17.4. Advanced wireless module, communication via radio or serial
data cables
If the device has been equipped with the Advanced wireless module it can be controlled by the
Galaxis controllers PFS Profi and PFC Advanced. Remote data requests and remote programming is
only possible if the G-Flame is used in conjunction with the PFC Advanced.
When the wireless module is installed remote data requests and remote programming is also possible
with the wireless USB modem together with the Composer software from any PC or notebook.
The operation of the G-Flame together with the Advanced wireless module is described in more detail
in the section 'menu' in this manual
If the wireless module is installed the G-Flame can also communicate with the PFC Advanced via
serial data cables. The connection is established by using the DMX jacks and the DMX interface which
in principle works as a so called RS485 interface. Please refer to the manual of the controller PFC
Advanced and the receiver PFE Advanced regarding network topography and operation.
If the cable interface has been selected in the menu of the G-Flame the pin assignment of the 5pin
male and female XLR connectors is as follows:
The pin assignment is as follows:
Pin1 = Shielding for serial data cable, to be connected with the shielding of the cable
Pin2 = Serial data cable, Signal -
Pin3 = Serial data cable, Signal +
Pin4 = unassigned but connected between the male and female jack
Pin5 = unassigned but connected between the male and female jack
A connection diagram is printed on the housing of the G-Flame.
Upon request you will be able to receive customized data cables if you provide us your requirements.

18. Switching on

The G-Flame can only be operated if the emergency switch is closed. If you want to use the device
without emergency switch you can plug in the supplied XLR connector which is bridging the contacts
of the emergency switch before you put the device into operation. In principle the main switch and the
emergency switch are wired in series.
To switch on the G-Flame press the main switch which you will find on the side of the device where
the display is.
Firstly on the LCD the start screen and the firmware version is being displayed:
Galaxis
PYROTEC
Right after that the safety timer is started, unless a warning message is being displayed that the
battery has been deeply discharged.
30
G-Flame
Firmware V2.3
