Summary of Contents for Hyundai HYSC210
-
Page 2: Table Of Contents
INDEX CONTENTS PAGE NO.S SAFETY 3 - 8 PART LOCATIONS ASSEMBLY 10 - 11 STARTING PROCEDURE 12 - 13 STOPPING PROCEDURE USING THE MACHINE 14 - 15 MAINTENANCE 16 - 19 STORAGE TROUBLE SHOOTING 21 - 22 SPECIFICATION RECYCLING & PRODUCT DISPOSAL DECLARATION OF CONFORMITY CONTACT DETAILS WARRANTY... -
Page 3: Safety
1. SAFETY General Safety Notes. The operator of the machine is responsible for, and has a duty of care in making sure that the machine is operated safely and in accordance with the instructions in this user manual. Keep the manual safe and pass it on if the machine is loaned or sold to another user. - Page 4 1.10 Carbon Monoxide (where applicable). 1.11 Carbon monoxide is a colourless and odourless gas. Inhaling this gas can cause death as well as serious long term health problems such as brain damage. 1.12 The symptoms of carbon monoxide poisoning can include but are not limited to the following;...
- Page 5 1.20 General Fuel Safety (where applicable). CAUTION ALL FUELS ARE FLAMABLE Fire Hazard – keep fuel away from all sources of ignition for example heaters. 1.21 Lamps, sparks from grinding or welding. 1.22 DO NOT carry out hot work on tanks that have contained fuel. 1.23 ALWAYS keep the work area tidy.
- Page 6 1.46 All trailing cables should be routed so as not to cause any kind of trip hazard. 1.47 NEVER work on or near electricity with wet hands, wet clothing and wet gloves. 1.50 Batteries (where present). 1.51 Batteries present a risk if they become damaged by the possible leaking of electrolyte.
- Page 7 recommended to observe the condition of your hands and fingers. Seek medical attention immediately if any of the above symptoms should occur. 1.70 Noise (where applicable). 1.71 The operating noise of the machine can damage your hearing. Wear hearing protection such as earplugs or ear defenders to protect your hearing. Long-term and regular users are advised to have hearing checked regularly.
- Page 8 1.92 NEVER allow children or anyone unable to fully understand the directions given in this manual to operate this product. 1.93 Make sure you keep this manual handy so you may refer to it whenever questions arise and ensure you pass this manual on if the machine is loaned or sold. 1.94 Correct Personal Protective Equipment (PPE) MUST be worn at all times when operating or repairing this machine.
-
Page 9: Part Locations
2. PART LOCATIONS Soft Grip Handle Working Depth Height Adjustment Knob Operator Presence Control Lever Wheels Handle Quick Release Grass Catcher Exhaust Recoil Starter Handle Fuel Filler Cap Transport Lever Oil Filler/Dipstick... -
Page 10: Assembly
3. ASSEMBLY CAUTION For OUTDOOR use ONLY. Petrol machinery produces carbon monoxide – a poisonous, colourless and odourless gas that can cause serious injury or death. Petrol is highly flammable, always handle with extreme care and in a well ventilated area. - Page 11 Lift the rear discharge flap and hook the grass catcher over the back of the scarifier (1). Manoeuvre the grass collector into position ensuring it is hooked firmly in place (2). Lower the rear discharge flap until it rests on the grass collector (3). Attach the cable clamp around the cable and fix to the handlebar (1).
-
Page 12: Starting Procedure
4. STARTING PROCEDURE NOTE This machine is shipped without fuel and oil and MUST be filled before use. Failure to do so may cause damage to the engine that will not be covered by warranty. Oil: 600ml SAE 15w40 Semi Synthetic Engine Oil Fuel: 3.6L Straight Unleaded Petrol CAUTION ALL FUELS ARE FLAMMABLE... -
Page 13: Stopping Procedure
Set the engine speed to the desired level for the job in hand (1). WARM START Repeat the cold start procedure but leave the choke in the ON position. 5. STOPPING PROCEDURE Allow the machine to run at idle for 20 seconds. Release the Operator Presence Control Lever (1). -
Page 14: Using The Machine
6. USING THE MACHINE CAUTION Do not make any adjustment to the scarifier without stopping the engine first. NOTE Check the oil level before operation. The scarifier is equipped with a working depth adjustment lever offering multiple working depths. The working depths are: -3mm -6mm -9mm -12mm... - Page 15 Never work barefooted or with open shoes or sandals. 5.10 Do not operate the engine in a confined space where dangerous carbon monoxide fumes can collect. 5.11 Use only in daylight. 5.12 Avoid operating the equipment in wet grass. 5.13 Always be sure of your footing on slopes WALK, never run.
-
Page 16: Maintenance
7. MAINTENANCE WARNING ALWAYS stop the engine, disconnect the spark plug HT lead and allow the engine to cool completely BEFORE carrying out any maintenance or repairs. NEVER touch a rotating blade. Check and maintain the oil and fuel level every use. Frequently check the scarifier and make sure that all deposits are removed before use. - Page 17 0.28” to 0.31” 0.700mm to 0.80mm Refit the cleaned and adjusted speak plug by hand to avoid cross threading then lightly tighten with a plug spanner. Re-attach the spark plug HT lead cap. AIR FILTER CAUTION A dirty air filter will restrict the air flow to the carburetor, which will reduce engine efficiency.
- Page 18 6.15 Refit the air filter and replace the air filter cover. FUEL & CARBURETOR CAUTION ALL FUELS ARE FLAMABLE ALWAYS fuel and defuel in a well ventilated area outside of buildings. ALWAYS wear correct, suitable and fit for purpose Personal Protective Equipment (PPE), suggested items are but not limited to safety gloves, overalls.
- Page 19 6.23 Undo the 4 bolts on the side of the machine (1). 6.24 Remove the shaft securing bracket and slide the blade out in the direction of the arrow (2). 6.25 To reinstall, slide one end of the blade into the hexagonal locating socket (1). 6.26 Refit the shaft securing bracket and bolt back in to place (2).
-
Page 20: Storage
8. STORAGE NOTE If you plan to store the machine for periods of longer than 30 days follow the procedure outlined below. Failure to do so may result in poor starting or other machine issues. Always allow the machine to cool completely before placing in to storage. Follow the maintenance procedure as outlined in section 7 of this user manual. -
Page 21: Trouble Shooting
9. TROUBLE SHOOTING Possible Cause Problem Remedial action Move throttle choke to correct Engine does not start Throttle choke is not in the position. correct position Fuel tank is empty. Fill tank with fuel: refer to ENGINE OWNERS MANUAL. Air cleaner element is dirty. Clean air cleaner element: refer to ENGINE OWNERS MANUAL. -
Page 22: Specification
10. SPECIFICATION Model HYSC210 Engine Type Single Cylinder OHV Engine Size 210cc Nominal Power Engine Speed 2800rpm Fuel Tank Capacity 3.6L Fuel Type Unleaded Petrol Oil Tank Capacity 600ml Oil Type SAE 15W40 Semi Synthetic Engine Oil Working Width 400mm... -
Page 23: Recycling & Product Disposal
11. RECYCLING & PRODUCT DISPOSAL We do not offer a takeback scheme for the recovery of Waste Electrical Electronic Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and or Batteries is passed onto you by So when it becomes necessary to dispose of your machine you must take it to your local Civic Amenity Site. -
Page 24: Declaration Of Conformity
12. DECLARATION OF CONFORMITY Genpower Ltd confirms that these Hyundai products conform to the following CE Directives. 2006/42/EC Machinery Directive 2004/108/EC EMC Directive 2000/14/EC, Amended by 2005/88/EC Noise Emissions Directive 97/68/EC_2010/26/EC NRMM Emissions Directive... -
Page 25: Contact Details
13. CONTACT DETAILS POSTAL ADDRESS Genpower Ltd, Isaac Way, London Road, Pembroke Dock, Pembrokeshire. SA72 4RW. UK. TELEPHONE +44 (0) 1646 687880 +44 (0) 0164 686198 TECHNICAL EMAIL aftersales@genpower.co.uk WEBSITE www.hyundaipowerequipment.co.uk 14. WARRANTY 10.0 To register your machine for the manufacturer's warranty, please visit https://www.hyundaipowerequipment.co.uk/warranty 15.
