Summary of Contents for SIM1 XT-1
- Page 1 Firmware 3.0...
- Page 2 balanced on/off & 9/12 V a. Learn & Play - automatic pickups matching (hold bypass + down) Set up your Source Guitar by recording Neck, Mid and Bridge position pickups. The system will automatically match the Target Guitar pickups with your Source Guitar pickups. interactive display b.
- Page 3 & Set-up your source guitar (automatic pickups matching). For a perfect guitar emulation the pedal must learn the tone of each pickup of the Source Guitar. With this procedure it will automatically make the matching between the Target and the Source Guitar pickups. 1.
- Page 4 Source Set Up Up to Next During the very first use, when XT-1 is reset, it’s possible to skip the Learning Down option Procedure, by holding for 3 seconds the DOWN and UP Switches.
- Page 5 Pickup Matching For each Guitar Profile Preset, while performing, it is recommended to switch the Pickup position of your Source Guitar to that one suggested on the display. This allows to reach a sound as close as possible to that one of the original Target Guitar.
- Page 6 Profile one pickup at a time (pickup matching through editor) This function allows to record more Source Guitar pickups, without modifying the previous configuration of the pedal. The matching between Target and Source Guitar pickups requires the use of the Editor for PC/Mac. Useful to: •...
- Page 7 This 1.2 Bypass (set the bank in bypass mode) feature allows to connect XT-1 directly to the PA or to 2. IR Cabinets (add an Impulse Response Cabinet Emulation) a powered speaker, and use it as a stand alone pedal.
- Page 8 How to Edit the Overdrive Section 1. Scroll up with the UP Switch until you reach the point 4 - Overdrive section; 2. Enter this section through the DOWN Switch (fig. 2); Up to Bank 3. Enter the section 4.1 Overdrive Status through the DOWN Switch (fig.3); Scroll up Number Down...
- Page 9 How to Edit the Overdrive Section 6. Scroll up with the UP Switch to get the DRIVE section; Up to Bank Bank Up to next Increase Number Number option 7. Enter this section through the Down to Down to Enter Decrease DOWN Switch (fig.
- Page 10 On each bank of XT-1 it’s possible to Copy/Paste the PreAmp/Effects settings from a different preset. Go to the bank you wish to modify, hold Bypass Switch for 3 seconds, and follow the instructions on brackets (fig. 10).
- Page 11 Back-up & Upgrade for the Configuration Manager Software XT-1 is equipped with an USB Port 2.0, which must be used strictly with an USB pendrive in order to transfer the Back Up of sounds (both source guitars and target guitars) from XT-1 to the Configurator Manager Software, make your own set up, and bring them back to XT-1 in order to make the upgrade of the device .
- Page 12 Hold simultaneusly the two switches to reset the device By switching the pedal on, during the booting process, the XT-1 Code, a special code … different for all devices, will appear on the display. This code is useful to register your device in the SIM1 Web-Store (https://store.sim-one.it/) or in the App.
- Page 13 Cabinets Simulations (IR); 7. Save your new configuration on the USB pen drive, and Exit. Bring the Pendrive to the pedal and hold the UP switch in order to do the Upgrade procedure and transfer the new configuration on XT-1.
- Page 14 Midi Master: control with for PC/Mac XT-1 other MIDI devices Select the Source Guitar Select the Target Guitar Insert Bypass in the Bank Adjust the Target Guitar Gain Assign a MIDI Program Change in the Bank Load ad insert IR for Cabinet...
- Page 15 Total pre-sets …..…………………………………………...……………………………………………………………………………………………………….……………….………30 Guitar Profiles pre-loaded ………………………….…………………………………………………………………………………………………………………………………12 AD Conversion …..…………………………………………………………………………………………………………………………………………….……………………...32 bit DA Conversion..…....................................32 bit Sample Rate ………………………………………………………………………………………………………..…………………………………………..……………….48/96 kHz Input Impedance ……………..……………………………………………………………………………………………………..………………………………………….…..…1 MΩ Output Impedance (Standard Output-OUT)……………….……..………………………………..……………………………………………………………...680 Ω Output Impedance (Balanced Output-BAL) …………………………………………………….…………………………………………………………….…...10 kΩ Recommended Load Impedance …..………………………………..…………………………………………………………………………….….10 KΩ or Greater Signal To Noise ratio ……………………………………..…………………………………..………………………………………………………………..…………….>...
- Page 16 Graphics or painting imperfections are due to handcraft production “Sim1 – Sound Imprinting’ is a registered trademark property of Sim1 Srl. All other product names and images, trademarks and artists names are the property of their respective owners, which are in no way associated or affiliated with Sim1.
