HuddleCamHD HuddleView Installation & Operation Manual

Auto framing camera
Hide thumbs Also See for HuddleView:

Advertisement

Quick Links

HuddleCamHD
HuddleView
Auto Framing Camera
Installation & Operation Manual
Ver. 1.1 – 4-19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HuddleView and is the answer not in the manual?

Questions and answers

Summary of Contents for HuddleCamHD HuddleView

  • Page 1 HuddleCamHD HuddleView Auto Framing Camera Installation & Operation Manual Ver. 1.1 – 4-19...
  • Page 2: Table Of Contents

    Table of Contents Precautions.…………………..………………………………………………….………..……………..………..……………… Page 3 Safety Tips…………………..……………..……………..……………..……………..……………..……………... Page 3 What’s in the Box……………..……………..………..…..……………..……………..……………..……………………… Page 3 Physical Descriptions.…………………..………………………………………………….………..……………..…………. Page 4 Front View of Camera……………..……………..……………..……………..……………..…………………………. Page 4 Rear View of Camera……………..………………..……………..……………..……………..……………………… Page 5 Basic Connection Instructions.…………………..………………………………………………….………..…………… Page 6 Network setup……………..……………..……………..……………..……………..……………..……………..….….. Page 6 Connections……………..……………..……………..……………..……………..……………..………………..…...
  • Page 3: Precautions

    • After long term operation, moving components can wear down. Contact your authorized dealer for repair. What’s in the Box Supplied Hardware • 12X HuddleView Camera • Power Supply • 3m / 9.8’ USB 3.0 A-B Cable • User Manual •...
  • Page 4: Physical Descriptions

    Physical Descriptions Front View of Camera 1. Tracking Camera Head 2. Tracking Camera Lens 12X Optical Zoom Field of View: 6.3°(Tele) ~ 72.5° (Wide) 3. Reference Camera Body 4. Reference Camera Lens Fixed 2.4mm Lens Field of View: 86° (Horizontal) / 52° (Vertical) Ver.
  • Page 5: Rear View Of Camera

    Back of the Camera 1. Audio Line in a. Embeds over IP Stream 2. Network Connection a. Allows for software connection & RTSP/RTMP Streaming 3. DVI-D Connection 4. 3G-SDI Connection 5. VISCA Connection a. Allows for joystick control of camera 6.
  • Page 6: Basic Connection Instructions

    2. Connect the included Power Supply to the camera. 3. Wait for camera to come to Home Position. 4. Install the HuddleView software on your Windows PC on the same network as the camera 5. Open the HuddleView software to connect to your camera Note: To pull the main RTSP stream please use the following URL rtsp://<camera ip>:<rtsp port>/main.h264...
  • Page 7: Interface Descriptions

    Interface Descriptions Tracking Software Device Management Interface Device Management interface Add selected camera from Online Device section Video configuration interface Modify network settings of selected Online Device Manually add device using IP address, Port Refresh Online Device list number, Username & Password Delete selected device from Device 10 Start/Stop searching for Online Devices Management list...
  • Page 8 Video Configuration Interface Cameras connected to Device Management Preset control Camera video feed Enable/Disable tracking PC performance & time Open tracking settings Pan, Tilt, & OSD Menu control 10 Connected camera resolution & frame rate Lens control 11 Enable/Disable recording OSD Menu enter/return 12 Stop video, full screen, and gallery view Ver.
  • Page 9: Connect Camera

    When utilizing the Online Device section, you can simply click Search, and the Tracking Software will automatically search your network for any HuddleView & SimplTrack2 cameras. Select the camera and click + Add to Client to add it to the Device Management list.
  • Page 10: Network Configuration

    Network Configuration To configure the network settings, select the from the Online Device list and click Modify Netinfo. You can also adjust the network settings of a connected camera by selecting it from the Device Management list and clicking Remote Configuration, then traversing to the Network section. Remote Configuration Remote Configuration includes: Streaming, Network, RTMP, Protocol, Upgrade, &...
  • Page 11 Remote Configuration (Continued) The Network category allows you to assign a dynamic or static IP address for the camera, in addition to settings the port numbers for RTSP & control. The RTMP category allows you to define a RTMP server. The Protocol category allows you to set the control parameters of the camera.
  • Page 12 Remote Configuration (Continued) The Upgrade category allows you to upgrade the firmware of the camera. The Username/Password category allows you to change the device name, password, and adjust the time format. Ver. 1.1 – 4-19...
  • Page 13: Remove Camera

    Remove Camera To remove a camera from the Device Management list, first select it, then click the Delete button above the list. You will be prompted with a confirmation window to remove the camera. Click OK to remove the device or Cancel to keep the current settings. Ver.
  • Page 14: Configure Video Settings

    Configure Video Settings In the Video Interface you can view and control up to four cameras simultaneously. You have full control over Pan, Tilt, Zoom, Focus, Iris, OSD Menu, Presets & Tracking Settings. You must first select one of the cameras from the video feed in order to adjust the settings. Ver.
  • Page 15 Configure Tracking Settings To adjust the Tracking Parameters of the selected camera, you must click the Settings button in the tracking control area. Once opened, you can add and remove tracking & blocking zones, change video resolution & frame rate, baud rate, control protocol, device address, and correct the position of camera. Within Basic2 settings, you can enable or disable tilt, permanent track, auto zoom, &...
  • Page 16 Configure Tracking Settings (Continued) The Senior 1 settings tab is disabled and will be enabled with future updates. Senior 2 allows for network control via TCP or UDP and allows the camera to act as a server or client for receiving commands.
  • Page 17: On Screen Display (Osd)

    On Screen Display (OSD) <VIDEO> SHARPNESS 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 CONTRAST 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14 SATURATION 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14 2DNR OFF, ON...
  • Page 18: White Balance

    0, 1, 2, 3, 4, 5, 6, 7, 8, 9, BRIGHT BRIGHT 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27 -7, -6, -5, -4, -3, -2, -1, EXP- LEVEL 0, +1, +2, +3, +4, +5, COMP +6, +7 ON, OFF...
  • Page 19: Systems

    <SYSTEM> ADDRESS 1, 2, 3, 4, 5, 6, 7 PROTOCOL VISCA, PELCO-D FORMAT 1080p60/50/30/25, 1080i60/50, 720p60/50 RATIO SPEED OFF, ON PRESET FREEZE OFF, ON RS485 HALF-DUPLEX-1, HALF-DUPLEX-2 DISPLAY INFO OFF, ON <STATUS> SHOWS CURRENT SETTINGS OF CAMERA <RESTORE DEFAULTS> Ver. 1.1 – 4-19...
  • Page 20: Using The Ir Remote

    Using the IR Remote 1. HOME Button Press the HOME Button to send the camera to the initial position where pan and tilt is 0. 2. Camera Selection Button Use to switch between IR channels for multiple camera control. For example, 4 is address 4. 3.
  • Page 21 16. Direction/Menu Operation In OSD Menu: traverse OSD Menu Out of OSD Menu: pan & tilt camera 17. Preset Settings Use the Number Keys to input a preset number, then press call, store, clear to perform the corresponding command. 18. Enter After inputting numbers, press this button to confirm.
  • Page 22: Visca Commands

    VISCA Commands ACK/Completion Messages Command Messages Comments Returned when the command is accepted. z0 4y FF (y:Socket No.) Returned when the command has been executed. Completion z0 5y FF (y:Socket No.) Error Messages Comments Command Messages Returned when the command format is different or when a Syntax Error z0 60 02 FF command with illegal...
  • Page 23: Commands

    Commands Command Set Command Command Packet Comments AddressSet Broadcast 88 30 01 FF Address setting IF_Clear Broadcast 88 01 00 01 FF I/F Clear CommandCancel 8x 2p FF p: Socket No.(=1or2) CAM_Power 8x 01 04 00 02 FF Power ON/OFF 8x 01 04 00 03 FF CAM_Zoom Stop...
  • Page 24 Commands (Continued) Command Set Command Command Packet Comments CAM_AE Full Auto 8x 01 04 39 00 FF Automatic Exposure mode Manual 8x 01 04 39 03 FF Manual Control mode Shutter Priority 8x 01 04 39 0A FF Shutter Priority Automatic Exposure mode Iris Priority 8x 01 04 39 0B FF...
  • Page 25 Commands (Continued) Command Set Command Command Packet Comments CAM_IDWrite 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000 to FFFF) IR_Receive 8x 01 06 08 02 FF IR(remote commander) receive ON/OFF 8x 01 06 08 03 FF Information Display 8x 01 7E 01 18 02 FF ON/OFF of the Operation status...
  • Page 26: Inquiry Commands

    Inquiry Commands Inquiry Command Command Packet Inquiry Packet Comments CAM_PowerInq 8x 09 04 00 FF y0 50 02 FF y0 50 03 FF Off (Standby) y0 50 04 FF Internal power circuit error CAM_ZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqrs: Zoom Position CAM_FocusModeInq 8x 09 04 38 FF...
  • Page 27 Inquiry Commands (Continued) Inquiry Command Command Packet Inquiry Packet Comments CAM_VersionInq 8x 09 00 02 FF y0 50 00 01 mnpq: Model Code (0504) mn pq rs tu vw FF rstu: ROM version vw: Socket Number (=02) Information Display 8x 09 7E 01 18 FF y0 50 02 FF y0 50 03 FF VideoSystemInq...
  • Page 28: Tips & Tricks

    Tips and Tricks The “Stage”: Imagine your subject moving around within the available presentation space and take note of the extremes, left or right and up or down, your presenter may happen to present from. The area you have just noted is what we will call our stage and is what you want to ensure is captured by the reference camera.
  • Page 29: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Power supply failure Check power supply No movement or Power adapter damaged Replace power adapter image after power on Power cable connection is loose Check & reconnect Check & reconnect power cable No self-testing after Not enough power connection powered on, or with...
  • Page 30: Notes

    Notes Ver. 1.1 – 4-19...
