StrongLink SL030 User Manual

Mifare read/write module
Hide thumbs Also See for SL030:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
RFID MODULE
Mifare Read/Write Module
SL030
User Manual
Version 1.3
Dec 2006
StrongLink

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL030 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for StrongLink SL030

Summary of Contents for StrongLink SL030

  • Page 1 RFID MODULE Mifare Read/Write Module SL030 User Manual Version 1.3 Dec 2006 StrongLink...

  • Page 2: Table Of Contents

    StrongLink SL030 CONTENT 1. MAIN FEATURES.................. 3 2. PINNING INFORMATION ..............4 3. DEVICE OPERATION................5 3-1. CLOCK and DATA TRANSITIONS:..............5 3-2. START CONDITION ....................5 3-3. STOP CONDITION ....................5 3-4. ACKNOWLEDGE ....................5 3-5. BUSY STATE ......................6 3-6.

  • Page 3: Main Features

    StrongLink SL030 1. MAIN FEATURES • Tag supported: Mifare 1K, Mifare 4K, Mifare UltraLight • Auto detecting tag • Built-in antenna • 0 to 400 kHz bit-wide I C-bus communication • DC2.5V to DC3.6V VDD operating, I/O pins are 5V tolerant •...

  • Page 4: Pinning Information

    StrongLink SL030 2. PINNING INFORMATION SYMBOL TYPE DESCRIPTION Power supply, DC2.5V to DC3.6V Input Falling edge wake up SL030 from power down mode Input/Output Serial Data Line Input Serial Clock Line Tag detect signal Output low level indicating tag in...

  • Page 5: Device Operation

    A low-to-high transition of SDA with SCL high is a stop condition. 3-4. ACKNOWLEDGE All addresses and data words are serially transmitted to and from the SL030 in 8-bit words. The SL030 sends a zero to acknowledge that it is not busy,and has received each word.

  • Page 6: Busy State

    3-7. Write Operations The host device send a command(refer chapter 4) to SL030 via write operation, then SL030 will carry out the order that receive. Finished time according to different order...

  • Page 7: Read Operations

    StrongLink SL030 3-8. Read Operations The host device passes to read the operation gets the order carries out the result 4. COMMAND DESCRIPTION 4-1. FORMAT Host Write Command to SL030: Address Len Command Data Address: 1 byte, 0xA0 Len: Byte length counting from Command Code to the last byte of the data, 1 byte.

  • Page 8: Command Overview

    StrongLink SL030 4-2. COMMAND OVERVIEW Command Description 0x01 Select Mifare card 0x02 Login to a sector 0x03 Read a data block 0x04 Write a data block 0x05 Read a value block 0x06 Write a value block 0x07 Write master key (key A)

  • Page 9: Command List

    StrongLink SL030 4-3. COMMAND LIST 4-3-1. Select Mifare card Host Write: 0x01 Host Read: 0x01 Status Serial num Type Status: 0x00: Operation success 0x01: No tag 0x0A: Collision occur Serial num: Serial number of the card detected if the operation is success, 4 bytes for Mifare Standard &...

  • Page 10: Write A Data Block

    StrongLink SL030 4-3-4. Write a data block Host Write: 0x04 Block Data Block: The block number to be written, 1 byte. Data: The data to write, 16 bytes. Host Read: 0x04 Status Data Status: 0x00: Operation success 0x01: No tag...

  • Page 11: Write Master Key (Keya)

    StrongLink SL030 4-3-7. Write master key (KeyA) Host Write: 0x07 Sector Sector: The sector number to be written, 1 byte. Key: Authentication key, 6 bytes Host Read: 0x07 Status Status: 0x00: Operation success 0x01: No tag 0x05: Write fail 0x0D: Not authenticate Key: Authentication key written if the operation is success, 6 bytes.

  • Page 12: Copy Value

    StrongLink SL030 4-3-10. Copy value Host Write: 0x0A Source Destination Source: The source block copy from, 1 byte Destination: The destination copy to, 1 byte The source and destination must in the same sector Host Read: 0x0A Status Value Status: 0x00:...
