Summary of Contents for SIM1 XT-B
- Page 1 Firmware 1.0...
- Page 2 balanced on/off & 9/12 V a. Learn & Play - automatic pickups matching (hold bypass + down) Set up your Source Bass by recording Neck, Mid and Bridge position pickups. The system will automatically match the Target Bass pickups with your Source Bass pickups.
- Page 3 & Set-up your source bass (automatic pickups matching). For a perfect bass guitar emulation the pedal must learn the tone of each pickup of the Source Bass. With this procedure it will automatically make the matching between the Target and the Source Bass pickups. 1.
- Page 4 8. At the end of the Computing Process, press the UP switch again to end the bypass Learning procedure. At this point the Target Bass profiles included in XT-B will be associated to the pickups you just configured. Scroll UP and DOWN the Switch selectors to test the variety of sounds.
- Page 5 Pickup Matching 9. For each Bass Profile Preset, while performing, it is recommended to activate the Pickup of your Source Bass according to the suggestion of the display. This allows to reach a sound as close as possible to that one of the Target original Target Bass.
- Page 6 Profile one pickup at a time (pickup matching through editor) This function allows you to record more Source Bass pickups, without modifying the previous configuration of the pedal. The matching between Target and Source Bass pickups requires the use of the Editor for PC/Mac. Useful to: •...
- Page 7 This feature 1.1 Gain (adjust the volume of each target bass) allows you to connect the XT-B directly to the PA or to 1.2 Bypass (set the bank in bypass mode) a powered speaker, and use it as a stand alone pedal.
- Page 8 How to Edit the Overdrive Section 1. Scroll up with the UP Switch until you reach “3 – Overdrive” section; 2. Enter this section through the DOWN Switch (fig. 2); 3. Enter the section “3.1 OD Status” (Overdrive Status) through the DOWN Switch Up to Bank Scroll up...
- Page 9 How to Edit the Overdrive Section 6. Scroll up with the UP Switch to get to the DRIVE section; Up to Bank Bank Up to next Increase Number Number option 7. Enter this section through the Down to Down to Enter Decrease DOWN Switch (fig.
- Page 10 How to Edit the Overdrive Section 13. When you finish editing your preset, exit by repeatedly pressing the BYPASS Switch, until you get the SAVE CHANGES page 14. Use UP Switch to save changes (fig. 10), DOWN Switch not to save, BYPASS Up to Bypass to Confirm...
- Page 11 Back-up & Upgrade for the Configuration Manager Software XT-B is equipped with a USB Port 2.0, which must be used strictly with a USB pendrive in order to transfer the Back Up of profiles (both source basses and target basses) from XT-B to the Configurator Manager Software, and to reload your profiles (Upgrade) in your device after editing.
- Page 12 Hold simultaneusly the two switches to reset the device In order to get the XT-B Code, a unique serial number, hold for 3 seconds the BYPASS Switch, and it will appear on the display. This code is useful to register your device in the SIM1 Web-Store (https://store.sim-one.it/).
- Page 13 6. Create your favourite configuration (matching Source/Target bass) in the available 30 banks. Edit Volumes and add Cabinets Simulations (IR); 7. Save our new configuration on the USB pen drive, bring it to the pedal and hold the UP switch in order to do the Upgrade procedure and transfer the new configuration on XT-B.
- Page 14 Midi Master: control with per PC/Mac XT-B other MIDI devices Select the Source Bass Select the Target Bass Insert Bypass in the Bank Adjust the Target Bass Gain Assign a MIDI Program Change in the Bank Load ad insert IR for Cabinet...
- Page 15 Total pre-sets …..…………………………………………...……………………………………………………………………………………………………….……………….………30 Guitar Profiles pre-loaded ………………………….…………………………………………………………………………………………………………………………………12 AD Conversion …..…………………………………………………………………………………………………………………………………………….……………………...32 bit DA Conversion..…....................................32 bit Sample Rate ………………………………………………………………………………………………………..…………………………………………..……………….48/96 kHz Input Impedance ……………..……………………………………………………………………………………………………..………………………………………….…..…1 MΩ Output Impedance (Standard Output-OUT)……………….……..………………………………..……………………………………………………………...680 Ω Output Impedance (Balanced Output-BAL) …………………………………………………….…………………………………………………………….…...10 kΩ Recommended Load Impedance …..………………………………..…………………………………………………………………………….….10 KΩ or Greater Signal To Noise ratio ……………………………………..…………………………………..………………………………………………………………..…………….>...
- Page 16 Graphics or painting imperfections are due to handcraft production “Sim1 – Sound Imprinting’ is a registered trademark property of Sim1 Srl. All other product names and images, trademarks and artists names are the property of their respective owners, which are in no way associated or affiliated with Sim1.
