Summary of Contents for Philips 105S7 Series
- Page 1 User’s Manual 105S7 15” (13.8” viewable) Ultra High Resolution Plug & Play Ready Multi-Frequency FS Color Monitor OSD Control...
-
Page 2: Table Of Contents
Contents American federation communication committee (FCC) standard explanation ---------3 Safety Precautions ----------3 Introduction ----------4 General Information ----------4 Features of the Monitor ----------4 Installation ----------5 Check List ----------5 Install the Monitor Base ----------5 Power Cable Connection ----------5 Signal Cable Connection ----------6 Power On ----------6 Adjust the Picture... -
Page 3: American Federation Communication Committee (Fcc) Standard Explanation
American federation communication committee (FCC) standard explanation Based on FCC standard 15th,This machine process test, Conforms to the B level digital equipment limit and the stipulation. These limits are for prevent the home use installment the harmful radio-frequency interference but to stipulate. This machine when use can produce the electromagnetic wave, If not according to instruction booklet installment and use, Possibly can have the disturbance to the radio wave. -
Page 4: Introduction
result in electric shock, fire hazard or cause a short circuit. Never attempt to service this product yourself. Opening this unit may expose you to dangerously high voltages. Refer all servicing to a qualified service personnel. Keep this instruction manual for later use. Note: Unplug this product and contact qualified service personnel if: The power cord or plug is damaged or frayed The product has been exposed to rain or water The product does not operate... -
Page 5: Installation
® Microsoft Windows 95/98/NT/2000/ME compatible ® VESA Display Data Channel (DDC) 1/2B compatible Installation Setting up your monitor is very easy. Just make a few simple connections and adjustments. The following procedure is to guide you to the proper usage of this product. 2.1 Check List Before operating this monitor, please make sure that all of the following items are included: Monitor... -
Page 6: Signal Cable Connection
2.4 Signal Cable Connection The monitor has an built-in signal cable with a male 15-pin mini D-sub connector. Attach this connector to the female 15-pin receptacle of your video adapter. Be cautious when inserting the cable properly into the graphics card adapter. If the cable does not seem to fit, it may be facing the wrong direction. -
Page 7: Operation
3. Operation Make sure you carefully follow the “Safety” and “Installation” instructions before operating your monitor. You may also want to familiarize yourself with the “Image Adjustment” section of this manual before making any operational adjustments. 3.1 To operate the monitor Turn on the monitor by pressing the power button once. -
Page 8: Image Adjustment
3.2 Image Adjustment The four control keys are designed to provide full user-friendly programming capabilities in one simple-to-use location. This allows you to choose either of the control keys and make necessary adjustments. To adjust visual settings: 1. Press “ - “ or “ + “ or “ < “ or “ > “ and then OSD menu will appear. 2. - Page 9 2. Geometry : Screen secondary adjustment. Rotation : Adjust the tilt of the display. V-Moire : Reduce the optical effect of wavy lines or ripples on the display image in the horizontal direction. ( Over adjustment the moire will cause the effect of the shaking and poor focus on the screen .) H-Moire : Reduce the optical effect of wavy lines or ripples on the display image in the vertical direction.
- Page 10 5. Language : Allow user to select OSD menu in preferred languages. Press “ - “ or “ + “ to make the selection. 6. Others : Other function selections. OSD H-Location : Allow user to adjust the horizontal position of OSD menu on the display.
- Page 11 Exit : Terminate OSD menu on the screen. When the monitor detects an excessive signal input, the warning message box (illustrated below) will appear on the screen to refrain user from further usage and advise user to adjust the signal input in compliance to the stated safe range. When the monitor does not have the signal input, Warned the news frame (the under illustration) will be able on the screen to appear in order to avoid the user will make the further movement, 8 seconds will meet the monitor to be able from now on to enter the standby...
-
Page 12: Specifications
4. Specifications 15-inch (13.8” viewable) diagonal Dot pitch 0.28mm Max Resolution 1024 x 768 / 60 Hz Display color Unlimited Scanning frequency Horizontal: 30K – 54 KHz Vertical: 50 – 120 Hz Display area Factory presetting: 270 x 202 mm (W x H) Video bandwidth 72 MHz (3dB) Input signal... -
Page 13: Power Management
5. Power Management ® The power management feature enables this monitor to recognize VESA DPMS (Display ® Power Management Signaling) signals from a VESA DPMS video adapter and power down to less than 5 watts of power consumption. There are three status to power management: On, Standby, and Active Off. In the On mode the monitor and computer are in operation and the LED is green. -
Page 14: Timing Guide
6. Timing Guide This multifrequency monitor operates at horizontal frequency of 30K to 54KHz and vertical frequency of 50 to 120 Hz. The microprocessor-based design offers auto-syncronization. This monitor offers 12 preprogrammed settings that cover most of the common video modes supported by popular graphics adapters. -
Page 15: Pin Assignment
7. Pin Assignment The pin assignment of the connectors is listed below for professional use only. Please do not attempt to alter the connections yourself as this may seriously damage the monitor. Pin No. Assignment Red Video input Green video input Blue video input Ground Red video ground...
