2.0 Programming

The control system can be programmed to meet your needs. Programming can be
performed using the R-net programmer software and dongle/programming key.
If you re-program your control system, make sure that you observe any restrictions given
in your wheelchair user manual. Note any changes you make for future reference.
Remark! Programming should only be conducted by healthcare professionals with in-
depth knowledge of PGDT electronic control systems and the CJA R-net. Incorrect
programming could result in an unsafe set-up of a wheelchair for a user. Permobil accepts
no liability for losses of any kind if the programming of the control system is altered from
factory pre-set values.

2.1 Program Settings

It is the wheelchair manufacturer's or dealer responsibility to program the control system to
suit the vehicle model and ensure safe operation in compliance with relevant legal
requirements over the whole of the operating range. Permobil accepts no liability for
losses of any kind due to failure to, or incorrect programming of the R-net Control System.
Programming should only be conducted by healthcare professionals with in-depth
knowledge of PGDT electronic control systems and of the CJA R-net of Permobil.
Incorrect programming could result in an unsafe setup of a wheelchair for the user.

2.2 Programming Connection

2.3 PC Programming

To utilize the R-net PC Programming Suite the R-net Dongle must first be connected in the
communications system as shown. A USB cable can then be connected between the
Dongle and a PC with the R-Net PC Programmer installed.
