Permobil Compact Joystick Advanced R-net Programming Manual page 8

Mode Drive/Axes:
Mode Drive/Axes/Profiles:
Drive Axis:
Running Lights:
Hazard Lights Indicator:
Left light Indicator:
Right light Indicator:
Toggle Auto Controls:
Programming manual Compact Joystick Advanced R-net
Document Number: 205314-UK-0 Edition 2 2009-10 (0033-8009a-0100a)
Selects alternating 'Drive Mode' or 'Local Axes Mode'.
This parameter is used in combination with the 'Next'
parameter. See section 4.3.4 for an example. Pressing
the button/switch that is assigned as 'Next' will select in
'drive mode' the next profile and in 'local axes mode' the
next axis. The number of axes is limited to the value set
in the 'Number of Axes' parameter.
This is also known as the 2 button control.
Selects between 'drive mode', 'profile selection' and
'local axes mode'. See section 4.3.3 for an example. In
'drive mode' the joystick is used to drive the wheelchair,
in 'profile selection' with the joystick you can select the
next or previous profile and in 'local axes mode' with the
joystick you can drive an axis or selects the next or
previous axis. This is also known as the 1 button control.
Allows you to control the axes specified in Profile Switch
Drive Axis by depressing the button/switch. Special
precautions are built-in to limit the possibility to
involuntary activation of an axis. It also limits the
maximum duration of the activation.
Allows you to switch on/off the running lights of you
wheelchair.
Allows you to switch on/off the hazard lights indicator of
you wheelchair.
Allows you to switch on/off the left light indicator of you
wheelchair.
Allows you to switch on/off the right light indicator of you
wheelchair.
Allows you to switch on/off the auto light and auto horn
control if they are activated.
Page: 8/15
