2. S pec ific ations

Voltage Ranges:
Current Ranges:
Accuracy:
1 Volt range:
100mV range:
10mV range:
100mA range:
10mA range:
8 Volt range:
Linearity:
Temp. Coeff:
Noise:
Battery:
Battery Condition:
Output Polarity:
Maximum Output Current:
1V, 100mV Ranges:
10mV Range:
Maximum Output Voltage
(Current Ranges):
Output Protection:
1030 Technical Manual
4
0 - 1V (1mV resolution).
0 - 100 mV (100µV resolution).
0 - 10 mV (10µV resolution).
8 Volts (10mV resolution)
using external precision 1KΩ resistor supplied.
0 - 100mA (100µA resolution),
0 - 10mA (10µA resolution).
± 0.1% of FS ± 30µV.
± 0.1% of FS ± 3µV.
± 0.2% of FS ± 0.3µV.
± 0.2% of FS ± 3µA.
± 0.2% of FS ± 0.3µA.
± 0.3% of FS.
0.15% of setting.
150 ppm of FS /ºC (Outside 18 to 28ºC).
30 ppm of full scale.
9V PP3 type. Approx. 60 hours life
depending on output current.
Nicad rechargeable available as an optional extra.
Continuously monitored by front panel indicator.
Positive or Negative, switch selectable.
A centre Off position is also provided, which shorts
the output terminals together.
Typically 20 mA.
Up to short circuit value although it should be
noted that loads of less than 1k ohm will give
greater than 0.1% error.
8V.
The 1030 can withstand continuous short circuit
or open circuit on all ranges.
