Loosely attach
lower handle to
frame using the
5/16-18 x .75
hex head cap
screws and
5/16-18 flange
lock nuts. Do
not tighten
hardware.
Attach upper
handle and handle
support brackets
to lower handle
using the 5/16-18
x 1.50 screws and
5/16-18 flange lock
nuts. Tighten all
hardware in Step 1
and Step 2.
21C-64M1 ©2008
IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND
Read and understand all instruction, warning, and danger labels.
Lea el manual de operación anexo sobre ensamblaje e inicio.
1
Forward
Clutch Cable
Upper Handle
Lower Handle
2
Call 1-888-TO-HELP-U
Need Help?
FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING.
3
Forward
Clutch Bail
Snap cable connector into
bottom hole in cable bracket.
Insert the
Z-fitting into
the hole in the
Handle Support
Forward Clutch
Brackets
Bail.
4
(1-888-864-3578)
778-11729
