Team Losi XXX-NT Sport Ready-to-Run Getting Started

NOTE:
Before you start running your XXX-NT Sport Ready-to-Run, read your engine break-in and operating
instructions. If you run your XXX-NT Sport without following proper break-in procedure, you may dam-
age or fail to get maximum performance from your engine, and void warranty.
Radio Batteries
1
Refer to Figure 91 in the Owners Manual to install
the radio antenna on the truck. Install the radio
system batteries, 8 in the bottom of the transmitter and
4 into the back of the model as shown. Use only quality
alkaline or rechargeable Ni-Cad AA-size cells.
Ignitor Battery
+ Pos
3
Remove the cover from the glow plug ignitor.
Install a "C" size alkaline battery with the "+" end
of the battery as shown in the figure above.
Getting Started
Getting Started
- Neg
Fueling
Spin Start Battery Install
2
Slide back the battery access panel opposite the hand strap and
remove the cover. Remove hex starter shaft from the back side
of the cover (fig 2a.) and press the o-ringed end into the drive
cup. Slide a 7.2 volt 6 cell "stick pack" into the Spin-Start and
plug it in. Note that the plug is made such that it can be plugged
in one way. Carefully tuck the plug wires under the battery ac-
cess panel and slide shut.
Operations Check
Steering
Throttle
Brake
Always turn the transmitter "on" first and check the display screen
for adequate voltage. Turn on the model and check both the
throttle and steering for proper operation and battery power.
5
Lift the lid of the fuel tank, place the tube of the
fuel bottle into the opening and carefully fill the
tank. Do not allow fuel to overflow as spilled fuel
can cause radio damage.
2A
4
Steering
Throttle
Brake
