SDM-3R Docking Station
Standalone Configuration
Operator's Manual
Part Number: 71-0487
Revision: P1
Released: 5/13/19
www.rkiinstruments.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDM-3R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RKI Instruments SDM-3R

Summary of Contents for RKI Instruments SDM-3R

  • Page 1 SDM-3R Docking Station Standalone Configuration Operator’s Manual Part Number: 71-0487 Revision: P1 Released: 5/13/19 www.rkiinstruments.com...
  • Page 2 Warranty RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in materials and workmanship, and performance for a period of one year from date of shipment from RKI Instruments, Inc. Any parts found defective within that period will be repaired or replaced, at our option, free of charge.

  • Page 3: Table Of Contents

    Wall Mounting the SDM-3R, Optional ........
  • Page 4 Chapter 4: Parameter Setup in SDM-3R’s Config Menu ....... . .

  • Page 5: Chapter 1: Introduction

    Docking Station PC Controlled Configuration Operator’s Manual. The purpose of this manual is to explain how to set up and use the SDM-3R in Standalone configuration. It also explains how to use the sections of the PC Program associated with Standalone use.

  • Page 6: System Requirements

    The operator of this instrument is advised that if the equipment is used in a manner not specified in this manual, the protection provided by the equipment may be impaired. System Requirements To use the SDM-3R Docking Station PC Controller Program, your personal computer must meet the following requirements: ® ®...

  • Page 7: Cautions & Safety Information

    Use only polyurethane sample tubing with the SDM-3R. Consult RKI Instruments, Inc. for other materials. • Do not subject the SDM-3R to infrared or intense light. This may cause communication errors. • Do not expose the SDM-3R to water. •...

  • Page 8: Chapter 2: Description

    Instrument Cradle The instrument cradle is a recessed area in the middle of the SDM-3R that is designed to accept the GX-3R or the GX-3R Pro. The yellow lever in the cradle must be up for GX-3R operation and down for GX-3R Pro operation.

  • Page 9: Control Buttons And Leds

    COPY • Copies bump test, calibration, Off: no records saved and alarm check records to a Green: More than 20% of SDM-3R memory remains USB drive Orange: Less than 20% of SDM-3R memory remains • Clears SDM-3R memory when Red: No memory available. Oldest records will be deleted use with CAL ...

  • Page 10: Cylinder Connections (Side Panels)

    Cylinder Connections (Side Panels) Four gas fittings are located on the left side of the SDM-3R. Three are for gas cylinders and one is for the particle filter or a zero air cylinder. The left to right order is: GAS 3, GAS 2, GAS 1, AIR. All four fittings accept 3/16 inch ID tubing.

  • Page 11: Power And Network Connections (Back Panel)

    USB PC Connector A type B USB connection allows for the SDM-3R to be connected to a PC using a Type A to Type B USB cable. Connection to a PC is necessary for setting up the LAN function and for using the SDM- 3R in its PC controlled configuration.

  • Page 12: Air Filter And Exhaust Tubing

    SDM-3R’s power jack. A screw included with the SDM-3R allows you to secure the plug to the SDM-3R’s jack if desired. The AC adapter is rated 100 - 240 VAC input, 5.99 VDC 2 A output.

  • Page 13: Standard Accessories

    USB Cable A Type A to Type B USB cable is used to connect the SDM-3R to a PC which is required for setting up the LAN connectivity function of the SDM-3R or for using the SDM-3R in the PC Controlled configuration.

  • Page 14: Wall Mounting Brackets

    Wall Mounting Brackets The SDM-3R can be mounted to the wall, if desired, using 2 mounting brackets. See “Wall Mounting the SDM-3R, Optional” on page 17 for a description of how many wall mounting brackets are needed depending on how many SDM-3Rs are in your system.

  • Page 15: Chapter 3: Mechanical Setup Of Sdm-3R

    Unscrew the two screws that retain the panel on the right side of the station. The screws are not captive. Be sure not to lose them. b. Pull the panel away from the SDM-3R. c. Use needle nosed pliers to remove the clear plugs that are installed in the four mating sample fittings.
  • Page 16 (Optional) Use the metal connection brackets and screws (sold separately) to secure the two connection points on the bottom of the SDM-3R to each other. Figure 9: Connecting SDM-3Rs Together...

  • Page 17: Hardware Assembly

    Insert the plug on the end of the AC adapter’s output cable into the power jack on the back of the SDM-3R. If desired, use the screw provided in the bag with the particle filter to secure the AC adapter to the SDM-3R.
  • Page 18 Total # of wall mounting # of SDM-3Rs brackets necessary 1 SDM-3R 2 wall mounting brackets 2-4 SDM-3Rs 4 wall mounting brackets 5-7 SDM-3Rs 6 wall mounting brackets Figure 10: Wall Mounting 1-7 SDM-3Rs 18 • Chapter 3: Mechanical Setup of SDM-3R...
  • Page 19 8-10 SDM-3Rs 8 wall mounting brackets Figure 11: Wall Mounting 8-10 SDM-3Rs If you are mounting multiple SDM-3Rs, be sure your SDM-3Rs are properly connected and secured to each other. Chapter 3: Mechanical Setup of SDM-3R • 19...

  • Page 20: Installing The Cylinder Holder, Optional

    They have a short section and a long section. The short section has a smaller hole than the long section. Screw the short section into the SDM-3R making sure that the long section goes away from the station and is flush with the back of the SDM-3R.

  • Page 21: Connecting Calibration Gas

    A cylinder of zero emissions air b. A fresh air area GAS 1, Recommended Gases RKI Instruments, Inc. recommends using one of the following for the GAS 1 fitting: a. A 4-gas mix (LEL/O /CO/H S) for GX-3R (Pro)s that have an H S sensor b.
  • Page 22 If testing different GX-3R (Pro) combinations at once requires more than 3 cylinders, you can assign a channel to CHG 3 in the SDM-3R’s Configuration Menu and the SDM will prompt you to change cylinders during a bump test or calibration. You cannot change cylinders more than once during a test.
  • Page 23 Install the demand flow regulator(s) on the calibration gas cylinder(s). NOTE: Do not connect pressurized gas directly to the SDM-3R. Be sure to install a demand flow regulator on the cylinder before connecting it to the SDM-3R. Connect the demand flow regulator to the appropriate inlet fitting using 3/16 inch ID sample tubing.

  • Page 24: Chapter 4: Parameter Setup In Sdm-3R's Config Menu

    10% - 50% in Tolerance 1% increments Automatic Calibration AUTO CAL AUTO CAL • • Fast Bump FASTBUMP FAST BUMP • • Alarm Check ALARM C ALARM • • CHECK 24 • Chapter 4: Parameter Setup in SDM-3R’s Config Menu...
  • Page 25 • at Instrument Turn On Pre-Sample Flush Time (AIR FL/AIR FLUSH) The pre-sample flush time is the length of time that the SDM-3R will draw air through the AIR fitting before performing an air adjust operation. NOTE: If the GX-3R (Pro) is not on for 40 seconds before a bump test is initiated, air will flow until the GX-3R (Pro) has been on for 40 seconds regardless of the time selected here.
  • Page 26 EXPIRED) If BUMP EXP/BUMP EXPIRED is set to On and if the connected GX-3R (Pro) is due for a bump test, the SDM-3R will automatically perform a bump test on all channels when the GX-3R (Pro) is connected. If BUMP EXP/BUMP EXPIRED is set to Off, an automatic bump test will not be performed, even if the GX-3R (Pro) is due for one.
  • Page 27 Automatically Bump Test at Instrument Turn On (AUTO EXE/ AUTO EXEC) If AUTO EXE/AUTO EXEC is set to On, the SDM-3R will automatically perform a bump test on all channels when the GX-3R (Pro) is connected, regardless of whether it’s due for bump testing.
  • Page 28 10 . When you are done setting the parameters, press BUMP  until DECISION appears. The SDM-3R returns to the Configuration Menu. 11 . To exit the Configuration Menu and return to the main screen, scroll to ESCAPE and press and release EDIT ENTER. 28 • Chapter 4: Parameter Setup in SDM-3R’s Config Menu...

  • Page 29: Calibration Parameters

    • • Pre-Sample Flush Time (AIR FL/AIR FLUSH) The pre-sample flush time is the length of time that the SDM-3R will draw air through the AIR fitting before performing an air adjust operation. NOTE: If the GX-3R (Pro) is not on for 40 seconds before a calibration is initiated, air will flow until the GX-3R (Pro) has been on for 40 seconds regardless of the time selected here.
  • Page 30 GX-3R (Pro) is due for one. Automatically Calibrate at Instrument Turn On (AUTO EXE/ AUTO EXEC) If AUTO EXE/AUTO EXEC is set to On, the SDM-3R will automatically perform a calibration on all channels when the GX-3R (Pro) is connected. Manual Calibration (MANUAL C/MANUAL CAL) If MANUAL C/MANUAL CAL is set to On, a calibration can be initiated by pressing the CAL ...
  • Page 31 Use BUMP  and CAL  to scroll through the calibration parameter settings. AIR FLUSH GAS TIME AIR PURGE ALARM CHECK CAL EXPIRED AUTO EXEC %LEL 25.0 vol% 12.0 2.50 MANUAL CAL DECISION TRANSMIT Chapter 4: Parameter Setup in SDM-3R’s Config Menu • 31...

  • Page 32: Gas Cylinder Assignments

    , etc.) are generally assigned to GAS 2 and GAS 3. Your SDM-3R will only have as many gas inlet choices as it has solenoid valves. For example, an SDM-3R with only one solenoid valve will only have G1/GAS1, C1/CHG1, and OFF as a choice. A gas cylinder can only be changed once during a test.
  • Page 33 Close the red door. The GX-3R (Pro) will automatically turn on and connect to the SDM-3R. %LEL 25.0 vol% 12.0 2.50 TRANSMIT Press the EDIT ENTER button. If Password is set to on (factory setting is off), you will be prompted for a password.

  • Page 34: Date And Time

    It is important to update the SDM-3R’s date/time to match your time zone. The SDM-3R automatically updates the date/time in a connected GX-3R (Pro) to match the SDM-3R’s date/time. If the date/time in your SDM-3R is not correct and you connect your GX-3R (Pro), the date/time in the GX-3R (Pro) will no longer be correct.
  • Page 35 Close the red door. The GX-3R (Pro) will automatically turn on and connect to the SDM-3R. %LEL 25.0 vol% 12.0 2.50 TRANSMIT Press the EDIT ENTER button. If Password is set to on (factory setting is off), you will be prompted for a password.

  • Page 36: Password

    Press the POWER button to turn on the SDM-3R. Install the GX-3R (Pro) into the SDM-3R’s instrument cradle. Be sure the yellow lever is up for a GX-3R and down for a GX-3R (Pro). 36 • Chapter 4: Parameter Setup in SDM-3R’s Config Menu...
  • Page 37 Close the red door. The GX-3R (Pro) will automatically turn on and connect to the SDM-3R. %LEL 25.0 vol% 12.0 2.50 TRANSMIT Press the EDIT ENTER button. If Password is set to on (factory setting is off), you will be prompted for a password.
  • Page 38 10 . To return to the Configuration Menu, scroll to ESCAPE and press and release EDIT ENTER. 11 . To exit the Configuration Menu and return to the main screen, scroll to ESCAPE and press and release EDIT ENTER. 38 • Chapter 4: Parameter Setup in SDM-3R’s Config Menu...

  • Page 39: Setting Up Lan Connectivity

    Extract the contents of the .zip file. Double click the setup.exe file. The SDM-3R Docking Station PC Controller InstallShield Wizard comes up to guide you through installation. Follow the InstallShield Wizard instructions. 10. A Device Driver Window will appear prompting you to install necessary drivers. You cannot continue the installation without installing the drivers.

  • Page 40: Making Detailed Parameter Changes In The Sdm Window

    14. Turn on the docking station pressing the POWER button. 15 . The first time an SDM-3R is turned on after being connected to the computer, the SDM-3R needs some time to be recognized by the computer. The status bar will indicate that the drivers are being configured and will alert you when the SDM-3R is ready to use.
  • Page 41 If you are starting the software for the first time, a message window appears informing you that a database has been created. Click OK in that window. Connect the SDM-3R to a PC using the SDM-3R’s PC port and a Type A to Type B USB cable.
  • Page 42 Right click on the SDM-3R icon and select Open (SDM)S. The SDM Window appears. Figure 16: SDM Window Click the Bump & Cal 2 tab. Figure 17: SDM Window, Bump & Cal 2 Tab Make the desired changes in the Data Logger section.
  • Page 43 GX-3R (Pro) if Auto Download is set to Interval. If the GX-3R (Pro) is connected to an SDM-3R before the interval has passed, a data download will not automatically occur. The Interval can be set anywhere from 1 to 60 days. The factory setting is 1 day.

  • Page 44: Setting Up Lan Connectivity

    (Pro) is installed in an SDM-3R at the specified day/time, the SDM-3R will turn on the GX-3R (Pro), perform the test, then turn off the GX-3R (Pro). 12 . Click SDM Update and Yes in the window that appears to save the changes to the SDM-3R. Setting Up LAN Connectivity Connecting the SDM-3R to a LAN network allows you to download test data from the SDM-3R’s...
  • Page 45 Click OK in that window. Connect the SDM-3R to the network port closest to its installed location using the SDM-3R’s LAN port and an Ethernet cable. Be sure to connect all SDM-3Rs you plan on having connected to the LAN network.
  • Page 46 Click Net Import. Figure 20: Net Import Window Click Search. The program will find any SDM-3Rs that are connected to the same network as the PC you are using. 46 • Chapter 5: Detailed Parameter and LAN Setup in PC Program...
  • Page 47 Figure 21: Net Import Window with Found SDM-3Rs 10 . If you would like to rename an SDM-3R to describe its location or some other defining parameter in more detail, click on the desired SDM-3R and then click Edit. Type in the desired name for the SDM-3R.
  • Page 48 Click OK in that window. Connect the SDM-3R to a PC using the SDM-3R’s PC port and a Type A to Type B USB cable. The SDM-3R does not need to be installed in its intended location or connected to the network in order to set up the LAN connectivity.
  • Page 49 Figure 24: Internal Tab Be sure DHCP is deselected. Enter an IP Address, SubNet Mask, and Default Gateway for the SDM-3R. 10 . Click SDM Update and click Yes in the window that comes up. 11 . Turn the SDM-3R off and then on again before continuing.
  • Page 50 12 . Click the Logs button. Figure 25: Logs Window 13 . Click Net Import. Figure 26: Net Import Window 50 • Chapter 5: Detailed Parameter and LAN Setup in PC Program...
  • Page 51 14 . Click Add. Figure 27: Add Window 15 . Enter a name for the SDM-3R and enter the IP Address that you assigned to the SDM-3R in the Internal Tab of the SDM Configuration Window. 16 . Click OK. The newly added SDM-3R will appear.

  • Page 52: Chapter 6: Operation

    Chapter 6: Operation Overview The SDM-3R is capable of performing bump tests, calibrations, and alarm checks on the GX-3R (Pro). It can also charge the rechargeable Li-ion battery pack in the GX-3R (Pro). This chapter describes procedures for using the docking station to bump test, calibrate, alarm check, download instrument logger data to a USB drive, and recharge GX-3R (Pro)s.

  • Page 53: Bump Testing

    SDM-3R. Bump Testing When a bump test is performed, the SDM-3R performs a fresh air adjustment on a GX-3R (Pro) and then applies calibration gas to the instrument. The docking station then analyzes the response and determines if the instrument passed the bump test based on the bump test check tolerance setting (see pg.
  • Page 54 SDM-3R’s pump will keep running. 11 . The SDM-3R will analyze the results after the end of each gas application. If the bump test fails and AUTO CAL is set to ON, the gas will keep flowing and a calibration will automatically begin.
  • Page 55 13 . If the ALARM CHECK bump test parameter is set to ON, an alarm check will begin. The buzzer will sound, the LEDs will turn on for a few seconds, and the SDM-3R will determine if these actions were completed successfully.

  • Page 56: Calibration

    If a flow failure occurs, confirm all tubing connections are correct, that all lines are clear, and that the GX-3R (Pro) is correctly installed in the SDM-3R. A pre-sample flush will begin. The SDM-3R will apply fresh air to the GX-3R (Pro) for the time defined by the AIR FLUSH calibration parameter.
  • Page 57 If the air adjustment is successful, the SDM-3R will continue as described in step 10 below. b. If one or more of the sensors fails the fresh air adjustment, the SDM-3R will abort the calibration and will not apply calibration gas. The LCD will indicate which channels passed and failed the fresh air adjustment.

  • Page 58: Alarm Check

    Turn on the SDM-3R system as described in “Turning on an SDM-3R System” on page 52. NOTE: The GX-3R (Pro) must be on for instrument data to be downloaded to a USB drive. Insert a USB drive into the USB port on the front of the SDM-3R. The COPY LED will begin to flash. NOTE: If a USB drive is not installed, then instrument data cannot be downloaded.

  • Page 59: Copying Bump Test, Calibration, And Alarm Check Records

    SDM-3R’s memory is full, the oldest record is overwritten when a new record is saved. One .txt file per GX-3R (Pro) is saved in the SDM-3R memory. The file includes results for all tests done while the GX-3R (Pro) is installed in the SDM-3R. The file name will begin with “SDM3R” and the remainder of the file name will depend on the serial number of the tested GX-3R (Pro) and the date of the most recent testing (i.e.

  • Page 60: Chapter 7: Maintenance

    Chapter 7: Maintenance Troubleshooting NOTE: This troubleshooting guide describes SDM-3R problems only. See the GX-3R (Pro) Operator’s Manual for problems you may encounter with the GX-3R (Pro). Table 6: Troubleshooting the SDM-3R Symptoms Probable Causes Recommended Action Fresh air adjustment fails •...

  • Page 61: Charging A Gx-3R (Pro)

    Instruments, Inc. for further instruction. Charging a GX-3R (Pro) The SDM-3R can be used to charge the rechargeable Li-ion battery pack in a GX-3R (Pro) equipped with one. To maximize the GX-3R (Pro)’s run time and the battery life, make sure the battery pack’s charge is as low as possible before recharging it.
  • Page 62 If the battery pack is drained enough for the docking station to charge it, the CHARGE LED will continue to blink orange while charging is taking place. The SDM-3R will take approximately 3 hours to charge a fully discharged GX-3R (Pro).

  • Page 63: Chapter 8: Importing Data Into The Pc Program

    Insert the USB drive into USB slot on your computer. Click Start on the Windows Icon Tray, then select Programs/SDM-3R. You may also double click the shortcut created on your desktop. The PC Program is launched and the main program window appears.
  • Page 64 Figure 30: Main Program Window 64 • Chapter 8: Importing and Viewing Data...
  • Page 65 Click the Logs button to display the Logs Window. Figure 31: Logs Window Click the USB Import button. Chapter 8: Importing and Viewing Data • 65...
  • Page 66 Select the types of data you want to import. Test Data is data from bump tests, calibrations, and alarm checks done with the SDM-3R (in either Standalone or PC Controlled Mode) and is saved as a .txt file. It will not include data from tests done away from the SDM-3R.

  • Page 67: Importing Using The Lan Network

    Importing Using the LAN Network Importing data using the LAN network allows you to import test data (.txt files) from the SDM-3R(s) on the network. You cannot import downloaded logger data using the LAN network. Before you try to import data using the LAN network, be sure that the LAN connectivity for the SDM- 3R(s) was set up as described in “Chapter 5: Detailed Parameter and LAN Setup in PC Program”...
  • Page 68 LAN Setup in PC Program” on page 39 will appear. Figure 35: Net Import Window Select the SDM-3R(s) whose files you want to import or use the Check All box to select all of 68 • Chapter 8: Importing and Viewing Data...

  • Page 69: Viewing Imported Data

    If the data import is not successful, you may need to set up the LAN connectivity again. For users with a DHCP network, if the SDM-3R lost power or the network went down for a period of time, a new IP address may have been assigned to the SDM-3R when power was restored or when the network came back up.

  • Page 70: Chapter 9: Spare Parts List

    Ethernet cable, black, 5 ft. 49-0133 Single-station AC adapter 49-0134 Multi-station AC adapter 71-0487 Operator’s Manual, SDM-3R Docking Station Standalone Configuration (this document) 71-0488 Operator’s Manual, SDM-3R Docking Station PC Controlled Configuration 81-0012RK-01 Calibration cylinder, 50 %LEL CH in air, 34 liter steel...
  • Page 71 Table 7: Spare Parts List Part Number Description 81-0076RK-03 Zero air cylinder, 103 liter 81-0090RK-01 Calibration cylinder, 3-gas (50% LEL CH /12% O /50 ppm CO), 34 liter steel 81-0090RK-03 Calibration cylinder, 3-gas (50% LEL CH /12% O /50 ppm CO), 103 liter 81-0142RK-02 Calibration cylinder, 5-gas (CH S/CO/SO...
