- Page 1 RFID MODULE Mifare Reader / Writer SL030 User Manual Version 3.0 January 14, 2016 StrongLink...
-
Page 2: Table Of Contents
4-3-1. S ......................9 ELECT IFARE CARD 4-3-2. L ......................9 OGIN TO A SECTOR 4-3-3. D SL030 ....................9 OWNLOAD EY INTO 4-3-4. L ..................11 OGIN SECTOR VIA STORED KEY 4-3-5. R ......................11 EAD A DATA BLOCK 4-3-6. -
Page 3: Main Features
StrongLink SL030 3.0 1. MAIN FEATURES *This picture may not be exactly the same as real object. • Tags supported: Mifare 1k, Mifare 4k, Mifare UltraLight, Mifare UltraLight C, NTAG203, DESFire, DESFire EV1 and Mifare Plus 2K/4K • Built-in antenna •... -
Page 4: Pinning Information
Serial Data Line Input Serial Clock Line Tag auto-detection signal Output low level indicating tag in high level indicating tag out Ground Attention: Pin IN must be connected HIGH voltage when working, so SL030 can enter power down mode properly. http://www.stronglink-rfid.com... -
Page 5: Device Operation
All addresses and data words are serially transmitted to and from the SL030 in 8-bit words. The SL030 sends a zero to acknowledge that it is not busy, and has received each word. This happens during the ninth clock cycle. -
Page 6: Busy State
The device address word consists of 7 bits addressing and 1 bit operation select bit. The first 7 bits are the SL030 addressing, is 10100xx depend on JP1 and JP2 status as below table... -
Page 7: Write Operations
StrongLink SL030 3.0 3-7. Write Operations The host device send a command(refer chapter 4) to SL030 via write operation, then SL030 will carry out the order that receive. Finished time according to different order 3-8. Read Operations The host device passes to read the operation gets the order carries out the result 4. -
Page 8: Command Overview
StrongLink SL030 3.0 4-2. Command Overview Table 3 Command Description 0x01 Select Mifare card 0x02 Login to a sector 0x03 Read a data block 0x04 Write a data block 0x05 Read a value block 0x06 Initialize a value block 0x07... -
Page 9: Command List
Login fail 0x08: Address overflow 4-3-3. Download Key into SL030 Mifare Plus SL0 and SL3 can tell differences via ATS(ISO14443-4). Before ATS, they have the same ATQA and SAK(ISO14443-3). SL030 judges card type only via ISO14443-3 layer for the compatibility. http://www.stronglink-rfid.com... - Page 10 StrongLink SL030 3.0 Host Write: 0x12 Sector Type Sector: 0x00 – 0x27 Type: Key type (0xAA: KeyA, 0xBB: KeyB) Key: 6 bytes, stored into SL030 Host Read: 0x12 Status Status: 0x00: Operation succeed 0x08: Address overflow 0x09: Download fail Note: Some delay is needed between Host Write and Host Read.
-
Page 11: Login Sector Via Stored Key
StrongLink SL030 3.0 4-3-4. Login sector via stored key Host Write: 0x13 Sector Type Sector: Sector need to login, 0x00 – 0x27 Type: Key type (0xAA: KeyA, 0xBB: KeyB) Host Read: 0x13 Status Status: 0x02: Login succeed 0x03: Login fail... -
Page 12: Initialize A Value Block
StrongLink SL030 3.0 Status: 0x00: Operation succeed 0x01: No tag 0x04: Read fail 0x0D: Not authenticate 0x0E: Not a value block Value: Value returned if the operation succeeds, 4 bytes. 4-3-8. Initialize a value block Host Write: 0x06 Block Value Block: The absolute address of block to be initialized, 1 byte. -
Page 13: Decrement Value
StrongLink SL030 3.0 0x08 Status Value Status: 0x00: Operation succeed 0x01: No tag 0x05: Write fail 0x06: Unable to read after write 0x0D: Not authenticate 0x0E: Not a value block Value: The value after increment if the operation succeeds, 4 bytes 4-3-11. -
Page 14: Read A Data Page (Ultralight & Ntag203)
StrongLink SL030 3.0 4-3-13. Read a data page (UltraLight & NTAG203) Host Write: 0x10 Page Page: The page number to be read, 1 byte Host Read: 0x10 Status Data Status: 0x00: Operation succeed 0x01: No tag 0x04: Read fail 0x08:... -
Page 15: Power Down
Host Write: 0x50 Host Read: 0x50 Status Status: 0x00: Operation succeed Note: Some delay is needed when waking up SL030. 4-3-19. Write Perso Host Write: 0x80 Data Bnr: 2Byte Block or Key Address to be written, MSB first. For example, Master Key Address is 0x9000, and write it as 0xFFFF..FF(16Bytes) -
Page 16: Get Firmware Version
By the way, we also offer you the Turn On/Off Auto-detection command. 2. New SL030 supports nearly all cards of NXP Mifare series now and we rebuilt the card type characters.(Details see to Command Select Mifare Card Description)
