold-resistant connecting cable from SICK. When operating the device without a SICK connection module and using a SICK connecting cable. When operating the device below 0 °C and using the cold-resistant connecting cable from SICK, part no. 6048319 (2 x 2.5 mm , 10 m).

  • Page 65: Wiring Data Interfaces

    ELECTRICAL INSTALLATION Wiring with SICK connection module Deliver the supply voltage via a connection module: Connection module Interface Reference CDB650-204 Supply voltage see "Connecting supply voltage for the device in CDB650-204", page 104 CDM420-0006 Supply voltage see "Connecting supply voltage for the device in CDM420-0006", page 117...
  • Page 66 Additional information on this can be found in the operating instructions for the relevant connection module. O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 67: Wiring The Can Interface

    Default: active high, debounce time: 10 ms (standard) 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 68 2” of the device in the CDM420-0006", page 124 O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 69: Wiring The Digital Switching Outputs

    “External output 2” are additionally available at the relevant terminals of the connection module. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 70 2” of the device in the CDM420-0006", page 127 O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 71: Commissioning

    Recording of device and communication data during operation via the diagnostics log file output • System diagnostics 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...

  • Page 72: Starting The Sopas Et Configuration Software And Connecting It To The Device

    Starting the SOPAS ET configuration software and connecting it to the device Start the “SOPAS ET” program option after completing the installation. Path: Start > Programs > SICK > SOPAS ET Engineering Tool > SOPAS. By default, the software automatically searches for connected devices via the Eth‐...

  • Page 73: Initial Commissioning

    MicroSD memory card Permanently saved device parameter set and/or 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 74 CMC600 or CDF600. O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 75 PC to the SOPAS ET configuration software. Memory card NOTE Only use types approved by SICK to ensure reliable function of the memory card. You can find these as accessories online at: • www.sick.com/RFU63x •...

  • Page 76: Operation

    LNK TX Lights up Green Data traffic via Ethernet O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 77 The color of the indicator, and the brightness of the status indicator in Quickstart mode cannot be modified. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 78 The two Step ▾ and Enter function keys p currently have no function. O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 79 Run (no entry of password required), no configuration possible Maintenance (entry of password required) 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 80 Used, for example, to implement user-specific data output protocols for the device. ■ Based on functionality already pre-installed in the programmable device. The app programmed using SICK AppStudio is loaded onto the device as a sensor ■ app. More information is available online at: www.sick.com/SICK_AppStudio...

  • Page 81: Maintenance

    Clean using a dry towel or an industrial vacuum cleaner. Do not use cleaning agents. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...

  • Page 82: Troubleshooting

    For faults that occur during reading, the device writes fault codes in the status log (see "Status log", page 83). O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 83: Status Log

    10.5 Repairs Repair work on the device may only be performed by qualified and authorized person‐ nel from SICK AG. Interruptions or modifications to the device by the customer will inval‐ idate any warranty claims against SICK AG. 10.6 Returns Do not dispatch devices to the SICK Service department without consultation.

  • Page 84: Replacing The Device

    NOTE Further information see "Initial commissioning", page 73 O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 85 PC, by downloading it to the replacement device and permanently storing it there. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...

  • Page 86: Decommissioning

    Separate the recyclable materials by type and place them in recycling containers. ■ O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 87: Technical Data

    Type-dependent. See type-specific online data sheet at: www.sick.com/RFU63x 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 88 Depending on the transponders used, the external antenna(s) and the ambient conditions. Optional accessories. O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 89 Bus length depends on data transmission rate and length of cable. Typical: 250 m at 250 kBit/s and wire cross-section ≥ 0.34 mm Protocols: • CSN (SICK CAN sensor network) • CANopen® PROFIBUS Via external fieldbus module CDF600-21xx to PROFIBUS (RS-485) for data output (read result) Aux (USB 2.0) for service...
  • Page 90 You can find further information on the Internet at: www.sick.com/SICK_AppStudio For example: Configuration, diagnosis, transponder access or display of the read results. Function blocks for various PLC manufacturers are available online at: www.sick.com/RFU63x. USB interface only for temporary use (service) Optional accessories.
  • Page 91 You can find further information on the Internet at: www.sick.com/SICK_AppStudio For example: configuration, diagnosis, transponder access or display of the read results. Function blocks for various PLC manufacturers are available online at: www.sick.com/RFU63x. USB interface only for temporary use (service) Optional accessories.
  • Page 92 When connected to the optional SICK CDB650-204 or CDM420-0006 connection module using a SICK cable. When operated without a connection module using a SICK cable. 2 A fuse protection at the start of the feeding supply circuit. When operated without a connection module using a SICK supply cable part no. 6048319 (2 x 2.5 mm 10 m).

  • Page 93: Technical Data Rfu65X

    MTBF 25 years Scanning range ≤ 10 m 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 94 Typical: 250 m at 250 kBit/s and wire cross-section ≥ 0.34 mm Protocols: • CSN (SICK CAN sensor network) • CANopen® O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 95 Function blocks for various PLC manufacturers are available online at: www.sick.com/RFU65x. USB interface only for temporary use (service) Optional accessories. e.g. with SOPAS ET configuration software. Functions can be enabled with the SDK6U SD card. Available at: www.sick.com. 12.2.3 Mechanics and electronics Table 32: Technical data for RFU65x: Mechanics/electronics...

  • Page 96: Working Range Diagram

    When connected to the optional SICK CDB650-204 or CDM420-0006 connection module using a SICK cable. When operated without a connection module using a SICK cable. 2 A fuse protection at the start of the feeding supply circuit. When operated without a connection module using a SICK supply cable part no. 6048319 (2 x 2.5 mm 10 m).

  • Page 97: Accessories

    The RFU63x-041xx does not have any internal antennae and requires at least one external antenna for operation. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...

  • Page 98: Annex

    For mobile installation: –25 °C to +80 °C, for fixed installation: –40 °C to +80 °C O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 99 For mobile installation: –25 °C to +80 °C, for fixed installation: –40 °C to +85 °C 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 100 Female connector, M12, 17-pin, A-coded (view from front) Illustration may differ O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 101 For mobile installation: –5 °C to +90 °C, for fixed installation: –30 °C to +90 °C 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...

  • Page 102: Connection Diagrams Of Connection Module Cdb650-204

    Device = RFU63x-131xx or RFU63x-041xx, 1 switching input used Device = RFU65x-101xx, 1 switching input used O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 103 (highlighted in gray) Supply voltage V à 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 104 Wiring serial host interface RS-232 of the device in CDB650-204 Device = RFU63x-131xx, RFU63x-041xx Device = RFU65x-101xx O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 105 Wiring serial host interface RS-422 of the device in CDB650-204 Device = RFU63x-131xx, RFU63x-041xx Device = RFU65x-101xx 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 106 Wiring serial host interface RS-485 of the device in CDB650-204 Device = RFU63x-131xx, RFU63x-041xx Device = RFU65x-101xx O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 107 RS-485 protocol. • This configuration is not permitted when using the standard data output and pro‐ tocol of the device. In case of doubt, contact SICK Service. • Activate the RS-485 data interface (“Bus” option) in the device using a configura‐...
  • Page 108 RFU63x-131xx and RFU63x0-041xx: connection cable 1:1 (female connector, M12, 17- ß pin, A-coded/male connector, M12, 17-pin, A-coded) O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 109 PNP sensor Supply voltage V 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 110 ≤ 30 V; 0.7 mA ≤ I ≤ 5 mA O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 111 PNP sensor Supply voltage V 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 112 15 ms when transmitting the signal input at the CMC600 to the device. O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 113 Connection module: female connector, M12, 17-pin, A-coded Device: male connector, M12, 17-pin, A-coded 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 114 Figure 56: Wiring external digital switching outputs “EXT. OUT 1” and “EXT. OUT 2” of the device in the connection module CDB650-204 O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...

  • Page 115: Connection Diagrams Of Connection Module Cdm420-0006

    An adapter cable (female connector, M12, 17-pin, A-coded / male connector, D-Sub- HD, 15-pin) is required to connect the device to the connection module. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 116 PLC (programmable logic controller) SCANNER = Device Female connector, D-Sub-HD, 15-pin O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 117 Connecting serial host interface RS-232 of the device in CDM420-0006 Device = RFU63x-131xx, RFU63x-041xx 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 118 Connecting serial host interface RS-422 of the device in CDM420-0006 Device = RFU63x-131xx, RFU63x-041xx Device = RFU65x-101xx O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 119 Wiring serial host interface RS-485 of the device in CDM420-0006 Device = RFU63x-131xx, RFU63x-041xx Device = RFU65x-101xx 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 120 RS-485 protocol. • This configuration is not permitted when using the standard data output and pro‐ tocol of the device. In case of doubt, contact SICK Service. • Activate the RS-485 data interface (“Bus” option) in the device using a configura‐...
  • Page 121 Maximum 32 users á Alternative connection module CDB650-204. â 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 122 PNP sensor Supply voltage V O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 123 ≤ 30 V; 0.7 mA ≤ I ≤ 5 mA 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...
  • Page 124 PNP sensor Supply voltage V O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 125 15 ms when transmitting the signal input at the CMC600 to the device. 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x...
  • Page 126 Assign the functions for the digital switching outputs in the device with a configuration tool, e.g. the configuration software SOPAS ET. O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x 8014335/ZTL9/2018-10-14 | SICK Subject to change without notice...
  • Page 127 Terminal C Aux Out 1 Aux Out 2 8014335/ZTL9/2018-10-14 | SICK O P E R A T I N G I N S T R U C T I O N S | RFU63x, RFU65x Subject to change without notice...

  • Page 128: Copyright Notices

    Automation GmbH, Germany. Open source programs SICK uses open-source software in the device. This software is licensed by the rights holders using the following licenses among others: the free licenses GNU General Pub‐ lic License (GPL Version2, GPL Version3) and GNU Lesser General Public License (LGPL), the MIT license, zLib license, and the licenses derived from the BSD license.
  • Page 129 Rich Text Format (standard document format with format descriptions) Radio Frequency Ultra high frequency Secure Digital SOPAS ET SICK Open Portal for Application and Systems Engineering Tool (PC soft‐ ware for Windows for device configuration) SOPAS Device Description (device description file) SELV...
  • Page 130 Phone +36 1 371 2680 Phone +386 591 78849 E-Mail ertekesites@sick.hu E-Mail office@sick.si India South Africa Phone +91-22-6119 8900 Phone +27 (0)11 472 3733 Further locations at www.sick.com E-Mail info@sick-india.com E-Mail info@sickautomation.co.za SICK AG | Waldkirch | Germany | www.sick.com...

This manual is also suitable for:

Rfu63x-041 seriesRfu63x-04100Rfu65x-101 seriesRfu63x-13100Rfu63x-13101Rfu63x-04101 ... Show all

Table of Contents
