StrongLink SL032 User Manual

Mifare reader / writer rfid module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RFID MODULE
Mifare Reader / Writer
SL032
User Manual
Version 3.0
Nov 30, 2016
StrongLink

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL032 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for StrongLink SL032

Summary of Contents for StrongLink SL032

  • Page 1 RFID MODULE Mifare Reader / Writer SL032 User Manual Version 3.0 Nov 30, 2016 StrongLink...

  • Page 2: Table Of Contents

    StrongLink SL032 V3.0 CONTENT 1. MAIN FEATURES ................. 3 2. PINNING INFORMATION ..............4 3. BAUD RATE SETTING ................5 4. COMMUNICATION PROTOCOL............5 4-1. C ..............5 OMMUNICATION ETTING 4-2. C ..............5 OMMUNICATION ORMAT 4-3. C ................6...

  • Page 3: Main Features

    StrongLink SL032 V3.0 1. MAIN FEATURES *This picture may not be exactly the same as real object.  Tags supported: Mifare 1k, Mifare 4k, Mifare UltraLight, Mifare UltraLight C, NTAG203, DESFire, DESFire EV1 and Mifare Plus 2K/4K  Built-in antenna ...

  • Page 4: Pinning Information

    Tag auto-detection signal Output low level indicating tag in high level indicating tag out Ground Attention: Pin IN must be connected HIGH voltage when working, so SL032 can enter power down mode properly. Auto-detection command to control its on/off. http://www.stronglink-rfid.com...

  • Page 5: Baud Rate Setting

    StrongLink SL032 V3.0 3. BAUD RATE SETTING R6 & R7 are used for setting baud rate as follows sheet Baud rate bps 9,600 19,200 Assembled 57,600 115,200 ( default ) 4. COMMUNICATION PROTOCOL 4-1. Communication Setting The communication protocol is byte oriented. Both sending and receiving bytes are in hexadecimal format.

  • Page 6: Command Overview

    StrongLink SL032 V3.0 4-3. Command Overview Table 3 Command Description 0x01 Select Mifare card 0x02 Login to a sector 0x03 Read a data block 0x04 Write a data block 0x05 Read a value block 0x06 Initialize a value block 0x07...

  • Page 7: Command List

    Status: 0x02: Login succeed 0x03: Login fail 0xF0: Checksum error Mifare Plus SL0 and SL3 can tell differences via ATS(ISO14443-4). Before ATS, they have the same ATQA and SAK(ISO14443-3). SL032 judges card type only via ISO14443-3 layer for the compatibility. http://www.stronglink-rfid.com...

  • Page 8: Read A Data Block

    StrongLink SL032 V3.0 4-4-3. Read a data block 0xBA 0x03 Block Checksum Block: The block number to be read, 1 byte Response: 0xBD 0x03 Status Data Checksum Status: 0x00: Operation succeed 0x04: Read fail 0x0D: Not authenticate 0xF0: Checksum error Data: Block data returned if operation succeeds, 16 bytes.

  • Page 9: Write Master Key (Key A)

    StrongLink SL032 V3.0 0x05: Write fail 0x06: Unable to read after write 0x0D: Not authenticate 0xF0: Checksum error Value: Value written if the operation succeeds, 4 bytes. 4-4-7. Write master key (key A) 0xBA 0x07 Sector Checksum Sector: The sector number to be written, 1 byte.

  • Page 10: Copy Value

    StrongLink SL032 V3.0 0xF0: Checksum error Value: The value after decrement if the operation succeeds, 4 bytes 4-4-10. Copy value 0xBA 0x0A Source Destination Checksum Source: The source block copy from, 1 byte Destination: The destination copy to, 1 byte...

  • Page 11: Download Key

    SL032 V3.0 4-4-13. Download Key 0xBA 0x12 Sector Type Checksum Sector: 0 - 39 Type: Key type (0xAA: KeyA, 0xBB: KeyB) Key: 6 bytes, stored in SL032 Response: 0xBD 0x12 Status Checksum Status: 0x00: Operation succeed 0x08: Address overflow 0xF0: Checksum error 4-4-14.

  • Page 12: Led Control

    StrongLink SL032 V3.0 4-4-17. LED Control 0xBA 0x40 Data Checksum Data: 0x00: LED off 0x01: LED on Return: 0xBD 0x40 Status Checksum Status: 0x00: Operation succeed 0xF0: Checksum error http://www.stronglink-rfid.com...

  • Page 13: Power Down

    StrongLink SL032 V3.0 4-4-18. Power Down 0xBA 0x50 Checksum Response: 0xBD 0x50 Status Checksum Status: 0x00: Operation succeed 0xF0: Checksum error 4-4-19. Write Perso 0xBA 0x80 Data Checksum Bnr: 2Byte Block or Key Address to be written, MSB first. For example, Master Key Address is 0x9000, and write it as 0xFFFF..FF(16Bytes)

  • Page 14: Turn On/Off Auto-Detection

    DESFire or MifarePlus L0/L2/L3 card coming into the detection range. By the way, we also offer you the Turn On/Off Auto-detection command. 2. New SL032 supports nearly all cards of NXP Mifare series now and we rebuilt the card type characters.(Details see to Command Select Mifare Card Description) 3.
