16.2. Safety distances if gas cartridges are being used,
device standing vertically
Nozzle size
approx. 1.5 m
-20 to -10°C
approx. 2.0 m
-10 to 0 °C
approx. 2.5 m
0 to 10 °C
approx. 3.0 m
10 to 20 °C
approx. 3.5 m
20 to 30 °C
approx. 4.0 m
30 to 40 °C
Marking in cyan color = Expected effect height if valves are opened for 1.5 seconds if G-Flame is
standing vertically
Marking in yellow color = Recommended safety distance upwards to persons, animals or flame
retardant objects
Marking in green color = Recommended safety distance sideways to persons, animals or flame
retardant objects
It can be necessary to increase the safety distance to uninvolved persons significantly also to ensure
that these people do not become frightened and do not show panic reactions. Our recommendation is
here a safety distance of at least 5 m sideways.
16.3. Safety distances if the device is being tilted
It is also possible to mount the device in a tilted orientation. If gas bottles are being used we
recommend a maximum tilt angle of 45° sideways. When operated with gas cartridges the maximum
tilt is 75° sideways.
If the device is operated with a tilt angle the safety distances sideways in the direction of the tilt angle
should be increased according either to the operator's judgment or to the guidelines of the authorities.
Possibly the safety distances on the other side can be reduced, but we recommend to keep at least a
minimum distance of 2.0 m.
We recommend to keep the minimum safety distance upwards to people, animals and flame retardant
materials if the device is being tilted because due to the thermal lift the same amount of heat will
ascent.
S
M
approx. 2.0 m
3.5 m
4.0 m
2.0 m
2.0 m
approx. 2.5 m
4.0 m
4.5 m
2.0 m
2.0 m
approx. 3.0 m
4.5 m
5.0 m
2.0 m
2.5 m
approx. 3.5 m
5.0 m
5.5 m
2.5 m
2.5 m
approx. 4.0 m
5.5 m
6.0 m
2.5 m
2.5 m
approx. 4.5 m
6.0 m
6.5 m
2.5 m
3.0 m
25
L
approx. 2.5 m
approx. 3.0 m
4.5 m
2.0 m
approx. 3.0 m
approx. 3.5 m
5.0 m
2.5 m
approx. 3.5 m
approx. 4.0 m
5.5 m
2.5 m
approx. 4.0 m
approx. 4.5 m
6.0 m
2.5 m
approx. 4.5 m
approx. 5.0 m
6.5 m
3.0 m
approx. 5.0 m
approx. 5.5 m
7.0 m
3.5 m
XL
XXL
approx. 3.5 m
5.0 m
5.5 m
2.5 m
2.5 m
approx. 4.0 m
5.5 m
6.0 m
2.5 m
2.5 m
approx. 4.5 m
6.0 m
6.5 m
2.5 m
3.0 m
approx. 5.0 m
6.5 m
7.0 m
3.0 m
3.5 m
approx. 5.5 m
7.0 m
7.5 m
3.5 m
4.0 m
approx. 6.0 m
7.5 m
8.0 m
4.0 m
4.5 m
